- Page 1 Hikvision Technical Manual DS-2CD802PF(NF)(-E)(-W) IP Camera Technical Manual ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 2 It may not be reproduced in whole or in part, in any form, or by any means or be used for any other purpose without prior written consent of HIKVISION and then only on the condition that this notice is included in any such reproduction. No information as to the contents or...
- Page 3 Hikvision Technical Manual Contents 1. Key Features 2. Specifications 3. Dimension ©2006 – 2010 by HIKVISION. All rights reserved.
-
Page 4: Key Features
Support IE Client for Network Preview Support HIKVISION Watermark Support PTZ Control Support Sensor Alarm Input and Relay Output Support Network Intercom Function Compatible with Current HIKVISION DVR/DVS /SDK and Client Software ©2006 – 2010 by HIKVISION. All rights reserved. -
Page 5: Specifications
; (-W) series support IEEE802.11g Wireless WLAN Criterion, 2.4GHz Frequency. Interface Audio Input 1 channel 3.5mm audio interface (2.0 ~ 2.4Vp-p, 1kΩ) Audio Output 1 channel 3.5mm audio interface (line level, 600Ω) ©2006 – 2010 by HIKVISION. All rights reserved. - Page 6 1 channel relay output Others Working -10℃ ~ 60℃ Temperature Power Supply 12VDC, ±10%, (-E) series support PoE (Power over Ethernet) Power 4W MAX Consumption Dimensions (mm) 63 × 59 × 114 Weight 650g ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 7 Hikvision Technical Manual 3. Dimension ©2006 – 2010 by HIKVISION. All rights reserved.
