- Page 1 BEETLE /moPOS 8.3” and 10.1” Tablet User Manual...
- Page 2 We are interested in your opinion about this brochure. Please send us a message if you would like to provide constructive recommenda- tions. For this, thank you in advance. Best regards, Your opinion: Wincor Nixdorf International GmbH Documentation R&D SAT11 Wohlrabedamm 31 D-13629 Berlin Email: retail.documentation@wincor-nixdorf.com...
- Page 3 BEETLE /moPOS 8.3” and 10.1” Tablet User Manual Edition June 2015...
- Page 4 All other product names mentioned in this document may be the trademarks or registered trademarks of their respective owner. Copyright © Wincor Nixdorf International GmbH, 2015 All rights reserved, especially for translation, reprint, reproduction by copying or similar processes, (in whole or part)..
-
Page 5: Table Of Contents
Charging the battery ................8 Charging by using a line adapter ..........8 Charging on a docking station, docking unit or single charger ... 9 The BEETLE /moPOS tablet............10 Front view ..................10 Ambient light sensor ..............11 Camera ..................11 Camera indicator LED .............. - Page 6 Exchange SIM card ............... 23 Exchange MicroSDXC card ............25 Connection with a POS device hub/docking unit ......27 Establish connection to the BEETLE /moPOS Device Hub ....27 Docking station by Aava (optional)..........28 Front panel ..................28 Rear ....................29 Magnetic card reader (optional) ...........
-
Page 7: Certification Of The Manufacturer
Certified safety Your device is UL and cUL certified. Important Notes The BEETLE /moPOS tablet is in accordance with the relevant safety regulations for data processing equipment. Repairs to the device may only be performed by authorized specialized personnel. Improper repairs will lead to the loss of any liability claims. - Page 8 Please ensure constructional and technical ambient conditions, which permit a flawless and efficient functioning. You should only connect the BEETLE /moPOS tablet or any other IT system to power supply networks with separate protective conductors (PE). BEETLE /moPOS Tablet user manual...
-
Page 9: Wireless Lan
Please adhere to the following warning when operating the BEETLE system. Warning Wireless network devices must not be operated in the proximity of detonators that are not shielded or in an explosion hazard environment. Except if the device was modified and adapted for this use. BEETLE /moPOS Tablet user manual... -
Page 10: General Information
/Manuals/manuals_node.html Recycling Environmental protection does not only start during the disposal of systems, but already during their production. This product was designed in accordance with our internal standard "Environmentally friendly product design and development". BEETLE /moPOS Tablet user manual... -
Page 11: Guarantee
Email: info@wincor-nixdorf.com We look forward to your email. Guarantee In general, Wincor Nixdorf (WN) guarantees a warranty of 12 months after delivery or acceptance date. This warranty covers all defects that occurred during normal use of the product. Defects based on incorrect or inadequate maintenance, incorrect use or authorized changes at the product, and unsuitable location or an unsuita- ble environment are not covered. -
Page 12: Cleaning Information
This could permanently damage the surface of the tablet PC. Make sure that the device is deactivated during cleaning, that the power plug is disconnected and that no moisture enters the inside of the device. BEETLE /moPOS Tablet user manual... -
Page 13: Before Switching On
Unpacking and checking the scope of delivery Unpack the parts and check whether they correspond to the parts listed on the delivery note. The by-pack kit of the BEETLE /moPOS tablet includes the power plug cable. Should you detect any transport damages or inconsistencies between package content and the bill of delivery, please inform your contractual partner or sales outlet of Wincor Nixdorf International GmbH. -
Page 14: Charging The Battery
Before the first use of the tablet, it should be completely charged. You can charge the tablet in two ways: first through the accompanying line adapter or by using an optionally available Wincor Nixdorf docking unit or a single charger or the Aava docking station. -
Page 15: Charging On A Docking Station, Docking Unit Or Single Charger
Please ensure that the tablet does not have any attachments, such as wrist straps, that cover the connector panel or that obstructs the access. This figure shows the BEETLE /moPOS docking unit with the BEETLE /moPOS tablet. This automatically locks the tablet. -
