Summary of Contents for TRANWO Technology 20t

  • Page 2: For Your Safety

    For Your Safety Accessories Use only the AC adapters provided. Use of any others may damage the camera and/or receiver. Connecting to Other Devices When connecting to any other device, read its user's guide for detailed safety instructions. Do not connect incompatible products. Use Qualified Service To avoid electrical shock, do not open the case of this product.
  • Page 3 For Your Safety Electronic Devices Most modern electronic equipment is shielded from radio frequency (RF) signals. However, certain electronic equipment may not be shielded against the RF signals from your GigaAir 3050. Operation of any radio transmitting equipment may interfere with the functionality of inadequately protected medical devices.
  • Page 4 Welcome to the world of smart wireless video with TRANWO's GigaAir series of products. The GigaAir 3050 consists of a B/W camera and a B/W monitor. The compact, mountable camera sends clear, stable pictures and sound to the monitor, over distances of up to 300 feet. Offering the latest in wireless technology, the GigaAir 3050 allows parents to take care of household duties while still keep an eye on their babies/children anywhere in the house or garden.
  • Page 6 GigaAir 3050 Layout Front View of Camera (GigaAir 30T) Infrared LEDs Eight LEDs to provide infrared light for night vision. Lens Focuses image automatically without any adjustment. Microphone Lens Body Rotates up to 180 degrees.
  • Page 7 GigaAir 3050 Layout Rear View of Camera (GigaAir 30T) Channel Selection Switch 2.4 Ghz Audio/Video Antenna Select the channel by sliding (Front ) the slide switch to the channel Transmits audio/video signals. number you want. Caution: Antenna does not rotate You must select the same freely through 360 degrees.
  • Page 8 GigaAir 3050 Layout Bottom View of Camera (GigaAir 30T) Mounting Hole Battery Compartment...
  • Page 9 GigaAir 3050 Layout Front View of Monitor (GigaAir 50R) Power Indicator LED Screen ON/OFF Screen can be turned off for Volume/Power Control audio monitoring only.
  • Page 11 GigaAir 3050 Layout Bottom View of Monitor (GigaAir 50R) Battery Compartment...

  • Page 14: Power Supply

    Setting Up your GigaAir 3050 - Camera (GigaAir 30T) Power Supply To Load Batteries Open the battery compartment cover Insert batteries so their plus (+) and minus in the direction of the arrow. (-) ends are facing as shown in the illustration.
  • Page 15 Setting Up Your GigaAir 3050 - Camera (GigaAir 30T) 3 Close the battery compartment cover. Make sure the battery compartment cover is locked securely. Press Slide the POWER Switch to the ON position. The LED on the back of the camera should light.
  • Page 17 Setting Up Your GigaAir 3050 - Camera (GigaAir 30T) Changing the Lens Orientation...
  • Page 19 Setting Up Your GigaAir 3050 - Monitor (GigaAir 50R) Close the battery compartment cover. Make sure the battery compartment cover is locked securely. Incorrect use or handling of batteries can cause them to leak or burst and seriously damage your monitor. "...

  • Page 20: Using Ac Power

    Setting up your GigaAir 3050 - Monitor (GigaAir 50R) Using AC Power Be sure that the monitor is turned off before connecting or disconnecting the power adapter. Plug one end of the adapter labeled OUTPUT:...

  • Page 21: Fine Tuning

    Setting up your GigaAir 3050 - Monitor (GigaAir 50R) Fine Tuning Adjust the video image using the V-HOLD, CONTRAST and BRIGHTNESS adjustment knobs on the back of the monitor, as needed. Place the monitor in a convenient location, and then adjust its antenna so that the front (curved side) faces the room where the camera is set up.

