- Page 1 ™ c o m p a c t d c p o w e r d i s t r i b u t i o n Setup and OperatiOn Manual...
- Page 2 ™ c o m p a c t d c p o w e r d i s t r i b u t i o n Comm/net Systems, inc. 4237 – 24th Avenue West Seattle, WA 98199 Setup and OperatiOn Manual tel: 206.282.8670 Fax: 206.282.8684 www.commnetsystems.com...
-
Page 3: Table Of Contents
4.9 Installing Breakers ......... .7 4.9.1 Breaker Inventory For HDX ABC 10 ..... . .8 product support 4.9.2 Breaker Inventory For All Other Models . -
Page 4: Section 1: Purpose And Applicability
016-451-10 HDX 400 Single Input A/B y 016-452-10 HDX ABC 10 Isolated Diode Routed Input Section 2: theory of Operation 2.1 introduction The HDX is a compact DC distribution center for rack-mount telecom and broadband applications. 2.2 Features thiS page intentiOnally leFt Blank... -
Page 5: Section 4: Installation
The HDX panel can be installed in any standard 19-inch or 23-inch relay rack. The panel itself occupies only 2RU, but it is recommended that space be left free above and below the panel to ease cable routing. It is common to mount the HDX panel at the topmost rack position. -
Page 6: Mounting
SaFety equipMent. CHASSIS GROUND The chassis ground is located in the side of the panel (see "Figure 3. HDX Ground Threaded for 1/4”-20 Oerminal Location"). A two hole lug landing position is provided. See table below for nOtiCe termination information screw is provided for attaching a chassis ground cable. -
Page 7: Output Connections
The bottom row of Step 12. Inventory the breakers (See "4.9.1 Breaker Inventory For HDX ABC 10" and terminals are the fused outputs for each fuse holder as numbered. Refer to "Breaker Inventory For All Nther Models"... -
Page 8: Breaker Inventory For Hdx Abc 10
Specifications 4.9.1 Breaker inventory For hdx aBC 10 Upon first power up there will be a red LED flashing to indicate breaker inventory a.1 electrical Specifications needs to be performed. Anytime the circuit breaker compliment is changed, you will need to update the breaker inventory for correct monitoring of breaker status. -
Page 9: Supported Lugs For Termination
ManuFaCtuReR ManuFaCtuRe paRt # CRiMp tool RequiRed #2 AWG 538-089-10 Burndy YAZV2C2TC14FX, Brown, 10 Burndy U4CRT, W2CVT, W2CRT, X2CRT HDX™ HDX™ HDX™ HDX™ Setup anD OperatiOn Manual Setup anD OperatiOn Manual Setup anD OperatiOn Manual Setup anD OperatiOn Manual paGe 10 - inStallatiOn... -
Page 10: Appendix B: Mechanical Illustrations
B: Mechanical illustrations Figure 9. Figure 10. Connection detail hdx 300 a/B isolated input Model 016-410-10 rear detail hdx 300 a/B isolated input Model 016-410-10 HDX™ HDX™ HDX™ HDX™ Setup anD OperatiOn Manual Setup anD OperatiOn Manual Setup anD OperatiOn Manual... - Page 11 Figure 11. Figure 12. top and Bottom view hdx 300 a/B isolated input Model 016-410-10 Connection detail hdx 300 Single input Model 016-412-10 HDX™ HDX™ HDX™ HDX™ Setup anD OperatiOn Manual Setup anD OperatiOn Manual Setup anD OperatiOn Manual Setup anD OperatiOn Manual...
- Page 12 Figure 13. Figure 14. rear detail hdx 300 Single input Model 016-412-10 top and Bottom view hdx 300 Single input Model 016-412-10 HDX™ HDX™ HDX™ HDX™ Setup anD OperatiOn Manual Setup anD OperatiOn Manual Setup anD OperatiOn Manual Setup anD OperatiOn Manual...
- Page 13 Figure 16. Figure 15. rear detail hdx 400 a/B isolated input Model 016-450-10 Connection detail hdx 400 a/B isolated input Model 016-450-10 HDX™ HDX™ HDX™ HDX™ Setup anD OperatiOn Manual Setup anD OperatiOn Manual Setup anD OperatiOn Manual Setup anD OperatiOn Manual...
- Page 14 Figure 17. Figure 18. top and Bottom view hdx 400 a/B isolated input Model 016-450-10 Connection detail hdx 400 a/B Single input Model 016-451-10 HDX™ HDX™ HDX™ HDX™ Setup anD OperatiOn Manual Setup anD OperatiOn Manual Setup anD OperatiOn Manual...
- Page 15 Figure 19. Figure 20. rear detail hdx 400 a/B Single input Model 016-451-10 top and Bottom view hdx 400 a/B Single input Model 016-451-10 HDX™ HDX™ HDX™ HDX™ Setup anD OperatiOn Manual Setup anD OperatiOn Manual Setup anD OperatiOn Manual...
- Page 16 Figure 21. Connection detail hdx a/B/C diode routed input Model 016-452-10 Figure 22. top and Bottom view hdx a/B/C diode routed input Model 016-452-10 HDX™ HDX™ HDX™ HDX™ Setup anD OperatiOn Manual Setup anD OperatiOn Manual Setup anD OperatiOn Manual...
- Page 17 Blank HDX™ Setup anD OperatiOn Manual paGe 26...
- Page 18 about Comm/net Systems Corporate headquarters 24/7 Sales & Service Comm/net Systems, Inc. (CSI) is the leader in high power density Comm/net Systems, Inc. To purchase Comm/net Systems solutions, contact your communications power systems. Comm/net offers comprehensive 4237 – 24th Avenue West Comm/net Systems representative at: (800) 274-0544 power and communications site systems integration and deployment Seattle, WA 98199...
