- Page 1 U s e r ’s m a n u a l NVIP-TC5401C/MPX2.0 NVIP-TC5400C NVIP-TC2400D/MPX1.3-II NVIP-TDN3400H/IR-3...
- Page 2 NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. IMPORTA T SAFEGUARDS A D WAR I GS EMC (2004/108/EC) and LVD (2006/95/EC ) Directives CE Marking Our products are manufactured to comply with requirements of the following directives and national regulations implementing the directives: •...
- Page 3 NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. IMPORTA T SAFEGUARDS A D WAR I GS WAR I G! THE KNOWLEDGE OF THIS MANUAL IS AN INDESPENSIBLE CONDITION OF A PROPER DEVICE OPERATION. YOU ARE KINDLY REQUSTED TO FAMILIRIZE YOURSELF WITH THE MANUAL PRIOR TO INSTALLATION AND FURTHER DEVICE OPERATION.
-
Page 4: Table Of Contents
IP setting ....................24 b. DDNS ....................... 25 4.2.3. A/V setting ....................26 a. Image setting ..................... 26 b. Video setting ..................... 27 c. Audio setting (NVIP-TC5400C, NVIP-TC5401C/MPX2.0) ....28 All rights reserved © AAT Holding sp. z o.o. - Page 5 NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. TABLE OF CO TE TS 4.2.4. Event setting ....................29 a. Event setting ..................... 29 b. Schedule setting ..................31 c. I/O setting( NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0) ................32 d. Mail & FTP ....................33 e.
-
Page 6: Foreword I Formatio
(avi) or image file (jpeg) on SD card * Schedule • Network protocol: HTTP, TCP/ IP, UDP, FTP, DHCP, DDNS, NTP, 3GPP, RTSP, UPnP • Software: NMS (NOVUS MANAGEMENT SYSTEM) for video recording, live monitoring, • playback and remote IP device administration Power over ethernet support * •... -
Page 7: Nvip-Tc5401C/Mpx2.0 Specification
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. FOREWORD I FORMATIO 1.2. VIP-TC5401C/MPX2.0 specification Model NVIP-TC5401C/MPX2.0 Pick-up Element 1/3” CMOS imager Imager Resolution 2.0 megapixels Min. Illumination 0.5 lx/F=1.4 Electronic Shutter Auto (AES) Digital Slow Shutter (DSS) 0.03 ~ 0.2 s... -
Page 8: Nvip-Tc5400C Specification
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. FOREWORD I FORMATIO 1.3. Specification VIP-TC5400C Model Color Classic Camera NVIP-TC5400C Pick-up Element CCD imager, 1/3” Horizontal Resolution 540TLV Min. Illumination 0.1 lx/F=1.2 Electronic Shutter Auto/Manual Auto Gain Control (AGC) On/Off White Balance... -
Page 9: Nvip-Tdn3400H/Ir-3 Specification
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. FOREWORD I FORMATIO 1.4. Specification VIP-TD 3400H/IR-3 Model Day/Night Bullet Camera NVIP-TDN3400H/IR-3 Pick-up Element CCD imager, 1/3” Horizontal Resolution 540TLV Min. Illumination 0lx (IR on) Electronic Shutter Auto:1/50s~1/100000 White Balance Auto Day/Night switching... -
Page 10: Nvip-Tc2400D/Mpx1.3-Ii Specification
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. FOREWORD I FORMATIO 1.5. Specification VIP-TC2400D/MPX1.3-II Model Color Dome Camera NVIP-TC2400D/MPX1.3-II Pick-up Element CMOS imager, 1/4” Pick-up Element Resolution 1.3 Megapixels Min. Illumination 1.5 lx/F=1.4 Electronic Shutter Auto Digital Slow Shutter (DSS) 0.03-0.3s... -
Page 11: Package Contents
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. FOREWORD I FORMATIO 1.6. Package contents After you open the package make sure that the following elements are inside: IP camera • Power supply adaptor 230 VAC / 12 VDC* • Bag with accessory kit •... -
Page 12: Start-Up A D I Itial Ip Camera Co Figuratio
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. START-UP A D I ITIAL CAMERA CO FIGURATIO 2. START-UP A D I ITIAL IP CAMERA CO FIGURATIO 2.1. Description of most important electric connectors and adjustment elements VIP-TC2400D/MPX1.3-II camera VIP-TC5400C camera VIP-TC5401C/MPX2.0 camera... -
Page 13: Lens Mount
2.3. Starting up of IP camera To run NOVUS IP camera you have to connect it directly to the power supply or by using power supply adapter. Next, connect the Ethernet cable between the PC or network switch and IP cameras. -
Page 14: Parameters Configuration By Using Web Browser
PC computer You can set network configuration (IP address, gateway, net mask, etc.) of NOVUS IP camera or select DHCP mode (DHCP server is required in this method in target network) by using web browser or by NMS software. -
Page 15: Etwork Co Ectio Utilizi G Web Broswer
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. ETWORK CO ECTIO UTILIZI G WEB BROSWER 3. ETWORK CO ECTIO UTILIZI G WEB BROSWER 3.1. Recommended PC configuration for web browser connections The below requirements apply to connection with an IP camera with smooth image display in 720x576 resolution and at speed of 25 fps. - Page 16 NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. ETWORK CO ECTIO UTILIZI G WEB BROSWER When you log on to the camera, web browser will download the applet for displaying images from the camera. Depending on the current Internet Explorer security settings it may be necessary to accept an ActiveX control.
