HISTORY INFORMATION FOR THE FOLLOWING MANUAL:

SERVICE MANUAL

AZ3WK
CHASSIS
ORIGINAL MANUAL ISSUE DATE: 8/2012
Segment: P-2L
Version
Date
Subject
1.0
8/2012
Original manual issue.
LCD Digital Color TV
9-888-500-01
23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KLV-46EX430 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sony KLV-46EX430

Summary of Contents for Sony KLV-46EX430

  • Page 1: Service Manual

    HISTORY INFORMATION FOR THE FOLLOWING MANUAL: SERVICE MANUAL AZ3WK CHASSIS ORIGINAL MANUAL ISSUE DATE: 8/2012 Segment: P-2L Version Date Subject 8/2012 Original manual issue. LCD Digital Color TV 9-888-500-01 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
  • Page 2 SERVICE MANUAL AZ3WK CHASSIS Segment: P-2L LCD Digital Color TV 9-888-500-01 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...

  • Page 3: Model List

    MODEL LIST MODEL COLOR COMMANDER DEST. MODEL COLOR COMMANDER DEST. KLV-46EX430 Black RM-SA022 CHINA KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...

  • Page 4: Warnings And Cautions

    Components identified by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe operation. Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that are critical for safe operation are identified in this manual.
  • Page 5 警告与注意 注意 维修使用说明仅限于有资质的维修人员使用。 为降低触电的风险，请不要进行使用说明书内容以外的检修，除非你可以胜任。 警告!! 检修时请务必使用隔离变压器，以避免因机壳带电引起触电。 接收器机壳直接连接在交流电源线上。 电视机运输 务必遵循这些指导来保护你的财产和避免造成严重伤害。 • 运送电视机需要足够的人手；大尺寸的电视机需要两人或更多的人 •搬运时把手放置在正确的位置对电视机的安全及避免损坏是非常重要的。 相关安全部件警告!! 在示意图, 分解图, 和零件清单上用阴影标识的部件对安全操作很关键. 用本手册或SONY增补手册上出现零件号码的零件来替换这些部件。 无论何时，替换关键部件或出现疑似不正确操作时，都要遵循本流程。 KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...

  • Page 6: Use Caution When Handling The Lcd Panel

    Use care when handling the wires or connectors of the inverter circuit. Damaging the wires may cause a short. Protect the panel from ESD to avoid damaging the electronic circuit (C-MOS). 10) It is recommended not to exceed 1 hour of Power-On nor Burn-in period with LCD panel face down condition, in repair activity. KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
  • Page 7 警告与注意 触碰液晶显示屏时请务必小心 修理液晶显示屏时，请务必佩戴静电手环。 修理挂壁液晶显示屏时，液晶显示屏必需用后盖上的4个固定孔保护。 不要按压到液晶屏或面框边缘以避免电击风险。 不要用任何尖锐物品在液晶屏上刮擦或按压。 不要让组件长期处在高温或高湿度环境中。 不要让LCD液晶屏暴露在直射阳光中。 避免与水接触。它可能引起组件内部短路。 当更换背光灯(冷阴极荧光灯管) 或 逆变器(逆变器的高压输出会有650Vrms。)时，断开交流电源。 要经常清洁液晶屏的话请用软布材料。 当处理逆变器的线路或连接时，要小心。线路的损坏可能引起短路。 用ESD保护液晶屏以免损坏电子电路 (C-MOS)。 在维修期间，LCD 液晶屏面朝下的情况下，建议不要上电超过一小时或老化期间。 KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...

