Chapter 1 1.1 Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. What the warranty does not cover ■ Any product, on which the serial number has been defaced, modifi ed or removed. ■...
Chapter 1 1.2 Regulatory Notice Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without no- tice.
It is very important to locate the Rackmount LCD Drawer / Display in a suitable environment. ■ The surface for placing and fi xing the Rackmount LCD Drawer / Display should be stable and level or mounted into a suitable cabinet.
Chapter 2 2.1 Package Contents RP-W719 & RP-W822 Rackmount LCD display x 1 pc User manual x 1 pc 6’ VGA cable (male to male) x 1 pc Power cord x 1 pc Auto switch power adapter x 1 pc M3.2*4.5mm screw x 4 pcs...
Chapter 2 2.3 Installation RP-W719 ■ Install each screw shown in Figure 1. Figure 1. ■ Fix the LCD into the rack. * M6 screws are not provided. Figure 2.
Page 11
Chapter 2 2.3 Installation RP-W822 Figure 3. Figure 4. ■ ■ Install each screw shown in Figure 3. Insert the upper part of the LCD display to the rack shown in Figure 4. * M6 screws are not provided. Figure 5.
KVM and Rackmount LCD Drawer. Before attempting to connect anything to the Rackmount LCD Drawer, we suggest turning off power to all devices before connecting them. Apply power to connected devices again only after the Rackmount LCD Drawer is receiving power.
Chapter 3 3.1 Package Contents RP-W119 LCD drawer x 1 pc 6’ VGA cable (male to male) x 1 pc User manual x 1 pc Power cord x 1 pc Mounting bracket x 2 pcs M6*15mm screw x 8 pcs M6 cage nut x 6 pcs Cup washer x 8 pcs P.10...
Chapter 3 3.3 How to Install "One Man" Installation Slides Install into rack Rear side Right bracket ■ Attach the left and right mounting bracket to rack 19” mounting rails. ■ Adjust the rear mouting bracket to fi t your rack. ■...
Chapter 3 3.3 How to Install "One Man" Installation Slides ■ Attach front left and right mounting ears of the LCD drawer to vertical mounting rails. ■ M6 screw and cup washer x 2 pcs included. Complete the installation ■ Tighten all 8 pcs of M6 screw to complete the installation.
Chapter 3 3.4 How to Use the Slides RP-W119 ■ A black arrow release button is located on the outside of each slide. (shown in Figure 7). Figure 7. ■ Pull and hold the black arrow button on either side of the LCD drawer to unlock. (shown in Figure 8).
KVM and Rackmount LCD Drawer. Before attempting to connect anything to the Rackmount LCD Drawer, we suggest turning off power to all devices before connecting them. Apply power to connected devices again only after the Rackmount LCD Drawer is receiving power.
Chapter 4 4.1 On-screen Display Operation RP-W719 & RP-W822 LCD membrane RP-W119 LCD membrane Membrane Switch Function Power light Green = On Orange = Power saving Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control...
Chapter 4 4.2 On-screen Menu RP-W719, RP-W822 & RP-W119 OSD Confi guration Page Image: To enter into the brightness, contrast, color temp, red, green, and blue Geometry: To enter into the auto adjust, H position, V position, phase and clock...
Chapter 5 5.3 Audio Option RP-W719 & RP-W822 Speaker Audio Power RP-W119 Speaker Power Audio Remarks: ■ Audio input is 35mm audio plug ■ The speaker is sharing the same power with LCD. P.20...
Chapter 5 5.5 Front NEMA 4 / IP65 Option RP-W719 & RP-W822 Rear case LCD panel 4mm protective glass (Front NEMA 4 / IP65 protection) Aluminum front panel Remarks ■ 4mm thickness of protective glass is not toughened one, please handle it carefully.
Chapter 5 5.6 Quad Display Option Specifi cations Video IN 1 ~ 4 RS-232 VCR in Video Loop Alarm I/O VCR out AV BNC VGA Power 1 ~ 4 Item Description Model Number QD (NTSC) QD (PAL) Number of Color 16.7 M 16.7 M Imaging System...
Chapter 5 5.7 DC Power Options RP-W719 & RP-W822 DC Power input RP-W119 DC Power input Model Input rating Input voltage: 12-Volt 24-Volt 48-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V Input current - No load...
Chapter 6 6.1 Package Contents RP-615, RP-717, RP-819 & RP-920 SP-717, SP-819 & SP-920 Rackmount LCD display x 1 pc User manual x 1 pc 6’ VGA cable (male to male) x 1 pc Power cord x 1 pc Auto switch power adapter x 1 pc M3.2*4.5mm screw x 4 pcs...
Chapter 6 6.3 Installation RP-920 & SP-920 ■ Install each screw shown in Figure 12. Figure 12. ■ Fix the LCD into the rack. * M6 screws are not provided. Figure 13. P.29...
