CHASSIS ELECTRICAL PARTS LIST
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by a ! mark in this parts list and the circuit diagram show components whose value have
special significance to product safety. It is particularly recommended that only parts specified on the following parts
list be used for components replacement pointed out by the mark.
Note: Parts order must contain Service Ref. No., Part No., and descriptions.
Ref. No.
Part No.
Read description in the Capacitor and Resistor as follows:
CAPACITOR
CERAMIC 100P K 50V
Rated value: P=pico farad, U=Micro farad
Material:
CERAMIC.......... Ceramic
MT-PAPER........ Metallized Paper
POLYESTER..... Polyester
MT-POLYEST.... Metallized Polyester
POLYPRO.......... Polypropylene
MT-POLYPRO.... Metallized Polypropylene
COMPO FILM..... Composite film
MT-COMPO........ Metallized Composite
STYRENE........... Styrene
TA-SOLID........... Tantalum Solid
AL-SOLID........... Aluminium Solid
ELECT................ Electrolytic
NP-ELECT.......... Non-polarized Electrolytic
OS-SOLID.......... Aluminium Solid with Organic Semiconductive Electrolytic
DL-ELECT.......... Doble Layered Electrolytic
RESISTOR
CARBON
4.7K
J
Rated value, ohms:
K: 1,000, M: 1,000,000
Material:
CARBON........... Carbon
MT-FILM............ Metal Film
OXIDE-MT......... Oxide Metal Film
SOLID................ Composition
MT-GLAZE......... Metal Glaze
WIRE WOUND... Wire Wound
CERAMIC RES.. Ceramic
FUSIBLE RES.... Fusible
Description
Rated Voltage
Tolerance Symbols:
Less than 10PF
A: Not specified B: ±0.1PF
D: ±0.5PF
F: ±1PF
R: ±0.25-0PF
S: ±0-0.25PF E: +0-1PF
More than 10PF
A: Not specified B: ±0.1%
D: ±0.5%
F: ±1%
H: ±3%
J: ±5%
L: ±15%
M: ±20%
P: +100-0%
Q: +30-10%
U: +75-10%
V: +20-10%
X: +40-20%
Y: +150-10%
A
1/4W
Rated Wattage
Performance Symbols:
A: General B: Non flammable Z: Low noise
Other: Temperature coefficient
Tolerance Symbols:
A: ±0.05% B: ±0.1% C: ±0.25% D: ±0.5%
F: ±1%
G: ±2%
J: ±5%
M: ±20%
P: +5-15%
Ref. No.
Chassis Construction:
Model :C28WP1
Service Ref. No. C28WP1-00
1AA0B10E188A0 ASSY,PWB,CRT F2JE
1AA0B10E27600 ASSY,PWB,FRONT F2JE
C: ±0.25PF
G: ±2PF
1AA0B10E27700 ASSY,PWB,SUB POW. F2JE
1AA0B10E27800 ASSY,PWB,POW/DEF. F2JE
1AA0N10E27900 ASSY,PWB,MAIN F2JE
C: ±0.25%
G: ±2%
1AA0B10E28000 ASSY,PWB,VIDEO COM F2JE
K: ±10%
1AA0B10E28100 ASSY,PWB,AUDIO COMP F2JE
N: ±30%
T: +50-10%
1AA0B10E28200 ASSY,PWB,MEGA TEXT F2JE
W: +100-10%
1AA0B10E29500 ASSY,PWB,3L-Y SEP. F2JE
Z: +80-20%
Parts List for C28WP1B-00 and
C28WP1E-00 are shown on page 47.
SERVICE REF. No. C28WP1-00
OUT OF CIRCUIT BOARD
PICTURE TUBE
/ ! \
Q901
COIL
/ ! \
L901
/ ! \
L902
MISCELLANEOUS
A901
SP901
K: ±10%
SP902
W0C19G
W0E0M
W2V17P
W33M0B
W4T28H
W6G19M
/ ! \
W901
W902
W902A
W902B
-28-
Part No.
Description
414 008 2407
CRT W66LFC195X
645 008 6953
COIL,DEGAUSSING
645 006 4470
YOKE,DEFLECTION
645 002 9523
MAGNET,CG.PR
645 003 0000
MAGNET,CG.PR
645 019 2586
MAGNET,CG.PR
645 011 1358
ASSY,SPEAKER
645 011 1358
ASSY,SPEAKER
645 019 2845
CORD,ID CONNECTOR
645 019 2838
CORD,ID CONNECTOR
645 007 7784
CORD,ID CONNECTOR
645 004 8449
CORD,ID CONNECTOR
645 004 8425
CORD,ID CONNECTOR
645 012 7953
CORD,ID CONNECTOR
645 012 7632
ASSY,CORD,POWER
610 250 3142
ASSY WIRE,GND CONECTOR S4
610 079 4085
GROUNDING SPRING-F
610 079 4085
GROUNDING SPRING-F
/ ! \
F2JE