  • Page 8: Safety Check-Out

    6. Check the line cords for cracks and abrasion. Recommend the replacement of any such line cord to the customer. 7. Check the antenna terminals, metal trim, “metallized” knobs, screws, and all other exposed metal parts for AC leakage. Check leakage as described below. 8. For safety reasons, repairing the Power board and/or Inverter board is prohibited. KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
  • Page 9 安全检测 故障维修完成后，在交付给用户前必须进行下列检查： 1. 检查所维修位置是否还有为焊接或焊接不良的地方。检查整个面板表面是否存在任何焊渣或焊桥。 2. 检查板上布线，确保线路未扭绞在一起或者与高瓦特（功率）的电阻接触。 3. 检查是否需要更换所有的控制按钮，屏蔽线，外壳，接地线以及固定部件。务必保障在更换后是绝缘的。 4. 检查需要更换的部件，尤其是在以往维修时安装的电子元件。此时，须向用户说明此情况，并建议更换。 5. 查找虽在运行，但其性能已明显老化迹象的部件。此时，须向用户说明此情况，并建议更换。 6. 检查线路是否有破裂或磨损，如有则建议用户进行更换。 7. 检查天线端子、金属装饰条、镀金属的旋钮、螺丝以及所有外露的金属部件是否漏电。检查步骤参照下面说明进行。 8. 为了安全起见，禁止修复电源板与逆变器中任意一个。 KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
  • Page 10 Try both slots, if necessary, to locate the hot side on the line; the lamp should light at normal brilliance if the screw is at ground potential (see Figure B). KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
  • Page 11 安全检测 漏电检测 从任何外露金属部分到接地，以及从所有外露金属部分到其他外露部分再回到底座之间的漏电电流不得超过 0.5mA。可使用下列三种方法的任意一个去检测漏电： 1. 商用检漏仪，例如 Simpson 229 或 RCA WT540A。按照制造商的指导操作使用。 2. 电池供电的交流毫安计，可使用 Data Precision 245 数字毫安计。 3. 使用VOM（伏特-欧姆计）或电池供电的交流伏特表测量电阻器降压。“限值”为0.75V，因此模拟仪表必需具 有精确的低压刻度。Simpson 250 和 Sanwa SH-63Trd 均为无电源VOM量表，十分适用。几乎所有电池供电的 数字毫安计都具有2V的交流范围，都适用进行测量（如图A所示）。 怎样找到一个好的接地点 冷水管是一种有保证的接地设备； 交流电插座盒盖板的固位螺丝同样是接地的。 如果要把固位螺丝用来接地, 应先用欧姆表测量固位螺丝与冷水管之间的电阻，如果读数为零，证明此固位螺丝 确实是接地的。 如果冷水管不容易接近, 连接60到100瓦的检修灯(不是霓虹灯）在插座的高电位侧与固位螺丝之间。如果有必要 的话,两个插槽都试试，以确定哪边是高电位侧,。如果螺丝在接地电位上，那么在正常的情况下灯是能被点亮的 (如图B所示)。 KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...

