- Page 1 LED TV control User Manual MODEL: 55THLCHD3 65THLCHD2 ATTENTION! Please read this manual carefully before installing or operating the TV. Keep this manual handy for further reference.
- Page 2 CONTENTS Introduction ......................Warnings and cautions ..................2 Main unit descriptions ....................5 Television Installation .....................9 The basic view of Remote Control board ..............11 Operation and Function Description of Keys on Remote Control ....
-
Page 3: Introduction
Introduction Thank you for choosing our product. You can use it as an LED television or as a PC monitor. To be able to make use of all application options, we commend that you read this operating manual carefully and keep it somewhere where you have quick access to it, if required. - Page 4 War nings and cautions Warning High voltages are used in the operation of this product. Do not remove the back cover of the cabinet. Refer servicing to qualified service personnel. Warning To prevent fire or electrical shock hazard, do not expose the main unit to rain or moisture.
- Page 5 War nings and cautions Minimum distances Caution 10cm 10cm If the television is to be built into a compartment or similarly enclosed, the minimum distances must be 20cm maintained. Heat build-up can reduce the service life of your television, and can also be dangerous. Heat build-up can reduce the service life of your television, and can also be dangerous.
- Page 6 War nings and cautions Caution When the product is not used for an extended period of time, it is advisable to disconnect the AC power cord from the AC outlet. Caution Avoid exposing the main unit to direct sunlight and other source of the heat.
-
Page 7: Main Unit Descriptions
Main unit descriptions 55THLCHD3 Control location 1.Power button 2.Volume up button(VOL+) 3.Volume down button(VOL-) 4.Program up button(PR+) 5.Program down button(PR-) 6.Menu button 7.INPUT button 8.Power Indicator 9. Remote Sensor... - Page 8 Main unit descriptions 65THLCHD2 Control location 1.Power button 2.Volume up button(VOL+) 3.Volume down button(VOL-) 4.Program up button(PR+) 5.Program down button(PR-) 6.Menu button 7.INPUT button 8.Power Indicator 9. Remote Sensor...
- Page 9 Main unit descriptions 10.AC power switch socket 11.USB input 55THLCHD3 12.HDMI1 input socket 13.HDMI2 input socket 14.YPBPR2 input socket PC AUDIO input socket 16.PC input socket 17.YPBPR1 input socket 18.AV intput socket 19.AUDIO L/R input socket 20.RF input socket COAXIAL output socket 22.HDMI3 input socket...
- Page 10 Main unit descriptions 10.AC power switch socket 11.AC power input 65THLCHD2 socket 12.USB input 13.HDMI1 input socket 14.HDMI2 input socket 15.YPBPR2 input socket PC AUDIO input socket 17.PC input socket 18.YPBPR1 input socket 19.AV intput socket input socket 20.AUDIO L/R 21.RF input socket COAXIAL output...
-
Page 11: Television Installation
Television Installation Connect antenna or video facility 1.Use 75Ω coaxial cable plug or 300-75Ω impedance converter to plug in antenna input terminal on the rear of the cabinet. 2.Connect the video facility to the audio, video in jack on the rear of the cabinet. VHF antenna UHF antenna Input terminal of antenna... - Page 12 Television Installation The remote control uses two 1.5V AAA batteries. For battery installation and replacement are as following: 1. Turn the remote control unit upside down. Press down the grip of battery compartment and slide the color in the direction of the arrow.
-
Page 13: The Basic View Of Remote Control Board
The basic view of Remote Control board The location and function of keys in the R/C are as the following picture : PMODE INPUT Remote control picture only for reference. The accurate remote control image while YC53-232A your receiving the real sample in hand. -
Page 14: Operation And Function Description Of Keys On Remote Control
Operation and Function Description of Keys on Remote Control 1 POWER Turn on and off,carry out the function of standby and turn-on. 2 INPUT By pressing this key, you will see the select menu of input source and you could select the source which you want quickly, press [OK] key to enter this source. - Page 15 Operation and Function Description of Keys on Remote Control ZOOM Switch the size of the picture in the sequence as following: Panorama → 4:3 → 16:9 → Zoom1 → Zoom2 → Panorama [0]~[9] Directly press the number keys to switch to the relevant program. Press this key to jump back to the previous program.
- Page 16 Operation and Function Description of Keys on Remote Control 16 VOL +/- When MUTE is off, press [VOL+]/ [VOL-] keys to increase/decrease sound volume. 17 CH +/- Change channel up/down. [OK] key is as a confirmable key in the menu operation. The others [ ] /[ ] are direction keys.
- Page 17 Operation and Function Description of Keys on Remote Control REVEAL Press this key to display the revealed content in current TELETEXT page. SUBCODE Press this key to execute TE LETEXT’s SUBCODE function. SUBTITLE Press this key to execute TE LETEXT’s SUBTITLE function. INDEX Press this key Go back directly to TELETEXT’s index page.
- Page 18 Operation and Function Description of Keys on Remote Control During playing, Press this key to stop the playing. By pressing this key , the scan forward speed will change as follows: Play →FF2X →FF4X → FF8X → FF16X → Play By pressing this key , the scan backward speed will change as follows: Play →FB →...