  • Page 22: Other Applications

    Setting Up Your GigaAir 3050 - Other Applications Other Applications Recording on a VCR The monitor comes with Audio/Video output jacks for connecting to a VCR for recording. Connect the Audio/Video cable's white and yellow plugs to the white and Tips yellow Audio/Video jacks of the monitor and to the white and yellow input jacks of the VCR, matching the plug colors with the jacks on both the...
  • Page 23 Setting up your GigaAir 3050 - Other Applications Other Applications Night Vision The camera has eight high-intensity LEDs for picking up clear images in unlit locations. To turn on the night vision function, slide the switch as shown in the illustration on the right.

  • Page 24: Auto-Sequence Function For Multiple Location Monitoring

    Auto-Sequence Function for Multiple Location Monitoring The monitor's built in auto-sequence function is ideal for security use. You can purchase additional GigaAir 30T wireless cameras with built-in transmitter to monitor and transmit image and sound to the monitor. The monitor can be used with up to four cameras on four different channels and display them in sequence on a single TV/monitor.
  • Page 25 Auto-Sequence Function for Multiple Location Monitoring Note 1: The monitor will auto detect the receiving channels and display them in sequence. When only one channel dipswitch is in the ON position, the monitor will receive the channel continuously, without regard to the position of the 5th dipswitch.

  • Page 26: Orienting Antennas For Optimal Performance

    Orienting Antennas for Optimal Performance Placing Place the camera and monitor on a flat, stable surface to prevent damage from falling. Try to place the units as high as possible to avoid any possible interference from people walking between the camera and the monitor. Microwave ovens can cause interference.
  • Page 27 Orienting Antennas for Optimal Performance The audio/video antennas have been designed to pivot but have limited rotation in either clockwise or counterclockwise directions. Antenna does not rotate freely 360 degrees. Rotating past the point where resistance is felt will result in permanent damage to both antenna and mechanical stopper.

  • Page 28: Troubleshooting

    Troubleshooting If you are not getting any signal at all Check the power on the camera and monitor Make sure power plugs are pushed all the way in Check the CHANNEL switches on both camera and monitor are set to the same number If the camera/monitor is powered by batteries, replace all batteries with new ones...
  • Page 29 Troubleshooting Make sure the camera and monitor are within range (up to 300 feet) Check the channel dipswitch positions on the monitor. If you have any questions on using the GigaAir 3050, please email us at: support@tranwo.com...

  • Page 30: Care And Maintenance

    Care and Maintenance Your GigaAir 3050 is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you to fulfill any warranty obligations and to enjoy this product for many years. " For best performance, don't touch the antennas unnecessarily.
  • Page 31 Care and Maintenance " Do not drop , knock, or shake the unit. Rough handling can break internal circuit boards. " Do not use harsh chemicals, cleaning solvents, or strong detergents when cleaning. Wipe with a soft cloth slightly dampened in a mild soap-and-water solution. If the GigaAir 3050 is not working properly, take it to your nearest qualified service facility.

  • Page 32: Specifications

    Specifications Camera (GigaAir 30T) Frequency 2.4 ~ 2.4835 GHz Range 300 feet (100 meters) clear line of sight Antennas Directional circular-polarized antennas Channel 4 selectable channels AV mod/demod. method Infrared LEDs Image Sensor 1/4" CMOS image sensor EIA: 320 (H) x 240 (V) Effective Pixels CCIR: 352 (H) x 288 (V) Lens...
  • Page 33 Specifications Monitor (GigaAir 50R) Frequency 2.4 ~ 2.4835 GHz Range 300 feet (100 meters) clear line of sight Antennas Directional circular-polarized antennas Channel 4 selectable channels AV mod/demod. method Sound Max. Output 800mW Hor. Pull-In + 200Hz 200Hz Hor. Hold + 400Hz 400Hz Linearity V...

  • Page 34: Fcc Statement

    FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 35 Additional transmitter for sending from multiple sources GigaAir 2020 2.4 Ghz Wireless audio/video Sender Complete set, with built-in remote control function, includes one receiver (GigaAir 20R), one transmitter (GigaAir 20T), accessories GigaAir 20R Additional receiver for multiple audio/video component installations, with built-in...