  • Page 12: Self Diagnosis Function

    [To Bring Up Screen Test] In standby mode, press buttons on the remote commander sequentially in rapid succession as shown below: Info Channel Volume TV POWER * : Note that this differs from entering the service mode (volume +) KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
  • Page 13 如果故障超过一个以上, LED将先识别故障类别。 诊断项目的所有结果都会显示在界面上。 维修菜单名称 如果界面显示为“0”的话，则无故障出现。 闪烁次数 自诊断描述 (显示界面) MAIN_POWER 12V_电流报错 待机指示灯闪烁计数显示 无此项 无此项 TCON_ERR 液晶屏电源报错 BACKLIGHT_ERR 背光报错 无此项 无此项 无此项 无此项 无此项 无此项 自诊断界面显示 例如“有时关机”或“有时屏幕不显示”，这些无法确定的故障状态， 这些有可能之前的故障会在界面中显示出来： [跳出测试界面] 在待机的状态下，按照如下的顺序快速连续的按遥控器上的按键： 频 道 屏 显 音 量 电视电源 * : 请注意这里需要区别于进入维修模式(音量 +) KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
  • Page 14 Press the Channel 7 => Channel 0 . Exiting the Self-diagnostic screen To exit the Self Diagnostic screen, turn off the power to the TV by pressing the POWER button on the remote or the POWER button on the TV. KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
  • Page 15 • Items marked " * " are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. Note: When removing the rear cover, to prevent damaging the rear cover, please refer “APPENDIX-1”. Note: LCD panel have points installing with some tapes. About the procedure of those disassembly and assembly methods, please refer to “APPENDIX-2”. KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
  • Page 16 DISASSEMBLY AND PARTS LIST 1-1. KLV-46EX430 1-1-1. STAND REF. No. PART No. DESCRIPTION MARK 4-436-757-01 STAND (46IRS) 4-435-628-01 COVER AC (46IRS) 1-839-908-11 POWER SUPPLY CORD 4-436-756-01 REAR COVER (46IRS) 2-580-608-01 SCREW, +PSW M5X16 7-685-661-79 SCREW, +BVTP 4X12 TYPE2 IT-3 4-256-393-01...
  • Page 17 DISASSEMBLY AND PARTS LIST 1-1. KLV-46EX430 1-1-3. SWITCH UNIT, CONNECTOR, G16B BOARD AND SPEAKER REF. No. PART No. DESCRIPTION MARK 1-490-584-11 SWITCH UNIT 1-474-344-11 G16B-STATIC CONVERTER (TV) 1-910-107-09 CONNECTOR ASSY 46 PSU-INV 14P 1-910-107-12 CONNECTOR ASSY 46 LVDS 51P 1-910-107-10...
  • Page 18 DISASSEMBLY AND PARTS LIST 1-1. KLV-46EX430 1-1-4. BOTTOM FRAME, A BOARD, H BOARD AND LCD PANEL REF. No. PART No. DESCRIPTION MARK 4-435-629-01 FRAME, BOTTOM (46IRS) 1-895-306-51 MOUNTED PWB A 4-442-985-01 BRACKET, SIDE (46IRS) 1-895-170-21 MOUNTED PWB H 1-910-107-07 CONNECTOR ASSY 46 MB-IR 12P...
  • Page 19 DISASSEMBLY AND PARTS LIST 1-2. OTHER PART 1-2-1. MISCELLANEOUS PART No. DESCRIPTION MARK 1-489-995-11 REMOTE COMMANDER (RM-SA022) 4-439-497-01 LABEL, TERMINAL CH 4-294-841-01 SUPPORT POWER BOARD (SQUARE) 4-445-917-01 TAPE 140X16MM 4-448-208-01 TAPE 12X8MM KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...

  • Page 20: How To Entering Service Mode

    The flow of control Service mode on <Info><5><Vol Up><Power> Service mode off <Other> / <Power off + on> Adjustment Item up / down Data Value up / down 5) After entering service mode, then turn off the power switch. KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...

  • Page 21: Sec 3. Diagrams

    MT5306_3D Termal Sensor HeadPhone (Phone Jack) I2C Address : 0x91 IF+/- Line-out driver TUNER APA2172 Line out (RCA type) TM701 SONY RE217 RF IN 100R Tune-RE217TN I2C Address : 0xC0 CVBS STA381BWS CVBS2 & I2C Address : 0x38 Video out...

  • Page 22: Connector Diagram

    DIAGRAMS 3-2. CONNECTOR DIAGRAM LED Driver Panel (14P) (14P) CN6402 (15P) CN2001 (15P) CN6401 CN4943 (51P) Main board (4P) CN8002 Power Board CN1003 CN1004 (4P) (12P) (12P) IR board CN9101 (51P) Panel T-CON Board KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...

  • Page 23: Circuit Boards Location

    DIAGRAMS 3-3. CIRCUIT BOARDS LOCATION G16B Board A Board Switch Unit H Board KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
  • Page 24 English 2012HL08-Data Sony Corporation Made in Japan Home Entertainment & Sound © 2012. 08 9-888-500-01 Business Group KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...

  • Page 25: Procedure To Removal Of Rear Cover

    Be careful not give damage to AC code. 3. Remove the AC code from TV set. 4. Remove the Rear Cover until side-hook unlocks. 5. Open the Rear Cover as below photo showing. And remove it from TV-set completely. Pull KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
  • Page 26 附录-1 后盖拆卸流程 1. 拆卸所有的螺丝以便移除后盖。 2.使用螺丝起或者其他工具来移除电源后盖板。 小心，不要损坏电源盖。 3. 把电源盖从电视机上移除。 4. 移开后盖直至侧边锁扣解锁。 5. 如图所示把后盖打开，并彻底从电视机上移开。 推拉 KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...

