- Page 1 User manual Currency counters 40 NEO / 40U NEO PRO 40 SERIES...
-
Page 2: Specification
PRO INTELLECT TECHNOLOGY corp. provides a series of economic class counters PRO 40, CASH LINE equipment. Counters PRO 40 and PRO 40U are designed for counting small volumes of various foreign currencies including EURO and USD. One of the distinctive features is the small size of the counter and simple operation including the main counting functions: counting, batching, summing up, optical density and UV light verification test. -
Page 3: Control Panel Operation
Appearance Figure 1 1. Control panel 2. Cover 3. Hopper 4. Stacker 5. Carrying handle 6. Power cord 7. Power switch 8. External display port 9. External display Control panel operation 1. Main count display- depicts counting results 2. Batch mode display – indicates the follow information: -a number of banknotes chosen in this mode -a message error code 3. -
Page 4: Safety Precautions And Maintenance Rules
7. “START” button The button starts: -counting -continues counting and clears error messages on display 2 -clears counting result on the main dis- play 1 -stores changes to the counter settings 8. “BTH” button Mode switch button (100, 50, 25, 20, 10, reset): Press “BTH”... -
Page 5: Counter Operation
Counterfeit detection (for PRO 40U model) UV detection The UV detector is designed for various currencies and all banknote types. The count- er automatically tests the banknotes’ UV-fluorescence level. If the level is incorrect, the device stops counting and “EU” error is displayed. Suspicious banknotes will always be placed on top of the output stack. - Page 6 Figure 4 Figure 3 7.3. Batch operation mode (Counting mode for a specified number of banknotes) -Press “BTH” button on control panel as many times as necessary until the display reads the desired batch size -Use additional button “+1” to set an exact number -Repeat from the beginning of Table 7.2.
- Page 7 Function settings and troubleshooting 8.1. Changing the UV detection sensitivity level (PRO 40U). Press and hold “UV” button for 4 seconds. The display 2 will show Uu[X] sign, where X – is level of UV detector sensitivity: 1 – minimum sensitivity 2 –...
- Page 8 8.3 Error codes Code Reason Solution 1.Passing of halved or torn 1. 1Remove banknotes from the stacker, leave banknote aside suspicious banknote (placed on the top), 2. Failure of left or right sensors of repeat counting procedure the counter 2. Contact appropriate service centre. Remove banknotes from the stacker and Chain note detected repeat counting procedure...
- Page 9 System errors. Service. Code Reason Solution Switch off and then switch on the power, clean Left sensor is either blocked or failed. the sensor or contact the service center Right sensor is either blocked or Switch off and then switch on the power, clean failed.
-
Page 10: Limited Warranty
Limited warranty Manufacturer guarantees proper functioning of the device during the warranty period since the date of sale under condition of compliance with maintenance and storage procedures described in this manual. After unpacking the device please keep the package and technical description. Warranties are canceled in the event that the device was not transported in the original packaging or maintenance procedures were violated.
