Chapter 1 Getting Started Important Safeguards...1 Regulatory Notice...2 Before Installation...3 Unpacking...3 Optional Accessories...3 Peripheral Products...4 Part 1 Widescreen LCD Quad Display Chapter 2 RP-W922QD & RP-W819QD Package Contents...5 Structure Diagram...6 Installation...7-8 Connection...9 Chapter 3 RP-W119QD Package Contents...10 Structure Diagram...11 How to Use the Slides...12 Connection...13 Chapter 4 LCD Specifi... - Page 3 Part 2 4:3 LCD Quad Display Chapter 6 RP-817QD, RP-919QD & RP-1020QD Chapter 7 RP-117QD, RP-119QD & RP-120QD Chapter 8 LCD Specifi cation Chapter 9 Dimensions Chapter 10 Operation 10.1 10.2 Chapter 11 Quad Operation 11.1 11.2 11.3 11.4 11.5 11.6 11.7 Chapter 12 Options...
- Page 4 Blank page P.41...
-
Page 5: Part
1.1 Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. What the warranty does not cover ■ Any product, on which the serial number has been defaced, modifi ed or removed. ■... -
Page 6: Regulatory Notice
1.2 Regulatory Notice Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without no- tice. -
Page 7: Before Installation
1.3 Before Installation ■ It is very important to locate the Rackmount LCD Drawer / Display in a suitable environment. ■ The surface for placing and fi xing the Rackmount LCD Drawer / Display should be stable and level or mounted into a suitable cabinet. -
Page 8: Peripheral Products
1.6 Peripheral Products Item Model No. MU-1602 / MU-1603 / MU-1604 MU-IP1613 / MU-IP1614 / MU-IP1624 Matrix Cat6 KVM MU-3202 / MU-3203 / MU-3204 MU-IP3213 / MU-IP3214 / MU-IP3224 M-802 / M-803 / M-804 M-IP813 / M-IP814 / M-IP824 Matrix DB-15 KVM M-1602 / M-1603 / M-1604 M-IP1613 / M-IP1614 / M-IP1624 U-801 / U-802 / U-IP802... -
Page 9: Package Contents
2.1 Package Contents RP-W819QD & RP-W922QD tr o > < p la D is Rackmount LCD display x 1 pc 6' VGA cable (male to male) x 1 pc User manual x 1 pc Power cord x 1 pc Auto switch power adapter x 1 pc Chapter 2... -
Page 10: Structure Diagram
2.2 Structure Diagram RP-W819QD & RP-W922QD Front view tr o > < p la D is S et LCD interchangeable module kit 2-in-1 LCD + Quad display membrane Power adapter bracket Rear view Chapter 2 Power adapter Power cord... -
Page 11: Installation
2.3 Installation RP-W819QD tr o > < p la D is tu p Figure 1. tr o > < p la D is tu p Figure 2. ■ ■ Chapter 2 Install each screws shown in Figure 1. Fixed the LCD into the rack. * M6 screws is not provided. -
Page 12: Installation
2.3 Installation RP-W922QD Figure 3. ■ Install each screws shown in Figure 3. * M6 screws is not provided. Figure 5. ■ Push the lower part of the LCD into the rack. Figure 4. ■ Insert the upper part of the LCD display to the rack shown in Figure 4. -
Page 13: Connection
Chapter 2 2.4 Connection RP-W819QD & RP-W922QD Video IN 1 ~ 4 RS-232 VCR in Video Loop Alarm I/O VCR out AV BNC VGA Power 1 ~ 4 ■ Please refer to P.27 - 39 The Rackmount LCD Drawer & Display are hot-pluggable, but components of Caution : connected devices, such as the servers and KVM switch, may not be hot-pluggable. -
Page 14: Chapter 3 Rp-W119Qd
3.1 Package Contents RP-W119QD LCD drawer x 1 pc 6’ VGA cable (male to male) x 1 pc User manual x 1 pc Power cord x 1 pc Mounting bracket x 2 pcs M6*15mm screw x 8 pcs M6 cage nut x 8 pcs M6 washer x 8 pcs M en >... -
Page 15: Structure Diagram
3.2 Structure Diagram RP-W119QD LCD interchangeable module kit “One Man” Installation Slides LCD + Quad display membrane Thumb Screw P.11 Chapter 3... -
Page 16: How To Use The Slides
3.3 How to Use the Slides RP-W119QD Figure 7. Figure 8. Figure 9. ■ A black arrow release button is located on the outside of each slide. (shown in Figure 7). ■ Pull and hold the black arrow button on either side of the LCD drawer to unlock. -
Page 17: Connection
3.4 Connection RP-W119QD RS-232 VCR in Alarm I/O VCR out ■ Please refer to P.28 - 40 The Rackmount LCD Drawer & Display are hot-pluggable, but components of Caution : connected devices, such as the servers and KVM switch, may not be hot-pluggable. Plug- ging and unplugging cables while servers and KVM are powered on may cause irreversible damage of the servers, KVM and Rackmount LCD Drawer. -
Page 18: Lcd Specifi Cation
4.1 LCD Specifi cations RP-W922QD, RP-W819QD & RP-W119QD Item Diagonal Size Max. Resolution Brightness (cd/m²) Color Support Contrast Ratio (typ.) Viewing Angle (H/V) Display Area (mm) Tr Response Time (ms) LCD Panel MTBF (hrs) VGA Signal Input Sync. Type Resolution Plug &... -
Page 19: Chapter 5 Dimensions
5.1 Dimensions RP-W922QD, RP-W819QD & RP-W119QD Product Dimension Model (W x D x H) 500.4 x 70.5 mm RP-W922QD 19.7 x 2.8" 480 x 71.5 mm RP-W819QD 18.9 x 2.8" 442 x 650 x 44 mm RP-W119QD 17.4 x 25.6 x 1.73" Packing Dimension (W x D x H) 565 x 539 x 156 mm... -