Page 16: The Beetle /Mopos Tablet
Front view ② ① ③ ④ ⑤ ⑥ ⑦ Ambient light sensor Microphone output Camera Camera LED indicator Charge status LED only 8.3" Charge status LED only 10.1" Windows key BEETLE /moPOS Tablet user manual... -
Page 17: Ambient Light Sensor
Press this switch ones to switch the tablet on. If the tablet is switched on and you briefly press the switch, then the system goes into sleep mode. If you press the switch for a longer time, then the tablet switches off. BEETLE /moPOS Tablet user manual... -
Page 18: Volume
The connections can be found underneath the cover on the right side of the tablet. ① ② ③ ④ ⑤ Loudspeaker only for 10.1" MicroSDXC card MicroUSB USB-A 2.0 Audio_out Stereo loudspeaker To the audio output BEETLE /moPOS Tablet user manual... -
Page 19: Microsdxc Card Slot
The socket is an audio output. This is where optional active loudspeakers, headphones, headsets or loudspeakers can be connected. If a device is connected to this socket, then the loudspeaker of the tablet is switched off. Underside Loudspeaker docking unit connection loudspeaker only 8.3“ only 8.3“ BEETLE /moPOS Tablet user manual... -
Page 20: Rear
Mechanical fastening points under the cover NFC antenna position Rear microphone output LED camera flash Camera Battery cover NFC antenna position NFC can be used to read NFC or RFID labels. Camera 8MP for high resolution images and video BEETLE /moPOS Tablet user manual... -
Page 21: Basic Settings Windows 8.1
Hold the tablet vertical and rotate now by 90 degrees to the left (counterclockwise) into a horizontal position. Use the rotation block The automatic rotation block of late tablet switches on: Slide the switch for an automatic rotation at the upper edge of the tablet. BEETLE /moPOS Tablet user manual... -
Page 22: Energy Management
Touch the icon for the energy display. Afterwards, tip on an element on the list to use the energy options. Slide from the right edge of the touch screen towards the center to display the application icons. BEETLE /moPOS Tablet user manual... -
Page 23: Battery Charging Status
Touch the icon for the energy display. Afterwards, tip on an element on the list to use the energy options. Slide from the right edge of the touch screen towards the center to display the application icons. BEETLE /moPOS Tablet user manual... -
Page 24: Energy Savings Mode
Note: The tablet should be shut down if the tablet is not used for a longer time period. It is recommended to activate the Windows command "Shutdown" to shut down the system and the tablet. BEETLE /moPOS Tablet user manual... -
Page 25: Exchange Battery
Open the battery chamber (the beveled edge of the cover is located in the upper right corner). Carefully remove the cover upwards. Depending on the tablet size, read the appropriate section for the further steps. BEETLE /moPOS Tablet user manual... -
Page 26: 8.3" Tablet
Pull the flap (1) of the battery bracket on the underside of the tablet. Remove the battery (2) upwards out of the housing. Please ensure that the battery unlatches upwards at both hooks. Remove the battery in the direction of the arrow from the lower fastenings. BEETLE /moPOS Tablet user manual... -
Page 27: Tablet
The battery is now secured. Close the battery changer using the previously removed cover. 10.1” tablet Unlock the locking (1) on both sides and lift the battery upwards (2). ② ① BEETLE /moPOS Tablet user manual... - Page 28 First, place the lower hooks into the respective openings (see arrows) and press upwards on the battery until the upper hook latches in audibly. The battery is now secured. Close the battery changer using the previously removed cover. BEETLE /moPOS Tablet user manual...
-
Page 29: Exchange Sim Card
Exchange SIM card Open the battery chamber as described above and remove the battery. Pull the SIM card from the slot. Shown for an 8.3" tablet: 10.1“ Tablet BEETLE /moPOS Tablet user manual... - Page 30 "beveled" edge points to the left. If you reinsert the battery please ensure that both brackets latch in audibly, because this means that the battery is secured. BEETLE /moPOS Tablet user manual...
-
Page 31: Exchange Microsdxc Card
Disconnect the power cable from the electrical outlet in case it should be connected. Remove it from the docking unit, docking station or the single charger in case it is currently being charged. Open the cover on the right side of the tablet. BEETLE /moPOS Tablet user manual... - Page 32 Press the SD card to unlock it. Remove the SD card. Insert the new SD card. Slightly press it into the correct position to lock it. Close the cover. BEETLE /moPOS Tablet user manual...
