KOBALT and the K Design are registered
trademarks of LF, LLC. All Rights Reserved.
ATTACH YOUR RECEIPT HERE
Serial Number
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-888-3KOBALT (1-888-356-2258),
8 a.m. - 8 p.m., EST, Monday - Friday.
AB13690B
®
3-IN-1 FLOORING
Purchase Date
1
ITEM #0471555
NAILER
MODEL #SGY-NS7
Français p.17
Español p. 33
kobalttools.com
Advertisement
Table of Contents
Related Manuals for Kobalt SGY-NS7
Summary of Contents for Kobalt SGY-NS7
- Page 1 MODEL #SGY-NS7 Français p.17 Español p. 33 ® ® KOBALT and the K Design are registered trademarks of LF, LLC. All Rights Reserved. ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT (1-888-356-2258), 8 a.m.
-
Page 2: Table Of Contents
TABLE OF CONTENTS ....................2 Package Contents ....................... 3 Safety Information ....................... 4 Preparation ........................5 Operating Instructions ....................6 Clearing a Jammed Fastener ..................9 Care and Maintenance ....................12 Storage ........................13 Troubleshooting......................13 Warranty ........................14 Exploded Views ......................15 PRODUCT SPECIFICATIONS DESCRIPTION SPECIFICATIONS... -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Whack Cap Gun Body Base Magazine Air Inlet Handle Release Button Base Plate For 1/2 Inch And 5/8 Inch Wood Flooring Base Plate For 3/4 Inch Wood Flooring Hex Key Mallet Oil Bottle Latch kobalttools.com... -
Page 4: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate and use the product. If you have any questions regarding the product, please call customer service at 1-888-3KOBALT (1-888-356-2258), 8 a.m. - 8 p.m., EST, Monday - Friday. THIS INSTRUCTION MANUAL CONTAINS IMPORTANT INFORMATION NECESSARY FOR THE PROPER ASSEMBLY AND SAFE USE OF THIS TOOL. -
Page 5: Preparation
SAFETY INFORMATION • • Keep proper footing at all times. Do not overreach, as slipping, tripping, and/or falling can be a major cause of serious injury and/or death. Be aware of excess hose left in working area or work surface. •... -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS Note: . ALWAYS remember to use proper eye and ear protection when using this item. There are three different types of fasteners which can be used with this 3-in-1 flooring nailer. • 16 Ga T-cleats (Maximum fastener capacity 100 pcs.) •... - Page 7 OPERATING INSTRUCTIONS 3. Pull back on the latch (M) at the base of the magazine (D) until it locks into position (See Figure 3). You will hear a click when latched properly. 4. Once the latch is pulled all the way back and is in the locked position, load the fasteners into the magazine (see figure 4).
- Page 8 OPERATING INSTRUCTIONS Before add 2 - 3 drops of pneumatic tool oil(part L) to the air inlet before each use.(See Figure 6) NOTE: Make sure the base plate screws do not protrude and that the proper safety equipmaent is worn. Keep hands and other parts of the body away from the tool’s discharge area when connecting the air supply.
-
Page 9: Clearing A Jammed Fastener
OPERATING INSTRUCTIONS foot plate to secure.(See Figure 9) 10. Using the mallet (K), strike the whack cap (A) of angle. Repeat this process.(See Figure 10) Note: Consult your flooring manufacturer for recommendation on proper spacing in between fasteners. CLEARING A JAMMED FASTENER CAUTION NEVER point the tool removed. - Page 10 CLEARING A JAMMED FASTENER Strike whack cap to release any air which may be built up in gun.(See Figure 2) If jammed fastener can be seen outside, remove with pliers (Not included).(See Figure 3) Remove with pliers If the fastener gets stuck inside to where it cannot be seen (See Figure 4), you should open the nail head cover(part 24 shown on parts list of manual).
- Page 11 CLEARING A JAMMED FASTENER Remove the spacer (part 56 shown on parts list of manual) un-tighten 2 screws by turning counter clockwise. (See Figure 5) Open nail head cover (part 24 shown on parts list of manual) and remove 4 screws by turning counter clockwise. (See Figure 6) Remove the jammed fastener.
-
Page 12: Care And Maintenance
CLEARING A JAMMED FASTENER Once the fasteners have been removed, attach the nail head cover (part 24 shown on parts list of manual) and tighten 4 screws by turning clockwise.(See Figure 8) Install the spacer(part 56 shown on parts list of manual) by tighting 2 screws turning clockwise.(See Figure 9) Once the jammed fastener(s) have been cleared, connect the air tool to the air supply and test fire three to five fasteners into a scrap piece... -
Page 13: Storage
CARE AND MAINTENANCE MAINTENANCE DESCRIPTION TOOLS OR MAXIMUM REQUIRED MATERIALS SERVICE INTERVAL REQUIRED Each Use or Needed Every 2 Hrs Replace worn or broken parts See above Pneumatic Lubrication lubrication tool oil guidelines CAUTION • If the proper care and maintenance is not followed with this tool, there is a potential hazard that will result in property damage, serious injury and/or death. -
Page 14: Warranty
TROUBLESHOOTING PROBLEM POSSIBLE CAUSES CORRECTIVE ACTION The tool does 1. The air supply is inadequate. 1. Verify that the air supply is not operate adequate. properly. It does not 2. Lubrication is inadequate. 2. Pour up to 6 drops of oil into drive the fasteners the air inlet. -
Page 15: Exploded Views
EXPLODED VIEWS 27 58 38 G 40 41 58 59 PART DESCRIPTION PART DESCRIPTION Whack Cap O-ring 34.5 × 2.65 Screw M5 × 20 Piston Sleeve O-ring 25 × 3.55 O-ring 32 × 4.5 Cylinder Cover O-ring 12.8 × 2.5 Bolt M4 ×... - Page 16 Roll Pin Pin Bush Spring II O-ring 2 × 1.5 E-ring Base Plate For 1/2 Inch Spring Pin And 5/8 Inch Wood Flooring Printed in China KOBALT® and the K Design® are registered trademarks of LF, LLC. All Rights Reserved. kobalttools.com...
