Section 1: purpose and applicability

The purpose of this document is to detail the installation and operation instructions
for the HDX Compact DC Power Distribution Center.

1.1 product Model

This document applies to Comm/net Systems, Inc product with model configurations:
y 016-410-10 HDX 300 Isolated A/B Input
y 016-412-10 HDX 300 Single Input A/B
y 016-450-10 HDX 400 Isolated A/B Input
y 016-451-10 HDX 400 Single Input A/B
y 016-452-10 HDX ABC 10 Isolated Diode Routed Input

Section 2: theory of Operation

2.1 introduction

The HDX is a compact DC distribution center for rack-mount telecom and broadband
applications.

2.2 Features

y High-reliability breaker distribution
y Supports AM style bullet terminal breakers
y Up 100A max per breaker channel (see electrical specifications)
y LEDs indicate status at a glance
y Form C alarm contacts
y Adjustable brackets for 19" or 23" rack mount installation

Section 3: unpacking and inspection

The Comm/net Systems HDX Compact DC Power Distribution Center was carefully
packaged at the factory to withstand the normal rigors of shipping. However, you
should carefully inspect the box and contents to confirm that no damage has occurred
in transit. Most shipping carriers require notification of shipping damage within twenty-
four hours of delivery, and it is the responsibility of the recipient to inspect the shipment
immediately upon receipt.

3.1 package Contents

Included with your product are the following items:
y HDX DC Distribution Center
y Mounting hardware kit with necessary screws and washers
y Rear plastic bus bar safety shield
Figure 1. hdx panel with rack mount brackets
Figure 2.
hdx panel with rear plastic safety shield