Page 20: Chapter 6 Rp-817Qd, Rp-919Qd & Rp-1020Qd
6.1 Package Contents RP-817QD, RP-919QD & RP-1020QD Rackmount LCD display x 1 pc 6' VGA cable (male to male) x 1 pc User manual x 1 pc Power cord x 1 pc Auto switch power adapter x 1 pc P.16 Chapter 6... -
Page 21: Structure Diagram
6.2 Structure Diagram RP-817QD, RP-919QD & RP-1020QD Front view LCD interchangeable module kit LCD + Quad display membrane Power adapter bracket Rear view P.17 Chapter 6 Power adapter Power cord... -
Page 22: Installation
Chapter 6 6.3 Installation RP-817QD, RP-919QD & RP-1020QD ■ Install each screws shown in Figure 10. Figure 10. ■ Fixed the LCD into the rack. * M6 screws is not provided. Figure 11. P.18... -
Page 23: Connection
Chapter 6 6.4 Connection RP-817QD, RP-919QD & RP-1020QD Video IN 1 ~ 4 RS-232 VCR in Video Loop Alarm I/O VCR out AV BNC VGA Power 1 ~ 4 ■ Please refer to P.28 - 40 The Rackmount LCD Drawer & Display are hot-pluggable, but components of Caution : connected devices, such as the servers and KVM switch, may not be hot-pluggable. -
Page 24: Chapter 7 Rp-117Qd, Rp-119Qd & Rp-120Qd
7.1 Package Contents RP-117QD, RP-119QD & RP-120QD LCD drawer x 1 pc 6’ VGA cable (male to male) x 1 pc User manual x 1 pc Auto switch power adapter ( for external power version) x 1 pc Power cord x 1 pc Mounting bracket x 2 pcs M6*15mm screw x 8 pcs M6 cage nut x 8 pcs... -
Page 25: Structure Diagram
7.2 Structure Diagram RP-117QD, RP-119QD & RP-120QD LCD interchangeable module kit “One Man” Installation Slides LCD + Quad display membrane Thumb Screw P.21 Chapter 7... -
Page 26: How To Use The Slides
7.3 How to Use the Slides RP-117QD, RP-119QD & RP-120QD Figure 12. Figure 13. Figure 14. ■ A black arrow release button is located on the outside of each slide. (shown in Figure 12). ■ Pull and hold the black arrow button on either side of the LCD drawer to unlock. -
Page 27: Connection
7.4 Connection RP-117QD, RP-119QD & RP-120QD RS-232 VCR in Alarm I/O VCR out ■ Please refer to P.28 - 40 The Rackmount LCD Drawer & Display are hot-pluggable, but components of Caution : connected devices, such as the servers and KVM switch, may not be hot-pluggable. Plug- ging and unplugging cables while servers and KVM are powered on may cause irreversible damage of the servers, KVM and Rackmount LCD Drawer. -
Page 28: Lcd Specifi Cation
8.1 LCD Specifi cations RP-817QD, RP-919QD, RP-1020QD, RP-117QD, RP-119QD & RP-120QD Item LCD Manufacturer Diagonal Size Max. Resolution Brightness (cd/m²) Color Support Contrast Ratio (typ.) Viewing Angle (H/V) Display Area (mm) Tr Response Time (ms) LCD Panel MTBF (hrs) VGA Signal Input Sync. -
Page 29: Chapter 9 Dimensions
9.1 Dimensions RP-817QD, RP-919QD, RP-1020QD, RP-117QD, RP-119QD & RP-120QD Product Dimension Model (W x D x H) 480 x 71.5 mm RP817QD series 18.9 x 2.8" 480 x 71.5 mm RP919QD series 18.9 x 2.8" 480 x 71.5 mm RP1020QD series 18.9 x 2.8"... -
Page 30: On-Screen Display Operation
10.1 On-screen Display Operation tr o > < p la D is tu p For LCD OSD Menu For Quad Display Control Remarks : ■ Quad Display Control please refer to P.39 - 44 LCD + Quad display membrane LCD OSD Menu Power light Green = On Orange = Power saving... -
Page 31: On-Screen Menu
10.2 On-screen Menu Select: OSD Confi guration Page 1024 x 768 59.8Hz Image Brightness Contrast Color Temp User Green Blue Adjust: Set: Image: To enter into the brighness, contrast, color temp, red, green, and blue Geometry: To enter into the auto adjust, H position, V position, phase and clock Video: Audio:... -
Page 32: Basic System Connection
11.1 Basic System Connection 1. VCR in : This BNC connector is connected to video output from VCR/DVR. A pre-recorded quad screen signal from a tape can be played back through a VCR/DVR and displayed on the video output channels. Push the VCR button (#2) to switch the device to VCR Playback mode. -
Page 33: Alarm I/O Connection & Operation
11.2 ALARM I/O Connection & Operation 1. ALARM I/O : This female type 9 pin D-sub connector is used for alarm sensor input and alarm output control connections. It provides Normal Open and Normal Close contacts for alarm out control. PIN# Sensor 1 Sensor 2... -
Page 34: Alarm I/O Connection & Operation
11.2 ALARM I/O Connection & Operation 3 Sensor Activated Alarm The unit is equipped with 4 alarm sensor inputs. If any alarm is activated: ■ the built-in buzzer will be activated. ■ the quad will switch the corresponding channel indicator LED to blinking mode. ■... - Page 35 Chapter 11 11.3 Remote Control Connection & Operation Rear Panel h i - z RS-232 1 2 3 4 ALARM monitor dc 12V, 1amp RS-232 Cable Wire Computer Remote Keypad P.31...
