SAFETY PRECAUTIONS IMPORTANT SAFETY NOTICE Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in the Schematic Diagram and Replacement Parts List. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards.
SERVICING PRECAUTIONS CAUTION: Before servicing receivers covered by this service should be used to help reduce the incidence of component manual and its supplements and addenda, read and follow the damage caused by static by static electricity. SAFETY PRECAUTIONS on page 3 of this publication. 1.
Page 5
c. Quickly move the soldering iron tip to the junction of the Fuse and Conventional Resistor component lead and the printed circuit foil, and hold it there Removal/Replacement only until the solder flows onto and around both the 1. Clip each fuse or resistor lead at top of the circuit board hollow component lead and the foil.
NOTE : Specifications and others are subject to change without notice for improvement. 1. Application range 3. Test and Inspection method This specification is applied to AL-03HA chassis. (1) Capacity: Follow LG electronics TV Testing Standard. (2) Another Required Standard 2. Requirement for Test EMI: Following CE Standard(EN55020,EN55013)
Page 7
6.Component Video Input(Y, C Resoluton H-freq(kHz) V-freq(kHz) Pixel clock Proposed 640 x 480 15.73 60.00 SDTV. DVD 480I 704 x 480 31.47 59.94 SDTV 480P 1280 x 720 45.00 60.00 HDTV 720P 1280 x 720 44.96 59.94 HDTV 720P 1920 x 1080 33.75 60.00 HDTV 1080I...
Page 8
8.DVI Input(PC/DTV) Resoluton H-freq(kHz) V-freq(kHz) Pixel clock Proposed 640 x 350 31.468 70.09 25.17 720 x 400 31.469 70.08 28.32 720 x 400 37.927 85.03 35.50 640 x 480 31.469 59.94 25.17 VESA(VGA) 640 x 480 37.861 72.80 31.50 VESA(VGA) 640 x 480 37.500 75.00...
ADJUSTMENT INSTRUCTION 1. Scope of Application (3) EDID data for RGB of AL-03HA These specifications are applied to all LCD TV models employing an AL-03HA EDID table = chassis. 01 02 03 07 08 09 0A 0B 0C 0D 0E 0F 2.
Page 10
4.3 Adjust Color Temperature (White Balance) VPX3226 1. Contrast(MAIN) ◀ 31▶ (1) Devices Used 2. Contrast(Sub) ◀ 31▶ Color analyzer (CA-100 or equivalent) Automatic adjustment device (Necessary for automatic adjustment. Should be compatible with RS-232C communication.) AV pattern generator US 6CH US 6CH (2) Instrument Interconnection (For automatic adjustment) 3) At first adjust ‘1.
Page 11
EDID ADJUSTMENT Windows EDID V1.0 User Manual 2. EDID Read & Write 1) Run WinEDID.exe Operating System: MS Windows 98, 2000, XP Port Setup: Windows 98 => Don’t need setup Windows 2000, XP => Need to Port Setup. This program is available to LCD Monitor only. 1.
SVC REMOTE CONTROLLER FUNTION REAMARK To turn the TV on or off POWER To turn the TV on automatically if the power is supplied to the TV. (Use the POWER ON POWER key to deactivate): It should be deactivated when delivered. To activate the mute function.
TROUBLESHOOTING No Power Check the Fail condition of the power- Connect the connectors related connectors. Pass Measure standby Measure digital Fail reference voltage: voltage: 24V at Power Board 6V at D_board P810 CN304 pin no. 15 pin no. 1 Pass Replace D_power_board Measure analog Measure standby...
Page 14
No Raster Measure standby voltage: Check no. power. Replace D_board 6V at D_board P810 pin (Go to No power) Fail Pass no. 1 Pass Measure standby Check no. power. voltage: Replace A_board 6V at A_board P818 pin Fail (Go to No power) Pass no.
Page 15
No Sound Check Measure sound supply: A_power board trans output: Replace 18V at A_board P821 4V at D_power_board P815 pin D_power_board Fail Fail pin no. 3 no. 4 Pass Pass Check if A_board 18V is short-circuited: Replace A_board Resistance between A_board Fail P821 pin no.
Page 17
BLOCK DIAGRAM DESCRIPTION ATSC/NTSC tuner (TDVB-001P) can receive both terrestrial analog and terrestrial digital signals. But a NTSC tuner (6700NFNS06C) can receive terrestrial analog only. Therefore if you run two displays at the same time, it is not possible to see two digital channels. A/V SW (CXA2069) is the IC that takes external input terminal signals and broadcast signals from the tuners and handles them selectively.
REPLACEMENT PARTS LIST For Capacitor & Resistors, the CC, CX, CK, CN, CH : Ceramic RD : Carbon Film charactors at 2nd and 3rd digit in the CQ : Polyestor RS : Metal Oxide Film P/No. means as follows; CE : Electrolytic RN : Metal Film CF : Fixed Film RH : CHIP, Metal Glazed(Chip)
