Detection of wooden objects

1. For the detection of wooden objects, proceed
as described in the section „Detection of vari-
ous objects".
2. If you have found something with the multi-
purpose detector, mark it.
3. To be sure that the found object is made of
wood, slide the function switch
position „METAL". Look for metal at the same
point.
4. If the appliance does not find anything at this
point in the mode „METAL", the object is
made of wood. If the appliance finds an ob-
ject at this point in the modus „METAL", then
the object is made of metal.
5. In this case, look in a different place in the
„STUD" mode, and repeat steps 1 to 4.

Laser marking

Use the laser marking function to align pictures, cup-
boards, and other things, vertically or horizontally.
Slide the function switch
„LASER". A laser line is produced.
Horizontal laser line
1. Hold the multi-purpose detector horizontally
to the wall. To do this, direct the appliance so
that the air bubble in the vial
the two marker lines.
to the
9
to the position
9
lies between
8
GB/CY 23