-
Page 36: Remote Control Connection & Operation
11.3 Remote Control Connection & Operation The device may be controlled via the male type 9 pin D-sub/RS-232 connector (#13) from a RC-5002 keypad, terminal or computer using ASCII code. Note: Please power off the unit before connecting the Remote Control keypad. 1. - Page 37 11.3 Remote Control Connection & Operation *1. For FIO-8037: in order to control the device to operate in Zoom mode, the computer has to fi rst send command code ” to switch the signal source from camera to VCR/DVR, at this time the device will automatically zoom channel 1 video from VCR/DVR to full screen.
- Page 38 11.3 Remote Control Connection & Operation 2.3 The confi guration of the status code for both normal and alarm operations: There are total 2 bytes of the status codes. Byte one, the fi rst 8 bits, shows the current status of the operation modes that the unit is in.
- Page 39 11.3 Remote Control Connection & Operation BYTE 2: Status code for alarm operations: The fi rst 4 bits show the sensor activated alarm status of each channel; next 4 bits show the video loss alarm status of each channel. The digit “1” means alarm event is detected, and “0”...
-
Page 40: Quad Display Connection
11.4 Quad Display Operation Setup Lock: Security locks out button. Push this button for 2 seconds to enable control panel lock out function. Push this button again for 2 seconds to disable the function. VCR: Push this button to enter into VCR Playback/Zoom operation. In this mode, the output video is displaying the video signal from VCR. - Page 41 11.5 Quad Display On-screen Menu Right after the unit is turned on, The monitor will display the last setting on the Setup Menu. 1. Page 1 of the Setup Menu - Display Setting Push Setup buttons (#1, #2) simultaneously to display the Setup Menu on the screen. There are total two pages in the Setup Menu.
- Page 42 11.5 Quad Display On-screen Menu 2 Page 2 of the setup menu- Alarm Setting Push Setup buttons (#1, #2) simultaneously and push (#1) button again to display page 2 of the setup menu on the screen. This Alarm Setting menu is used to set the desired alarm confi guration like buzzer, V-loss alarm and V-loss relay. ALARM SETTING SENSOR OPEN...
-
Page 43: Quad Display On-Screen Menu
11.5 Quad Display On-screen Menu 4: The setup menu can be reset to factory setting by pushing the Setup buttons (#1, #2) and power on the quad simultaneously. The factory setting is as follows: TITLE QUAD CH 1 CH 2 CH 3 CH 4 LIVE VIDEO FREEZE... -
Page 44: Vcr Operations
11.6 VCR Operations Zoom on VCR playback operation: Push VCR button (#2) to ON will switch the device to VCR playback mode. Under this mode, if the device is on quad display mode, a pr-recorded quad display video in the tape will be shown on the screen. If the device is in Full screen display mode, push any channel select buttons (#5) will select and expand the corresponding quadrants of the pre- recorded video to full screen display. -
Page 45: Dc Power
12.1 DC Power Options RP-W819QD & RP-W922QD RP-817QD, RP-919QD & RP-1020QD RP-W119QD & RP-120QD Model Input rating Input voltage: Input range: Input current - No load - Full load Output rating Output voltage: Output current: Effi ciency Remarks ■ Package does not include power cord and AC power adapter 12-Volt 24-Volt 9 ~ 18V... -
Page 46: Chapter 13 Troubleshooting
Chapter 13 13.1 Troubleshooting 1. How do I adjust the resolution? To change monitor resolution, click Start -> Control Panel -> Display. Select Setting tab to adjust the monitor resolution in Desktop Area. The available resolutions, "640 x 480", "800 x 600", "1024 x 768", "1152 x 864", "1280 x 1024", are deter- mined by the display card in your computer. - Page 47 Blank page...