KVM and Rackmount LCD Drawer. Before attempting to connect anything to the Rackmount LCD Drawer, we suggest turning off power to all devices before connecting them. Apply power to connected devices again only after the Rackmount LCD Drawer is receiving power.
Chapter 7 7.1 Package Contents RP-120 & SP-120 RP-115, RP-117, RP-119, SP-117 & SP-119 RP-1415, RP-1417 & RP-1419 LCD drawer x 1 pc 6’ VGA cable (male to male) x 1 pc User manual x 1 pc Auto switch power adapter ( for external power version) x 1 pc Power cord x 1 pc Mounting bracket x 2 pcs M6*15mm screw x 8 pcs...
Chapter 7 7.3 How to Install "One Man" Installation Slides Install into rack Rear side Right bracket ■ Attach the left and right mounting bracket to rack 19” mounting rails. ■ Adjust the rear mouting bracket to fi t your rack. ■...
Page 37
Chapter 7 7.3 How to Install "One Man" Installation Slides ■ Attach front left and right mounting ears of the LCD keyboard drawer to vertical mounting rails. ■ M6 screw and cup washer x 2 pcs included. Complete the installation ■...
Chapter 7 7.4 How to Use the Slides RP-120 & SP-120 RP-115, RP-117, RP-119, SP-117 & SP-119 RP-1415, RP-1417 & RP-1419 ■ A black arrow release button is located on the outside of each slide. (shown in Figure 14). Figure 14. ■...
KVM and Rackmount LCD Drawer. Before attempting to connect anything to the Rackmount LCD Drawer, we suggest that turn off power to all devices be- fore connecting them. Apply power to connected devices again only after the Rackmount LCD Drawer receiving power.
Chapter 8 8.1 On-screen Display Operation RP-120 & SP-120 RP-115, RP-117, RP-119, SP-117 & SP-119 RP-1415, RP-1417 & RP-1419 15" LCD membrane 17", 19" & 20" LCD membrane Power light Green = On Orange = Power saving Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button...
Chapter 8 8.2 On-screen Menu RP-120 & SP-120 RP-115, RP-117, RP-119, SP-117 & SP-119 RP-1415, RP-1417 & RP-1419 OSD Confi guration Page Image: To enter into the brightness, contrast, color temp, red, green, and blue Geometry: To enter into the auto adjust, H position, V position, phase and clock Video: To enter into the colour, tint, sharpness, noise reduction, DCDi and...
Chapter 9 9.3 Audio Option RP-615, RP-717, RP-819 & RP-920 Speaker Audio Power Remarks ■ Audio input is 35mm audio plug ■ The speaker is sharing the same power with LCD. P.41...
Page 45
Chapter 9 9.3 Audio Option RP-120 RP-115, RP-117 & RP-119 RP-1415, RP-1417 & RP-1419 Speaker Internal power version Power Audio External power version ( For short depth version - RP-1415 / 1417 / 1419 ) Remarks: ■ Audio input is 35mm audio plug ■...
Chapter 9 9.4 Touchscreen Options RP-615, RP-717, RP-819 & RP-920 USB interface Power Serial interface Serial Power RP-120 RP-115, RP-117 & RP-119 RP-1415, RP-1417 & RP-1419 USB interface Power Internal power version ( For short depth version - RP-1415 / 1417 / 1419 ) External power version Serial interface Power...
Chapter 9 9.6 Quad Display Option Specifi cations Video IN 1 ~ 4 RS-232 VCR in Video Loop Alarm I/O VCR out AV BNC VGA Power 1 ~ 4 Item Description Model Number QD (NTSC) QD (PAL) Number of Color 16.7 M 16.7 M Imaging System...
Chapter 11 11.1 Troubleshooting 1. How do I adjust the resolution? To change monitor resolution, click Start -> Control Panel -> Display. Select Setting tab to adjust the monitor resolution in Desktop Area. The available resolutions, "640 x 480", "800 x 600", "1024 x 768", "1152 x 864", "1280 x 1024", are deter- mined by the display card in your computer.
Chapter 12 12.1 Dimensions RP-W719, RP-W822 & RP-W119 RP-615, RP-717, RP-819 & RP-920 SP-717, SP-819 & SP-920 Product Dimension Packing Dimension Gross Model Net Weight (W x D x H) (W x D x H) Weight 480 x 57.5 mm...
Chapter 12 12.1 Dimensions RP-120 SP-120 RP-115, RP-117, RP-119 SP-117 & SP-119 RP-1415, RP-1417 & RP-1419 Product Dimension Packing Dimension Gross Model Net Weight (W x D x H) (W x D x H) Weight 442 x 650 x 44 mm 581 x 755 x 172 mm 14 kg 19 kg...
