PIN CONFIGURATION OF SYSTEM CONTROL, CPU

SYSTEM CONTROL
IC101
TDA8361
IDENT 4
COLOUR 26
BRIGHT 17
CONTRAST 25
SHARPNESS 14
AFT 44
TO Y/C SEPARATION
BOARD
TO SUB VIDEO
BOARD
F2JE
IC801
M37207MB-
I DENT
1
CHROMA ID
2
KEY IN
4
RC SIGNAL
5
COLOUR
8
BRIGHTNESS
9
CONTRAST
10
SHARPNESS
11
SCLK
13
DATA
14
I2C BUS SW.
15
SYNC ID
16
PAL/NTSC
17
THRESH HOLD
19
SQ
20
CLK
21
SI
22
AFT
23
I2C SCL
25
I2C SDA
26
OSC
30
OSC
31
-3-
Vcc +5V
60
FBP
H-SYNC
63
SANDCASTLE PLS
V-SYNC
62
OSD RED
61
OSD GREEN
60
OSD BLUE
59
OSD BLANKING
57
POWER ON/OFF
56
LED DRIVE
55
AV1 SW
53
TO IC1001
AV2 SW
PINS 6, 12
52
SOUND MUTE
46
LINE MUTE
45
SC1 FUNCTION
44
SC2 FUNCTION
43
POWER FAILURE DET.
42
IGNORE
41
TITLE IN
36
PITTARI
34
NORMAL
33
TO
Q203,
Q204,
Q205
TO IC201-
PIN21
FROM
SCART1, 2
TO
DEFLECTION
BOARD