  • Page 27: Procedure To Assemble Of Rear Cover

    1. Put the Rear Cover as below photo showing. And assemble it to TV-set completely. 2. Press the Rear Cover as below photo showing. And make the Hook to lock with Bezel completely. Press Press Press Press Press KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
  • Page 28 附录 后盖装配流程 注意: 在盖上后盖时, 为了预防EMI干扰, 必须确保 FFC线与背面机架要有缓冲垫垫着。 FFC 线的其他部分（ 例如：折角处也不可以与背面机架接触）。 FFC 线（扁平线） 缓冲垫子 背面机架 1. 如图所示安放后盖，使它完全安装到电视机机体上去。 2. 如图所示按压后盖，使锁扣完全与面框锁紧。 按压 按压 按压 按压 按压 KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...

  • Page 29: Hook Position Of Rear Cover

    Notice for re-assemble Rear Cover Press Hook area of Rear Cover until locking sound can be heard. And check that Rear Cover has locked to Bezel by your eye. (refer to photo) After that, screw up for Rear Cover fixing. KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
  • Page 30 附录 后盖上的锁扣位置 重新盖上后盖时请注意 按压后盖的锁扣区域直至听到锁扣锁紧的声音。 然后用眼睛检查后盖与面框之间是否被锁扣好. (请参考下面图片) 之后，旋紧螺丝固定好后盖。 KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...

  • Page 31: Panel Tape Sticking And Parts Number

    Note: The parts (SUPPORT POWER BOARD) which stuck the himeron tape are used for the mass-production TV. However, When this SUPPORT POWER BOARD replacement is needed at service, since a himeron tape is unnecessary, please use 4-294-841-01 SUPPORT POWER BOARD (SQUARE) instead. KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
  • Page 32 附录-2 液晶屏胶带与零件编号 1.0±1.0mm 黑色聚酯薄膜胶带 40.73Z30.001 (60*25MM) 导电胶带 42.3XC24.001 (50*30MM) 1.0±1.0mm Himeron 胶带 Himeron 胶带 38.04AG1.001 (10*5*0.5MM) ＜装配件＞ 电源板支架 Himeron 胶带 38.04AEP.001 (140*16*0.25MM) 4-445-917-01 (胶带 140X16MM) 4-294-841-01 电源板支架(方形) 注意: 这部分 (电源板支架) himeron 胶带用于大规模电视机生产. 无论如何, 在替换电源板支架服务时，更换himeron 胶带是不必要的，请使用4-294-841-01零件来替换电源板支架(方形)。 KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
  • Page 33 APPENDIX-2 PANEL TAPE STICKING AND PARTS NUMBER Himeron Tape 38.04AGA.001 (12*8*1MM) × 5pcs Sony Part No. ： 4-448-208-01(TAPE 12X8MM) 0±1 0±1 Top View KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
  • Page 34 附录 液晶屏胶带与零件编号 Himeron 胶带 38.04AGA.001 (12*8*1MM) × 5pcs Sony 零件编号 ： 4-448-208-01(胶带 12X8MM) 0±1 0±1 顶视图 KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...

  • Page 35: Software Data Update

    APPENDIX-3 SOFTWARE DATA UPDATE THE CONFIRMATION OF THE SOFTWARE VERSION OF THE TV SET 1. Model Name Entering product information of setting menu. 1: KLV-46EX430 2. Serial Number Please use the latest software. 2: 0123450 3. Software Version 3: 6.01.010 [HOME] - [Settings] - [Set-up] - [Product Information] Note: When change Main board, 1 and 2 are not displayed.
  • Page 36 4. Plug the AC power cord then start update automatically. Product information of setting menu. [HOME] - [Settings] - [Set-up] - [Product Information] Lights up Green LED. (no picture) Starting update Light up Red LED and Orange LED was flushing. (1-2min) KLV-46EX430(CH) 23AA9ABD4CBEDEA91407506AB84FAEA8217AB167621A915CC7A3BAEEA15A0AEE6705885A70374EDB...