-
Page 33: Connection With A Pos Device Hub/Docking Unit
Additional information about the docking unit or the device hub can be found in the respective manual. Detailed information about the communication between tablet and BEETLE /moPOS device up can be found in the document "BEETLE /moPOS end user guide – getting started". BEETLE /moPOS Tablet user manual... -
Page 34: Docking Station By Aava (Optional)
Docking station by Aava (optional) Front panel ①②③ ④ ⑤ Guide pins Hooks Kensington lock (optional) Charge pins Docking connection (optional) Release button (optional) (press to remove the inserted tablet) BEETLE /moPOS Tablet user manual... -
Page 35: Rear
Rear ① ② ③ ④ ⑤ Power supply connection USB 3.0 connection (in complete expansion stage) HDMI connection (in complete expansion stage) LAN (RJ45) connection (in complete expansion stage) Kensington lock opening BEETLE /moPOS Tablet user manual... -
Page 36: Magnetic Card Reader (Optional)
The uploading of data on the card is not different from the uploading of existing magnet card devices. Holding the tablet in your hand, slide the magnet card in the direction of the arrow through the reader. Please ensure that the magnet strip points downwards to the devise. BEETLE /moPOS Tablet user manual... -
Page 37: Installation Of A Magnet Card Reader
Installation of a magnet card reader Lift the cover of the battery compartment carefully upwards (the beveled edge of the cover is located in the lower left) Using pliers, remove the cover of the connection. BEETLE /moPOS Tablet user manual... - Page 38 Remove the magnet card reader from the packing. Place the devise into the correct position. Plug the connection of the card reader into the socket. Secure the devise using the two accompanying screws (tx6) as shown in the figure. BEETLE /moPOS Tablet user manual...
-
Page 39: Technical Data
Intel Atom™ Z3745 Quad-core 1.8 GHz Graphic charac- Intel HD Graphics teristics Intel Quick Sync Video Intel Insider™ Intel Wireless Display Intel Clear Video HD External screen support: Up to 1920 x 1080 px, 60 Hz Intel Wireless Display BEETLE /moPOS Tablet user manual... - Page 40 Input voltage: 5 V DC Current consumption: max. 2 A Power supply ADP-10BW: 100-240V, 0.4 A, 50-60 Hz Charging time (in standby): 0 – 90% in 3.5 h, up to 100% in 5 h BEETLE /moPOS Tablet user manual...
- Page 41 10% up to 90% Max. drop height Vibration & shock Operation: Gms: 1.9gRMS Frequency: 10 – 1000 Hz During shutdown: Gms: 4.1gRMS Frequency: 10 – 1000 Hz Test duration: 1 hour per direction (x, y, z) BEETLE /moPOS Tablet user manual...
-
Page 42: Beetle /Mopos Tablet 10.1
64 GB MicroSDXC cards Cards with up to 2 TB are supported Wireless connec- WLAN IEEE 802.11 a/b/g/n tion 2x Dual band WiFi antenna Bluetooth 4.0 + HS (class 2 or 1 up to 7dBm) BEETLE /moPOS Tablet user manual... - Page 43 Power supply ADP-10BW: 100-240V, 0.4 A, 50-60 Charging time (in standby): 0 – 90% in 4 h, up to 100% in 5.5 h 3.5 mm Stereo headphones/microphone audio socket Audio Stereo loudspeakers at the side BEETLE /moPOS Tablet user manual...
- Page 44 10% up to 90% Max. drop height Vibration & shock Operation: Gms: 1.9gRMS Frequency: 10 – 1000 Hz During shutdown: Gms: 4.1gRMS Frequency: 10 – 1000 Hz Test duration: 1 hour per direction (x, y, z) BEETLE /moPOS Tablet user manual...
-
Page 45: Dimension 8.3" Tablet (In Mm/Inch)
Dimension 8.3" tablet (in mm/inch) 150/ 5.91 227.8/ 8.97 12.65/ 0.5 BEETLE /moPOS Tablet user manual... -
Page 46: Dimension 10.1" Tablet (In Mm/Inch)
Dimension 10.1" tablet (in mm/inch) 180.66/ 7.11 269/ 10.59 12.7/ 0.5 BEETLE /moPOS Tablet user manual... -
Page 47: Abbreviations
Near Field Communication RFID (Radio Frequency Identification) at 13.56 kHz Operating System Peer-to-Peer Personal Computer PEN-Leiter Protective Earth Neutral conductor Point Of Sales Pixel SDXC Secure Digital Memory Card eXtended Capacity TN-S Terre Neutre- Separé BEETLE /moPOS Tablet user manual... - Page 48 Underwriters Laboratory (standards) Universal Serial Bus Volt Association of Electrical Engineering, Electronics and Information Technology e.V. Watt WiFi Wireless Fidelity WLAN Wireless Local Area Network Wincor Nixdorf International GmbH WUXGA Wide Ultra Extended Graphics Array BEETLE /moPOS Tablet user manual...
- Page 49 Wincor Nixdorf International GmbH D-33094 Paderborn Order No. / Bestell-Nr.: 01750267872A...
