Sony JE81352 User Manual

Dps super wide dynamic camera.
Hide thumbs
DPS Super Wide Dynamic Camera
User Manual
Super WDR High Resolution Color Camera
Super WDR High Resolution Day&Night Camera

Advertising

   Related Manuals for Sony JE81352

No related manuals

   Summary of Contents for Sony JE81352

  • Page 1

    DPS Super Wide Dynamic Camera User Manual Super WDR High Resolution Color Camera Super WDR High Resolution Day&Night Camera...

  • Page 2: Table Of Contents

    Content Content Safe Warnings Notice Introduction of WDR Function Character System Functions Connecting Example Back Panel Instruction Main Camera Function Settings Menu Tree Basic Operations Menu Instruction Production Specifications Remove Common Troubles...

  • Page 3: Notice

    Warning To prevent fire or shock hazard,do not expose the unit to rain or moisture. The symbol is intended to alert the user to the presence of important operating and maintenance(servicing)instructions in the literature accompanying the appliance. The symbol is intended to alert the user to the presence of uninsulated"dangerous voltage"within the product's enclosure that may be of sufficient magnitude to result in...

  • Page 4: Introduction Of Wdr

    Introduction of WDR Introduction of WDR Compared with common cameras, WDR (Wide Dynamic Rang) can revert to filmed image more correctly. If the filmed region has a large contrast, stronger bright covers a large area of filmed region, common camera's electronic shutter will work in a higher speed after lighting, at the same time, dark region will be darker, even black, on the contrary, If the dark covers a larger area, common cameras' electronic...

  • Page 5

    Introduction of WDR Common camera Common camera BLC OFF BLC ON WDR CAMERA Above features of WDR camera can be more suitable for the using of some environment has large brightness contrast, such as ATM automated teller machine, the entrance of the building, wharf, etc.

  • Page 6: Function Character

    Function Characters Function Characters 1.Super Wide Dynamic Range, up to 120dB. 2. Taking advanced DPS camera technique needs much less storage capability of DVR than CCD camera. 3. Be more convenient for users to operate with English and Chinese OSD menu. 4.

  • Page 7

    System Function 4. Power supply indicator light (LED) When the power supplies normally, power indicator light will light up. 5. Automatic IRIS lens interface (AUTO IRIS) Plug AUTO IRIS lens wire If the cable is thick or the plug SIGNAL cover does not fit DAMP- DAMP+...

  • Page 8: Connecting Example

    Connecting Example Connecting Example 1 The way of single camera connecting. Monitor Camera Video Coaxial Cable 2 The way of Muli-camera connecting. Video Sequential Switching * Make sure power off before comecting.

  • Page 9: Back Panel Instruction

    Back Panel Instruction Back Panel Instruction (1) Key-press Upward selection push-button to move the menu. DOWN Downward selection push-button to move the menu. LEFT Leftward selection push-button to select menu. RIGHT Rightward selection push-button to select menu. MENU Menu functional Key-press. Video output port (BNC VIDEO OUT) Power supply input port Power supply indicator light (LED)

  • Page 10: Main Camera Function Settings

    Main Camera Function Settings Main Camera Function Settings : WDR camera has 4 optional models : common indoor outdoor user-defined (Details of the reference manual 1.1) ; Also can select region to be optimized (Details of the reference manual 4.3). Video format (MENU->BASIC SETUP->VIDEO FORMAT), Set signal system as PAL or NTSC.

  • Page 11

    Menu Tree BASIC SETUP 3.1VIDEO STANDARD NTSC AI THRESH AI THRESH 3.2LENS SELECT DC GAIN MANUAL DC GAIN WDR CAMERA AI THRESH WDR MODE 3.3AGC MEDIUM NORMAL HIGH INDOOR OUTDOOR 3.4SHUTTER LIMIT OFF/X2/X4/X8/X16/X32 CUSTOM LINELOCK IMAGE ADJUST 3.5SYNC V PHASE INTERNAL BASIC SETUP LINELOCK...

  • Page 12: Basic Operations

    Basic Operation Basic Operation MENU tree totally include : MENU UP DOWN LEFT RIGHT five key-press, Hold MENU key three seconds to enter MENU SETUP. The MENU with " " express having submenu. The MENU with "." express can be operated but no submenu, Press EXIT key to exit MENU, Hold MENU key three seconds to exit menu.

  • Page 13

    Menu Instruction environment, when the effects of using ATW or AWB are not well, choose manual white balance to select an appropriate mode. When the color temperature environment is stable, and then can select the color temperature mode to adjust color temperature value. If the overall environment is fixed-tone, red and blue patterns can be selected and adjust the value of red and blue color temperature excursion.

  • Page 14

    Menu instruction enter DC lens adjustment to adjust Auto aperture gain . and adjust AUTO gain to start level control the camera correct action. 3.3 AGC AGC can be defined as low, medium, and high. 3.4 SHUTTER LIMIT Shutter limit function also is used in low-light; improve the image brightness through sacrificing the speed of image response in low-light environment.

  • Page 15

    Menu Instruction green pane can enlarge region, red pane to narrow region, Hold MENU key three seconds to return last menu. 4.4 RESTORE FACTORY SETTINGS Restore factory default value. 5.1 SAVE /EXIT Save: Save users' settings, and exit MENU; EXTE: Exit Menu without saved;...

  • Page 16

    Product Specifications Product Specifications Image Sensor 1/3" Pixim Orca,DPS Signal System PAL/NTSC Compatible PAL:720 540 NTSC:720 540 Effective Pixels Color: 540 TV lines Black&White: 570 TV lines (level) Resolution 0.5 Lux F1.2;0.08 Lux/F1.2 (32X slow shutter) Min.illumination S/N Ratio > 48 dB Dynamic Range 101 dB (Typical Value), 120 dB (Max Value) Control Mode...

  • Page 17: Remove Common Troubles

    ² ú Æ · ¹ æ ¸ ñ Remove Common Troubles Remove Common Troubles Remove ways Number Trouble Causation No power supply Plug power No picture Power supply not well Chang power supply Video line is not No picture Connect video line connected Check the lens or image sensor whether be...
