Instruction manual

Very important: Please, read the whole of this manual before installation and using the washing machine.
This manual is designed with the corresponding illustration accompanying the texts.
1
Installation
1.1 Unpacking the washing machine (1.1.1,
1.1.2 and 1.1.3). Remove the transit
brackers and the fixing and blocking
elements used for transport.
1.2 Connection to the mains water (1.2.1,
1.2.2 and 1.2.3). Always use the new
hose supplied with the appliance. Remove
any previously used supply tubes.
1.3 Draining. Install the elbow supplied, in
accordance with the measurements
shown in the diagram.
1.4 Levelling. Correctly level the washing
machine to prevent any noise or shifting.
The recommended order is as follows: 1.
Position the rear legs and fix them in place
(1.4.1). 2. Place the washing machine in
its final location (1.4.2). 3. Position the
front legs and fix them in place (1.4.3).
1.5 Connection to the mains electric. Refer
to the plate data.
2
Use
2.1 Before using the washing machine.
Find the label with your language (2.1.1.)
and stick it on to the tub (2.1.2., 2.1.3
and 2.1.4.).
CONFIGURATION MENU
2.2 Switching on. Press
2.3 Configuration menu. Press
2.4 Selecting the language. You can
choose the language by turning the
control knob (2.4.1 and 2.4.2). Press the
control to select it (2.4.3 and 2.4.4).
2.5 Adjusting the sound. You can adjust
2.6 Adjusting the end of programme. You
2.7 Adjusting the clock time. Set the clock
LOADING THE WASHING MACHINE
2.8 Opening the hatch. Press
2.9 Detergents and additives. Load the
.
.
the sound by turning the control knob.
Press the control to select it.
can adjust the duration of the sound
for the end of programme by turning
the control knob. Press the control to
select it.
at the correct time. Turn the control knob
and the two hour digits will appear. Press
the control to select it (2.7.1). Turn the
control knob and the two digits
corresponding to minutes will appear.
Press the control to select it (2.7.2).
clothes into the washing machine after
having separated them according to
colour, level of dirt and type of fabric.
The tub contains the following
compartments: wash
and softener (2.9.1).
All washing machines are prepared for
powdered detergents (2.9.2).
If you wish to use liquid detergent
(2.9.5), you will find a blue latch (2.9.3)
in the wash compartment. Pull it
outwards as far as it will go, release it
and it will remain in the vertical position
(2.9.4). This prevents the liquid detergent
from escaping. To go back to using
powdered detergent, move the blue
latch to the horizontal position and
push it backwards as far as it will go
to open the door.
Remember that you should not exceed
the MAX level marked on the softener
compartment.
e n g l i s h
.
, prewash
