Utax CDC 5526L Quick Manual

1 2 7 8
3 4 5 6 11
QUICKGUIDE CDC 5526L|5626L
Operation panel
9 10 16 17
12 13 14 15
1 Displays the Status screen, where you
can check the status, print a status
report, and pause or cancel the job in
process.
2 Displays the Copy screen, where
you can make settings required for
copying.
3 Displays the Document Box screen,
where you can operate the document
box and USB memory.
4 Displays the System Menu/Counter
menu screen, where you can check the
system settings and counters.
5 Displays the Send screen, where you
can send an e-mail, folder (SMB/FTP)
or fax.*
6 Displays the fax screen, where you can
send a fax.*
7 Displays the Addressbook screen,
where you can add, edit and delete
destinations.
8 Calls the previous destination. Also
used to enter a pause when entering a
fax number.*
9 Displays the Add Destination screen,
where you can add destinations.
10 Switches between on-hook and off-
hook when manually sending a fax.*
11 Used to register, call and delete
destinations to the one-touch key
numbers (1 to 22).
12 Shifts to switch the one-touch key
numbers (1 to 11 and 12 to 22).
Indicator is lit while shifted (12 to 22).
13 Selects black and white mode.
14 Selects full color mode.
15 Selects auto color mode.
16 Message Display. Checks what is
shown here while operating the
machine.
18 22 23 24
19 20 21 25
17 Selects the menu displayed at the
18 Selects the menu displayed at the
19 Blinks while print data is being
20 Blinks while the machine is accessing
21 Lights or blinks when an error occurs.
22 Used to select a menu item, move
23 Selects the chosen item or nalises the
24 Displays the function menu for copy,
25 Returns the Message Display to the
26 Numeric keys. Enter numbers and
27 Clears entered numbers and
28 Resets settings and displays the basic
29 Starts copying and scanning operations
30 Cancels the printing job in progress.
31 Lights when the machine's main power
32 Puts the machine to sleep or wakes it
33 Ends operation (logs out) on the
34 Used to register or recall programs.
*Only CDC 5626L
27
26 29
lower left in the Message Display.
lower right in the Message Display.
received or data is transmitted.
the memory.
the cursor when entering characters,
change a value, etc.
entered value.
print, transmission and document box.
previous screen.
symbols.
characters.
screen.
and processing for setting operations.
is on.
up.
Administration screen.
28 31 32
30 34 33
