- Page 1 4CH/ 8CH/ 16CH Digital Video Recorder DVR204B/ 208B/ 216B INSTRUCTION MANUAL...
-
Page 2: Table Of Contents
DIRECTORY CHAPTER 1 Hard Disk Installing (Standard shipping products include neither HDD or R/W) ......2 CHAPTER 2 Panel Appearance ........................4 2-1. Front panel controls..........................4 2-2. Rear panel connectors........................5 CHAPTER 3 Live, Playback Operations......................6 3-1. In LIVE mode, the remote control instructions ..................6 3-2. -
Page 3: Chapter 1 Hard Disk Installing (Standard Shipping Products Include Neither Hdd Or R/W)
CHAPTER 1. Hard Disk Installing (Standard package includes either HDD or R/W) Step 1. Install hard disk after opened the DVR lid 【4CH】 Place the hard disk into the hard disk drive bay, and hook up SATA cable and power cable to their corresponding ports accordingly. - Page 4 Step 2. Screw the bottom 4 corner screw holes (for hard disk mount) Step 3. Place the lid back on the top of the machine and locking screw holes. Hard disk installation is complete. NOTE： ： ： ： After installation, please reboot the hard disk before recording. For more detailed information, please check out User Manual System Tools for reference.
-
Page 5: Chapter 2 Panel Appearance
CHAPTER 2. Panel Appearance 2-1. Front panel controls Under the LIVE mode (livetime viewing mode) or playback mode, 1~4/8 Channel 1~4/8/16 Channel 1~4/8/16 display. Under the playback mode, press the STOP button to stop the operation or go to the Stop upper menu. -
Page 6: Rear Panel Connectors
2-2. Rear panel connectors 【4CH】 【8CH】 【16CH】 USB Mouse Port 2.0 USB Mouse Video In 4/8/16CH Video Input (BNC) Video Out 1CH Video Output (BNC) Audio Out 1CH Audio Output (RCA) Audio In 4CH Audio Input DC12V Power Input PC Monitor Output RJ-45 Network Connection RS-485 For Speed Dome Use... -
Page 7: Chapter 3 Live, Playback Operations
CHAPTER 3. Live, Playback Operations The IR (infrared) remote control and mouse operate varied under different modes; this chapter introduces the functions of them under three different modes: LIVE, PLAYBACK and PTZ. 3-1. In LIVE mode, the remote control instructions Record Zoom in/out Previous/Next single channel... -
Page 8: Main Menu User Guide
3-2. Function features instruction Right-click the mouse, you may enter into LIVE mode to manage different features. DESCRIPTION ICON Main Menu，Resting the cursor on this icon will bring up the following nine menu icons System Disk Information – Version, IP, MAC, and HDD capacity Zoom In/Out = ”Zoom,”... - Page 9 Lock= “LOCK” Backup- information backup Graphical icons that will display after right-clicking your mouse under Remote mode ICON DESCRIPTION Remote Snapshot. Pictures taken on camera and image storage. (Pre-archived folder—My Documents Folder / DVRData / Snapshot) Select Archive Folder-Select the folder to store the photo and video Switch off to full screen display Image quality switch HQ (High Quality);...
- Page 10 Switch to the PLAYBACK Mode by pressing “PLAY” button under the LIVE mode. The control panel will appear on far right down on the screen, the control panel can be controlled via mouse cursor. ICON DESCRIPTION Snapshot- turn the current screen into the “Image “and store in USB device.；the Image will be stored in computer on Remote mode Rewind Fast.
- Page 11 Graphical icons that will display under Remote mode DESCRIPTION ICON USB device detected HDD not being detected Lock is on — need to enter code number in order to unlock Network is connected Recoding — in full screen the icon appears when the one of the cameras is recording Event occurred.
- Page 12 DESCRIPTION ICON Via Set function, cameras will point-by-point to patrol the environment fully. Click on “SET” icon and hit Enter button to proceed this action. Pre-set number N(1~255) Move to Pre-set number N Delete Pre-set number Automatically patrol Zoom in Zoom out Iris on Iris off...
