WM8766 Evaluation Board User Handbook
INTRODUCTION
GETTING STARTED
PACKING LIST
CUSTOMER REQUIREMENTS
WOLFSON MICROELECTRONICS plc
www.wolfsonmicro.com
The WM8766 is a 24-bit, 192kHz 6-Channel DAC.
This evaluation platform and documentation should be used in conjunction with the latest version of
the WM8766 datasheet. The datasheet gives device functionality information as well as timing and
data format requirements.
This evaluation platform has been designed to allow the user ease of use and give optimum
performance in device measurement as well as providing the user with the ability to listen to the
excellent audio quality offered by the WM8766.
The WM8766 Evaluation Kit contains:
1 WM8766-EV1B Evaluation Board
2 WM8766-EV1S 3.5" floppy disks containing control software
This manual -1 WM8766-EV1M
Minimum customer requirements are:
D.C. Power supply of +12V and -12V
D.C. Power supply of +2.7V to +5.5V
PC and printer cable (for software control)
Minimum spec requirements are:
Win95/98/NT/2000/XP
486 Processor
DAC Signal Path Requires:
Digital coaxial or optical data source
1 set of active stereo speakers
WM8766-EV1M
November 2003, Rev 1.2
Copyright 2003 Wolfson Microelectronics plc
