IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed, including the following: Please read all instructions carefully before using any appliance . Always ensure that the voltage on the rating label corresponds to the mains voltage in your home .
Page 5
11 . To reduce the risk of electric shock, do not immerse or expose the motor assembly, plug or the power cord to water or any other liquid . 12 . Never immerse the unit in water or any other liquid for cleaning purposes . 13 .
Page 6
24 . The manufacturer does not accept responsibility for any damage or injury caused by improper or incorrect use, or for repairs carried out by unauthorised personnel . 25 . In case of technical problems, switch off the appliance and do not attempt to repair it yourself . Return the appliance to an authorised service facility for examination, adjustment or repair .
ADDITIONAL IMPORTANT SAFEGUARDS If this appliance begins to malfunction during use, immediately turn the ON/OFF/ REVERSE button to OFF (O) and unplug the cord . Do not use or attempt to repair the malfunctioning appliance . If this appliance falls or accidentally becomes immersed in water, unplug it immediately . Do not reach into the water! Do not use this appliance after it has fallen into or becomes immersed in water .
NOTES ON THE CORD The provided short power-supply cord (or detachable power-supply cord) should be used to reduce the risk resulting from becoming entangled in or tripping over a longer cord . Do not use an extension cord with this product . PLASTICIZER WARNING CAUTION: To prevent Plasticizers from migrating to the finish of the countertop or table top or other furniture, place NON-PLASTIC coasters or place mats between the appliance and the finish...
INTRODUCTION TO COLD PRESS JUICER Cold press juicing technology operates via a chewing (mastication) method to produce high quality juice from each fruit and vegetable . The single juicing screw first crushes, then compresses and squeezes out the juice . There are no fast-spinning blades that cut and pulverize the fruits and vegetables to produce juice .
ASSEMBLY INSTRUCTIONS WARNING: ALWAYS MAKE SURE COLD PRESS JUICER IS UNPLUGGED BEFORE STARTING ASSEMBLY. IMPORTANT: The Cold Press Juicer’s safety system prevents the unit from being turned ON unless it is completely and properly assembled . Place the motor base on a flat, stable surface . Check to make sure the groove in the rubber seal ring is properly attached to the center hole in the bottom of the processing bowl .
Page 12
Watching through the clear processing bowl, attach the base of the crushing auger through the processing bowl’s center hole and over the motor base spindle . (See Figure 4 . ) Make sure the crushing auger drops down and rests flush against the bottom of the processing bowl . When securely attached, the crushing auger will not turn on the motor base .
Page 13
Rest the lid on the auger spindle so that the lid’s locking tab sits slightly to the right of the black bar . (See Figure 6 . ) Grasping the Cold Press Juicer firmly by the motor base handle in one hand, grasp the hopper to turn the lid clockwise .
PREPARING FRUITS AND VEGETABLES FOR JUICING • Clean all produce thoroughly, using a • Leafy greens, parsley, wheatgrass, and sprouts natural bristle brush . If you are not using should be bunched into a small, tight ball organic produce, we recommend using and pushed through the hopper with the a biodegradable cleaner to help remove food pusher .
PREPARING FRUITS FOR FROZEN SORBET • Peel over-ripe bananas and freeze • Peel, seed and freeze 1 to 2-inch chunks in an airtight bag . of larger fruits such as pineapple, mango, apples, oranges, lemons and limes . • Freeze fresh berries: strawberries, seedless red grapes, blueberries, raspberries, kiwis .
Page 16
Place washed and trimmed 1 to 2-inch chunks of produce into the hopper . Use the food pusher to gently direct food through the hopper and processing bowl . Press the ON/OFF/REVERSE button to ON to begin juicing . NOTE: To ensure maximum results when juicing, alternate between leafy, harder, and softer produce . If the motor jams, press the REVERSE button (REV) to reverse the direction of the crushing auger .
DISASSEMBLY INSTRUCTIONS WARNING: ALWAYS MAKE SURE THE COLD PRESS JUICER IS UNPLUGGED BEFORE STARTING DISASSEMBLY. The lid is locked when the locking tab is fully inserted into the handle slot in the upper rim of the processing bowl and perfectly aligned with the black bar . Holding the Cold Press Juicer firmly by the motor base handle in one hand, grasp the hopper in the other hand and turn the lid counter-clockwise to unlock .
USER MAINTENANCE INSTRUCTIONS This appliance requires little maintenance . It contains no user serviceable parts . Do not try to repair it yourself . Contact a qualified appliance repair technician if the product requires servicing . CARE & CLEANING INSTRUCTIONS IMPORTANT: Due to the slow rotating crushing auger, the accumulation of pulp residue can occur on the base of the auger, stainless steel juice strainer, and the channel on the bottom of the processing bowl .
Rinse the crushing auger in warm running water . Use the cleaning brush to remove any debris from the base of the auger . Rinse the processing bowl in warm running water . Use the handle of the cleaning brush to help clear pulp from the spout;...
TROUBLESHOOTING PROBLEM POSSIBLE SOLUTION Cold Press Juicer • The Cold Press Juicer’s safety system prevents the unit from operating unless the lid is completely and properly assembled . The crushing will not turn ON . auger’s top spindle must press against the lid; the lid’s tab must be fully inserted into the slot in the upper rim of the processing bowl .
Page 21
PROBLEM POSSIBLE SOLUTION Excessive noise or vibrations • Try alternating different types of produce while juicing . Cold Press Juicer occur after Cold Press Juicer • Because of the ’s motor, a small amount of is turned ON . noise and/or vibration is normal when the unit is turned ON and as it comes to a complete stop .
TWO YEAR WARRANTY Please retain your proof of purchase/receipt in the event of a claim under warranty this receipt must be produced. Warranty House Innovative Technologies Africa (Pty) Ltd warrants to the original purchaser of this product (“the customer”) that this product will be free of defects in quality and workmanship which under normal personal, family or household use and purpose may manifest within a period of 2 (Two) years from the date of purchase (“warranty period”).
Page 23
TWO YEAR WARRANTY (CONT’D) The guarantee does not cover accidental damage, misuse, cabinet parts, knobs or consumable items. The product must be correctly installed and operated in accordance with the instructions contained in this manual. It must be used only for domestic purposes. 10.
Page 24
For customer service questions or comments 021 418 5242 BELLA® is a registered trademark of Sensio Inc . , Montréal, Canada H3B 3X9 . Made in China . Distributed by: House Innovative Technologies Africa (Pty) Ltd, www . h ouseitafrica . c om...