-
Page 13: Chapter 4 The Main Menu Setup
CHAPTER 4. The Main Menu Setup Enter the setup menu first time, please choose the login account, and then enter the password. Administrator default password is "1111". Verify password, if correct will enter the setup menu 4-1. Camera Setup - 12 -... -
Page 14: Event Setup
Customize the camera channel name PTZ Enable On/Off No. of PTZ PTZ Number( 0~255) Select the PTZ camera transmission speed(2400、4800、9600、 Baud Rate 19200) Support ：LILIN MLP2、PELCO-D、PELCO-P、HME PTZ Protocol PDZ ,UNITED-D Brightness Brightness Adjustment (From value１~２５５) Contrast Contrast Adjustment (From value１~２５５) Color Adjustment (From value１~２５５) Saturation Chroma Adjustment (From value１~２５５) -
Page 15: Recording Setup
ICON DESCRIPTION 1-16 Each channel can be set dependently Enable Switch on or off the motion detection function Buzzer Alarm On／Off Set up Sensitivity from value 1 to 10 for each channel. The lower Sensitivity value you set the higher sensitivity it will be Motion Area Setup Enter to Motion Area Setup Apply All... -
Page 16: Sequence Setup
ICON DESCRIPTION 1-16 Each channel can be set independently OSD Position X Setup OSD X axis OSD Position Y Setup OSD Y axis OSD Position setup Setup OSD axis Record Sound On／Off HDD Circulate Record On／Off Alarm recording time 1~60 seconds Recording Mode Manual/ Schedule Record 1~6 Schedule Record Setup... -
Page 17: Video Quality And Frame Rate Setup
4-3-2. Video Quality and Frame Rate Setup ICON DESCRIPTION View Normal / View Event Select recording mode Check/uncheck the box enable/disable selected channel No.1~8 recording Select recording resolution: Resolution NTSC:352x240, 704x240, 704x480 PAL:352X288,704X288,704X576 Quality Select quality: Below Basic/ Basic/ Normal/ High/ Highest Select recording frame rate. -
Page 18: System & Disk Information
ICON DESCRIPTION HDD Cycle Recording On／Off Hard Disk Information Hard Disk Information Instruction H. D Formated Setup Hard Disk Format 4-4-1. System & Disk Information ICON DESCRIPTION Ver=Version DVR current software version DVR Network IP address, if DVR doesn’t connect ,it will show IP ADDR=IP Address "Network not connected"... -
Page 19: Networking Connection
ICON DESCRIPTION Connectivity Connectivity Setup (LAN, DHCP, PPPoE, 3G) HTTP Setup Enter HTTP setup menu DDNS Setup Enter DDNS setup menu E-Mail Setup Enter E-Mail setup menu FTP Setup Enter FTP setup menu SMS Setup Enter SMS setup menu Setup on Push Enter menu on Push Notification setup Notification 4-5-1. - Page 20 ICON DESCRIPTION Local IP Address Enter IP address provided by ISP Mask Enter IP address of Subnet Mask provided by ISP Gateway Enter IP address of Gate way provided by ISP Enter DNS address provided by ISP. DNS Server (Note: The correct DNS address must be entered for DDNS function).
-
Page 21: Http
ICON DESCRIPTION User name Enter user name provided by ISP Password Enter password provided by ISP 4-5-2. HTTP ICON DESCRIPTION Check to enable HTTP server. Users can remotely access into the DVR Startup HTTP over the network if the HTTP function is activated. HTTP Port Enter a valid port value from 1 up to 65000. -
Page 22: Email Setup
ICON DESCRIPTION Enable DDNS Enable / Disable DDNS function Enter the registered SMTP Server: DDNS Server dyndns.org、no-ip.org、dnsexit.com、ddnsipcam.com Enter the completed registered SMTP Server. (Including username + Server) Host Name If the user name is lilin304 and you choose dyndns.org as your server, you should enter: lilin304.dyndns.org User Name Enter DDNS Server User Name... -
Page 23: Data Backup Setup
4-6. Data Backup Setup ICON DESCRIPTION DATA BACKUP ENTER「DATA BACKUP」MENU CD/DVD data backup Enter「CD/DVD DATA BACKUP」MENU Enter「backup to USB」MENU Save DVR Setup to USB Set the DVR to a USB device. USB will appear the file. Enter "Download Setup from USB settings “menu Get DVR Setup from USB The USB device settings, loaded to the DVR Enter「Reduction factory settings」Menu. -
Page 24: System Setup
4-7. System Setup ICON DESCRIPTION DVR NAME Display name for application software log remotely into the DVR. Language Setup OSD display language VGA Resolution 1024X768, 1280X1024, 1366x768 or 1440x900 Video Type Auto or Manual Menu / Key Lock On／Off DVR ID Number 0~63 Display setup Enter Display setup... -
Page 25: Display Setup
4-7-1. Display Setup ICON DESCRIPTION Display Time On / Off Date and Time Display Display Camera Info. On / Off camera information Display Record Info. On / Off Record Information Display Control Relay On/ Off control relay Display Border On / Off Border Time Position up~ down 0~255... - Page 26 ICON DESCRIPTION Date Format year/month/date, date/month/year, month/date/year Select Time zone Adjust to Greenwich Mean Time<GMT> Change Date/Time On / Off Change date/Time DayLight Saving Time Setup On / off Daylight saving time Internet Time Setup On / Off Network time Change Date / Time Setup Select the Year/Month/Date and press “YES”.