-
Page 19: Operation And Function Description Of Menu
Operation and Function Description of Menu First-time installation Connect the power cord and antenna to your television; then Installation Guide turn on the TV. The first time you use your TV,the Installation Please set the following options,then Guide menu will appear on the screen as right. Press OK button to begin auto tuning. - Page 20 Operation and Function Description of Menu CHANNEL MENU Press[MENU] key and then press [ ]/[ ] keys to select [CHANNEL] menu, press[OK] key to enter [CHANNEL] menu. Auto Scan DTV Manual Tuning ATV Manual Tuning Programme Edit AUTO SCAN Signal Information Sinnal Information Record Start Press [ ]/[ ] keys to select Auto Scan, then press...
- Page 21 Operation and Function Description of Menu Programme Edit Press [ ]/[ ] keys to select Programme Edit, then press [OK] key to enter sub-menu. RED: Press [RED] key to delete highlighted program. GREEN: Press [GREEN] key to rename highlighted program. YELLOW: Press [YELLOW] key to move highlighted program.
- Page 22 Operation and Function Description of Menu COLOR TEMPERATURE Press [ ]/[ ] keys to select COLOR TEMPERATURE , then press [OK] key to enter Color Temperature . Press [ ]/[ ] keys to change Color Temperature as follows: User ↔ Cool ↔ Medium ↔ Warm ↔User When Color Temperature is selected to User, you...
- Page 23 Operation and Function Description of Menu SOUND MENU Press[MENU] key and then press [ ]/[ ] keys to select [SOUND] menu, press[OK] key to enter [SOUND] menu. SOUND MODE Sound Mode Standard Treble Bass Press [ ]/[ ] keys to select Sound MODE , then press Balance Auto Volume SOUND...
- Page 24 Operation and Function Description of Menu TIME MENU Press[MENU] key and then press [ ]/[ ] keys to select [TIME] menu, press[OK] key to enter [TIME] menu. Clock Clock -- -- -- -- Press [ ]/[ ] keys to select Clock , then press [OK] key Off Time On Time Sleep Timer...
- Page 25 Operation and Function Description of Menu * Channel: Press [ ] keys to select the power-on channel number while in DTV or ATV input source. * Volume: Press [ ] keys to select the power-on volume value. Sleep Timer Press [ ]/[ ] keys to select Sleep Timer, then press [OK] key to enter sub-menu. Press [ ]/[ ] keys to change Sleep Timer as follows: →10 →20...
- Page 26 Operation and Function Description of Menu AUDIO LANGUAGES 1ST Press [ ]/[ ] keys to select Audio Language 1st, then press [OK] key to enter sub-menu. Press the [ ]/[ ] keys to select Audio Language 1st, then press [OK] key to confirm. AUDIO LANGUAGES 2nd Press [ ]/[ ] keys to select Audio Language 2nd, then press [OK] key to enter sub-menu.
- Page 27 Operation and Function Description of Menu RESTORE FACTORY DEFAULT Press [ ]/[ ] keys to select Restore Factory Default, then press [OK] key to enter sub-menu. Press the [ ]/[ ] keys to select Yes or No. press [OK] key to confirm. LOCK MENU Press[MENU] key and then press [ ]/[ ] keys to select Lock Channel...
- Page 28 Operation and Function Description of Menu PARENTAL GUIDANCE Press [ ]/[ ] keys to select Parental Guidance, press [OK] key to enter sub-menu. Press the [ ]/[ ] keys to select Parental Guidance, then press [OK] key to confirm. MEDIA OPERATION Note Before MEDIA operation plug a USB device into the USB socket of TV set, then press [INPUT] key and select input source USB to enter...
- Page 29 Operation and Function Description of Menu Use [ ] keys to navigate through menu. media file is circled with. Use [ok] key to enter media file into the play list with a token. Use [RED] key to delete current file. Use [GREEN] key to Add/Remove all files.
- Page 30 Operation and Function Description of Menu RECORD TO USB FUNCTION (PVR MODE) Only oprates under DTV mode. Not used for other input mode. RECORD START (inserting USB equip). Press[MENU] key and then press [ ]/[ ] keys to select [CHANNEL] menu, then press [ ] key to select RECORD START, Press [OK] key to start record.
- Page 31 Operation and Function Description of Menu RECORD MODE (inserting USB equip). Press[MENU] key and then press [ ]/[ ] keys to select [CHANNEL] menu, then press [ ] key to select RECORD MODE. Press [OK] key to enter RECORD MODE menu. Press [ ] keys to select channel and press [ ] keys to change channel number.
- Page 32 Operation and Function Description of Menu * SELECT DISK Choose the disk to store whatever content need record as follows, default as C: Press [ ] keys to select SELECT DISK. Press [OK] key to enter SELECT DISK sub-menu. * CHECK PVR FILE SYSTEM Press [ ] keys to select Check PVR File System.
- Page 33 Operation and Function Description of Menu TIMESHIFT(only oprates under DTV mode) *We strongly command that the capacity of the USB Device which to be used must be 2G or over. 1.Before use this function,make sure turn the TV on and under the DTV mode. 2.Press [ ](PLAY), the screen will appear index bar as fellow: SHIFT TIME/MAX SHIFT TIME:...
-
Page 34: Troubleshooting
Troubleshooting Before arranging for service, firstly know the status and then check simply as follows: Problems Check Check if the power supply is plugged in. No picture or sound. Check if the power switch is in "on" position. Picture is OK,no sound. Check if the volume control is set to the minimum or mute position. - Page 35 Troubleshooting Problems Check Check if the antenna is broken. All channels lose colour Check if the antenna is disconnected. intermittently. Check if the antenna is damaged. Poor recrption,loss of coulur Check if channels are correctly tuned(see "Fine tuning"). with certain channels. The receiver may be affected by interfernece(e.g.