-
Page 17: Camera Network Connection Utilizing Mozilla Firefox
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. ETWORK CO ECTIO UTILIZI G WEB BROSWER 3.3. Camera network connection utilizing Mozilla Firefox It is also possible to connect to the camera by using Mozilla Firefox, but this browser doesn't offer full functionality of the camera, so the recommended browser is Internet Explorer. - Page 18 NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. ETWORK CO ECTIO UTILIZI G WEB BROSWER Select Run Then you can see a window confirming the installation of necessary components. After properly installing the necessary components in the browser window you should see image from the camera...
-
Page 19: Www I Terface- How To Work With Ip Camera
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. CAMERA WWW I TERFACE 4. WWW I TERFACE- HOW TO WORK WITH IP CAMERA 4.1. Video images displayed in live view. 7.Alarm 8. OSD. 2.Outputs 3.Online 1. Streaming 6.Setup 4.Speaker connection selection 5.Snapshoot... -
Page 20: Camera Configuration
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. CAMERA WWW I TERFACE Right mouse button click on the live screen view allows to use the following functions: 1.Snapshot - save the current frame in JPEG format 2.Record start/record stop - run or stop video recording with sound to local disc 3.Mute - disable sound from camera (if available) -
Page 21: System Settings
System information - Set up the camera name, select language, and set up the camera time. • Server name - this name will be shown on the NMS device and the web page • Camera model - information on the camera model (NVIP-TC5401C/MPX2.0) • MAC Address - information about MAC address of a device •... -
Page 22: Users Management
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. CAMERA WWW I TERFACE b. User management - tab for setting up users parameters, add new one or delete existing. • Anonymous user login - allows anyone to watch live view of camera. -
Page 23: System Update
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. CAMERA WWW I TERFACE c. System update - tab for upgrading firmware, save, restore and set default camera setting. • Firmware upgrade - function to upgrade new firmware. To update the firmware online, click BROWSE button and select new f/w file with „bin” extension. -
Page 24: Network
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. CAMERA WWW I TERFACE 4.2.2. etwork a. IP setting - table containing IP configuration and camera ports. • IP assignment - option to choose DHCP server or set IP address and other parameters manual. -
Page 25: Ddns
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. CAMERA WWW I TERFACE b. DD S - tab for setting parameters of Dynamic DNS service DDNS Configuration - allows you to run DDNS. This service allows you to locate a device in the Internet by calling the registered domain. -
Page 26: A/V Setting
4.2.3. A/V setting a. Image setting - tab with camera picture settings. • Privacy zones (NVIP-TC5401C/MPX2.0) - three independent privacy zones are available. To set them up, please select a button corresponding to a particular zone, and mark the area while pressing right mouse button. -
Page 27: Video Setting
• Image sensor resolution - selects maximum resolution of the sensor (NVIP-TC5401C/MPX2.0) • Video system - switches between video systems (PAL/NTSC) (NVIP-TC2400D/MPX1.3-II, NVIP- TC5401C/MPX2.0) • Video output settings - selects video system on the analog output (NVIP-TC5401C/MPX2.0) • Basic mode - suggested for beginners. − Resolution −... -
Page 28: Audio Setting (Nvip-Tc5400C, Nvip-Tc5401C/Mpx2.0)
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. CAMERA WWW I TERFACE • Advanced mode - allows for precise setting up of camera parameters. It is an extension of the basic mode. The following options are added: − Bitrate Control Mode - CBR constant bit rate, VBR variable bit rate −... -
Page 29: Event Setting
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. CAMERA WWW I TERFACE 4.2.4. Event setting a. Event setting - configuration of motion detection and network events Motion detection - allows you to define three motion detection areas with each area featuring •... - Page 30 NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. CAMERA WWW I TERFACE • Record file - selects type of file that will be saved in case of alarm − Avi - video recording (with sound, when active) whose length is a sum of pre and post alarm recording durations −...
