Sunphor SUP58T1 Manual

58 mm thermal printer series
Hide thumbs
Table of Contents

Advertisement

Quick Links

58mm Thermal Printer Series
Manual
(SUP58T1/ SUP58T2/ SUP58T3)
VERSION 2.0.01
July 2010
Copyright of this manual remains with Sunphor, reproduction of any section of this manual is prohibited
without prior written permission of Sunphor.
While all care has been taken to ensure the accuracy of this user manual, the continual development of
this product may reflect some inaccuracies.
Sunphor takes no responsibility for the inaccuracies and will Endeavour to update this user manual
periodically. Further assistance can be supplied by your local dealer.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUP58T1 and is the answer not in the manual?

Questions and answers

Related Manuals for Sunphor SUP58T1

Summary of Contents for Sunphor SUP58T1

  • Page 1 VERSION 2.0.01 July 2010 Copyright of this manual remains with Sunphor, reproduction of any section of this manual is prohibited without prior written permission of Sunphor. While all care has been taken to ensure the accuracy of this user manual, the continual development of this product may reflect some inaccuracies.

  • Page 2: Table Of Contents

    Content Notes ............................3 Application Area ........................3 Main Feature ..........................4 Technical Parameters ....................... 4 Connection of the printer….…………………………………………………………………..5 Installation of paper roll……………………………………………………………………….6 Driver Installation…………………………………..………………………………………….6 Baud Rate Setting(for computer)……………………………………………………………..8 Configuration Program “Iprinter.exe”……………………………………………………...10 Set or Change Printing Logo………………………………………………………………...12 Set or change language code page …..................14 Set Baud Rate (only for Pos58)……………………………………………………………..15 Set Repeat mode (only for Pos80)…………………………………………………………..15 IP Address Tool “Printer.exe”...

  • Page 3: Notes

    Notes 1. The printer is to be installed on a flat dry surface. 2. Do not store the printer in hot and humid conditions. 3. The printer’s power adapter is to be connected to a stable power supply of 240-Volts, please do not use other devices on the same power socket, to avoid voltage fluctuations.

  • Page 4: Main Feature

    Main Feature ² Print high-quality, low cost ² Low-noise, high-speed printing ² Supports cash drawer release ² Small and lightweight ² Easy paper loading, ease of use and maintenance ² Built-in data buffer (when printing can receive print data) ² Communication interface optional parallel port or serial port ²...

  • Page 5: Connection Of The Printer

    Adapter Voltage output DC 12V/3A Printer Input Voltage DC 12V/3A Cashbox Control DC 12-24V/1A Working Temperature 0-45℃， Humidity：10-80% Saving Temperature -10-60℃, Humidity：10-90% Connection of the printer (Switch off first) a. Connect the power adapter cable to the printer power interface b.

  • Page 6: Installation Of Paper Roll

    Installation of Paper Roll a. Open the printer cover by pressing the release button on the front right-side of the printer. b. Insert the thermal paper roll and note the direction in the image, to ensure the roll is correctly inserted . c.
  • Page 7 Select Printer Type ”SUP58T2 Series” and click “OK” to continue the installation. See the following image: 5. Click Start> Control Panel> Printers and faxes> to check the new printers installed successfully. Right click the new printer “SUP58T2”. Open “Properties” to select the appropriate “Port” (USB, Serial or Parallel).

  • Page 8: Baud Rate Setting(For Computer)

    Baud Rate Setting (for computer) For the COM port printer, the baud rate must be set correctly before using it. (The current baud rate you can get from the printer’s self-testing page.) 1. Select Control PanelèHardware and SoundèDevices and Printers. Right click on your printer Icon, choose“Printer properties”.
  • Page 9 2. Active “Prots” panel, and choose the correct COM port number, then click on “Configure Port”..

  • Page 10: Configuration Program "Iprinter.exe

    3. Set the baud rate to fit the printer, then click on “Apply”. Configuration Program “Iprinter.exe” The basic parameters of printer could be changed by running the configuration program ”Iprinter.exe” on the driver CD-ROM. You also can download it from our website: www.sunphor.com. Ø SET OR CHANGE PINTING LOGO;...
  • Page 11 Find the program on the attachment CD-ROM, open the main configuration panel by double-clicking it. Make sure the correct “COMM Port” has been selected, (Please make sure the selected port hasn’t occupied by other program or device) and have set the correct Baud rate for the COM port, or the correct IP Address for the Ethernet Port.

  • Page 12: Set Or Change Printing Logo

    1. Set or Change Printing Logo ² Click “NV Logo Download” button to open the logo download panel, select the correct printer series. Make sure the logo file is BMP format and the size is not over 576*600 dots. when the logo file has been loaded successfully, it will be showed on the logo window.
  • Page 13 ² Open the “Device settings” from the printer properties window, and choose the logo you want to print on the“NV LOGO” dialog box, click on “apply”.

  • Page 14: Set Or Change Language Code Page

    2. Set or change language code page Choose the character set that you need, then click on“Set Default Page”.

  • Page 15: Set Baud Rate (Only For Pos58)

    3. Set Baud Rate (only for Pos58) Choose Baud rate that you need, then click on “Set Baud Rate”. 4. Set Repeat mode (only for Pos80) Choose “Enable” or “Disable” , then click on “Set Repeat Mode”.

  • Page 16: Ip Address Tool "Printer.exe

    IP Address Tool “Printer.exe” ² Set or Change Printer’s IP Address. This program is effective for 58mm Ethernet printers and 80mm Ethernet printers. It used to set or change printer’s IP address. In order to realize the data communication between the computer (or POS host) and the printer, the computer (or POS host) IP and the printer IP must be at the same gateway and the printer IP/ID must be unique.
  • Page 17 For example, the computer (or POS host) IP is 192.168.1.108, the gateway is 192.168.1 the printer IP is 192.168.123.100. See the following steps for your reference. Build a simple connection with printer and computer. 2. Change the computer IP to 192.168.123.108. Running the IP configuration program “Printer.exe”, you can see the current IP information on the program window as below: 3.
  • Page 18 5. If changed successfully. There will pop up a response window (see the right picture). You also can print a self-test page to check again. (The current IP on the self-test page should be updated to 192.168.1.205). And then, you perhaps need to reset the computer IP to 192.168.1.XXX.

  • Page 19: Change The Printer Id

    ² Change the printer ID Normally, Users do not need to set or modify the printer ID, unless a conflict with other device’s ID around the LAN. You can get the current unique ID of printer by finding from the self-testing page. For example: 000.202.255.017.246.232, Input the last four numbers 255.017.246.232 on the “LastFourMACAddress”...

  • Page 20: Other Notice

    Other Notice 1. When doing maintenance on the printer, make sure the power is turned off. 2. Don't allow your hands or any metal object to touch the surface of the printer head. Beware that metal tools can damage the rubber roll, the sensor and other components in the printer. 3.

This manual is also suitable for:

Sup58t2Sup58t3
