Summary of Contents for AirMobi iPlay

  • Page 1       Quick Installation Guide  Wireless Music Router  iPlay    ...
  • Page 2 Part 1: Check the Package                                                                              iPlay                              Quick Installation Guide ...
  • Page 3: Repeater Mode

      AP mode  It extends your existing hardwired network to your wireless clients.        Recommend for: hotel, small office, etc.  Repeater Mode  It extends the coverage of your root wireless router, boost the wireless  signal strength.        Recommend for: villa, big house, etc.   ...
  • Page 4: Router Mode

    Part 4: Installation                                                                                        Before hardware connection, please write down the Wi‐Fi name and Wi‐Fi  Password of your router on the label attached on the iPlay.   ...
  • Page 5   AP Mode  Step 1: Connect the LAN/WAN port of iPlay to Internet with an Ethernet  cable. Then, move the switch to “AP Mode” and plug the iPlay into a wall  outlet. Verify that the power LED has turned blue.    Step 2: From your laptop or mobile device go to your Wireless Utility to  display the available wireless networks and select the Wi‐Fi name(ex:  AirMobi_222222). Then, enter the Wi‐Fi password (ex: bdef222222).      Note: Once completed the two steps, your laptop or mobile device can  access the Internet.  Repeater Mode  Step 1: move the switch to “Repeater Mode” and plug the iPlay into a wall  outlet. Verify that the power LED has turned blue.    Step 2: Press the WPS button of your root wireless router or AP, and then  press the WPS button of iPlay within two minutes. iPlay will connect to your  root wireless router or AP automatically.   ...
  • Page 6     Note: The Wi‐Fi name and Wi‐Fi password of iPlay are same as your root  wireless router or AP when the connection succeeds.  Router Mode  Step 1: Connect the LAN/WAN port of iPlay to DSL Modem with an Ethernet  cable. Then, move the switch to “Router Mode” and plug the iPlay into a  wall outlet. Verify that the power LED has turned blue.    Step 2: From your laptop or mobile device go to your Wireless Utility to  display the available wireless networks and select the Wi‐Fi name(ex:  AirMobi_222222). Then, enter the Wi‐Fi password (ex: bdef222222).     ...
  • Page 7   Step 3: Open your Web browser and type 192.168.0.1 in the address bar,  press Enter. A login page will pop up asking you for Username and Password.  Enter the default Username admin and Password admin, click Login.    Step 4: Follow the Setup Wizard to finish the configuration step‐by‐step.    Note: After the configuration, from your laptop or mobile device go to your  wireless utility to display the available wireless networks and select the  network that you created for Internet access.     ...
  • Page 8   Part 5: Music Streaming and USB Data Sharing                                         iPlay supports the function of Music Streaming and USB Data Sharing.  Music Streaming: It takes the music from your iPhone, iPad, iPod touch or  Android mobile devices and sends it wirelessly to any stereo or speakers in  your home.  USB Data Sharing: iPlay serves up effortless access to stored personal files  and multimedia whenever a USB disk is connected to the router’s built‐in  USB port. Music, videos, photos and files can be shared among multiple  users with the easy touch‐based iPlayShare App for iOS and Android devices,  or users with a notebook.  Using the function of USB Data Sharing, you need to insert your USB disk to  iPlay. Using the function of Music Streaming, please connect your speakers  to iPlay with an audio cable. At the same time, please make sure your  Smart Phone, Tablet and PC have been connected to the iPlay.  Using USB Data Sharing via PC  Step 1: Open My Computer and type ftp://192.168.0.1 in the address bar,  press Enter. And then you can access all files on the USB disk.   ...
  • Page 9   Using USB Data Sharing & Music Streaming via Smart Phone and  Tablet  Step 1: Search the app on the App store or Google Play, and you also can  scan the QR code to download and install the iPlayShare App to your iPhone,  iPad or Android devices.                                                Step 2: Once installed click on the icon                    to open the iPlayShare.   ...
  • Page 10     Step 3: Click on the icon                to enter the following interface. Click on  the icon surrounded by the square frame, choose play in iPlay, and then the  music will play on the stereo.          Android   ...
  • Page 11       iOS           ...
  • Page 12                                       Technical Support    For more information or troubleshooting help, please download the User Manual  from our website.    Additional support is also available on our website: www.cctairmobi.com    The website contains the latest user documentations and software updates for  AirMobi products.  Support E‐mail Address: support@cctairmobi.com    Copyright©2013 Shenzhen Huaxunark Technology Co., Ltd. All rights reserved.  ...