-
Page 31: Schedule Setting
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. CAMERA WWW I TERFACE Information: SD card option is available in VIP-TC2400D/MPX1.3-II, VIP-TC5400C IP, VIP-TC5401C/ MPX2.0 cameras. I/O option is available in VIP-TD 3400H/IR-3, VIP-TC5400C IP, VIP-TC5401C/MPX2.0 cameras. b. Schedule setting • Schedule setting - defines the time when camera reacts to alarm input signals and motion detection. -
Page 32: Nvip-Tc5401C/Mpx2.0)
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. CAMERA WWW I TERFACE c. I/O setting ( VIP-TD 3400H/IR-3, VIP-TC5400C, VIP-TC5401C/MPX2.0) • Input setting − Input sensor - NO or NC type − Input action - E-mail message with an attachment, sending a file to FTP server, activating the output, saving a file to SD card (file type is selected in EVE T SETTI G tab) −... -
Page 33: Mail & Ftp
− Path - a specific folder on FTP server to save a files − Operating mode - passive or via port (NVIP-TC5401C/MPX2.0) − Day folder - creates separate folders for each day (NVIP-TC5401C/MPX2.0) All rights reserved © AAT Holding sp. z o.o. -
Page 34: Log List
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. CAMERA WWW I TERFACE e. Log list • System logs • Motion detection logs • I/O logs ( VIP-TD 3400H/IR-3, VIP-TC5400C, VIP-TC5401C/MPX2.0) • All logs All events are described by time and date. User Login is additionally described by the IP address of actual users computer. -
Page 35: Electric Co Ectors A D Co Ectio S
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. ELECTRIC CO ECTORS A D CO ECTIO S 5. ELECTRIC CO ECTORS A D CO ECTIO S 5.1. Description of electric connectors and adjustment elements VIP-TC5400C & VIP-TC5401C/MPX2.0 Electric connectors of camera: 1.SD card socket... - Page 36 NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. ELECTRIC CO ECTORS A D CO ECTIO S VIP-TD 3400H/IR-3 Electric connectors of camera 1. Ethernet port 100 Mb/s - RJ45 socket 2. I/O alarm interface 3. Analogue video output - BNC 4.
-
Page 37: Alarm Input And Output Electric Connections (Tdn3400H/Ir-3, Nvip-Tc5400C, Nvip-Tc5401C/Mpx2.0)
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. ELECTRIC CO ECTORS A D CO ECTIO S VIP-TC2400D/MPX1.3-II Electric connectors of camera 1.Ethernet port 100 Mb/s - RJ45 socket 2.Power terminal 12VDC 3.SD card socket 5.2. Alarm input and output electric connections ( VIP-TD 3400H/IR-3, VIP-TC5400C, VIP-TC5401C/MPX2.0) -
Page 38: Sd Card Installation (Nvip-Tc2400D/Mpx1.3-Ii, Nvip-Tc5400C, Nvip-Tc5401C/Mpx2.0)
NVIP-TC2400D/MPX1.3-II, NVIP-TDN3400H/IR-3, NVIP-TC5400C, NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. ELECTRIC CO ECTORS A D CO ECTIO S 5.3. SD card installation ( VIP-TC2400D/MPX1.3-II, VIP-TC5400C, VIP-TC5401C/ MPX2.0). The camera supports SD and SDHC cards. To properly install the SD card, follow the instructions: •... -
Page 39: Default Setti Gs Ip Camera
NVIP-TC5401C/MPX2.0 - User’s Manual ver.1.3. DEFAULT IP CAMERA SETTI G 6. DEFAULT IP CAMERA SETTI GS NOVUS IP cameras have a software (via browser) and hardware (when pressing reset button) option to restore factory settings. 6.1. Factory software default Factory software default causes restoration of all default settings of the IP camera apart from network settings. - Page 40 AAT Holding sp. z o.o., 431 Pulawska St., 02-801 Warsaw, Poland tel.: +4822 546 07 00, fax: +4822 546 07 59 2011-04-15 AN AG...