-
Page 27: User Account Setup
Internet Time Setup ICON DESCRIPTION Check to enable DVR automatic synchronization function. Effective by this option selected, DVR will automatically Automatically Sync synchronize the time upon rebooting or by every 24 hours after booting. Effectively, Date and Time show on DVR will immediately Update Now correspond with those in internet server. - Page 28 ICON DESCRIPTION NUMBER NO Check to activate the user’s account USER NAME Setup username PASSWORD Set up password for each user PERMISSION Set up Permissions for each user CHANGE ADMIN PASSWORD Change administrator’s password Permission Setup - 27 -...
-
Page 29: Chapter 5 Backup And Playback Search
CHAPTER 5. Backup and Playback Search 5-1. Backup Setup User can backup any segment of recorded data in a specified time frame. To do so, either a CD R/W or storage device, like USB, must be connected to the DVR. Backup DVF file that can be played by “DVFPLAYER”... -
Page 30: Dvf Player Usage
5-1-1. DVF Player Usage Step1. Install “DVR play” software to your PC. You can get ”DVR play” file from the CD with DVR Packing. PS. When you using USB to backup file, DVRplay.exe will copy to USB with the backup file automatically. -
Page 31: Playback Search Setup
Step4. DVRplay software will play the backup file automatically. 5-2. Playback Search Setup Play - 30 -... -
Page 32: Time Search
ICON DESCRIPTION TIME SEARCH Enter time search menu EVENT SEARCH Event search menu 5-2-1. Time Search TIME SEARCH can search for the specific time of recording data to playback. Press “Enter” or left click on the □ desired date to playback. Note that dates with recording data are marked with a red square “ “System will start playing back according to the date you selected. -
Page 33: Chapter 6 Remote Software Installation And Setup
CHAPTER 6. Remote Software Installation and Setup AP software: ”DVR Remote Desktop” allows you to remotely access and control the DVR from PC. p.s. Operation system currently supports Windows XP SP2 and above and Windows Vista, Windows 7 6-1. Application Software Installation and Setup Step1. - Page 34 Step4. Run or Save our AP software Step5. If you choose to run the software, Start window will be shown up. Please enter information of login DVR: IP, Port, Username and Password, or choose “Play Recorded File” to open backup files in your PC.
-
Page 35: How To Do Remote Monitoring Through Ie
6-2. How to do remote monitoring through IE Step1. Enter the IP address of DVR in IE browser. The address appeared in this image is only for demonstration. Actual address is depending on the setup of on-site DVR. Step2. Windows as below will show up. Please enter the user name and password. Default user name and password is admin/1111. -
Page 36: How To Do Remote Monitoring Through Jpg Viewer (Monitor Function Only)
NOTE： ： ： ： There will be IE connection security issue when clicking this link for the first time. Please refer to index II for Remote Monitoring IE ActiveX Control Installation Instruction. Step4. DVR image appear 6-3. How to remote monitoring through JPG Viewer (Monitor Function only) Step1. - Page 37 Step2. Windows as below will show up. Please enter the user name and password. Default user name and password is admin/123456. Other related setup about user account and password, please check “4-5 Account Setup. “ The user name and password appeared in this image is only for demonstration. Actual user name and password depend on the setup of on-site DVR.
-
Page 38: Application Software And Ie Operation
6-4. Application software and IE operation System Requirements for AP software Intel Pentium 4 above 512M above Microsoft Windows 7、Windows Vista、Windows XP SP2 above Need to support DirectX 9.0 (above) VGA card NOTE1 IE and AP connection need PORT80(according to HTTP PORT Antivirus software settings) Others... -
Page 39: Chapter 7 Digital Video Recorder Dvr Specifications
CHAPTER 7. Digital Video Recorder DVR Specifications Model DVR204B DVR208B DVR216B Video System NTSC/PAL Control Panel Compression H.264 Video Input BNC x4(1 Vp-p,75Ω) BNC x8(1 Vp-p,75Ω) BNC x16(1 Vp-p,75Ω) Video Output BNC x1/ VGA x1 BNC x1/ VGA x1 Audio Input/Output... -
Page 40: Chapter 8 Mobile Application Installation And Usage
CHAPTER 8. Mobile Application Installation and Usage 8-1. iPhone operating system – installation and management (iViewerDVR software installation guide) Step 1 Step 2 Step 3 Connect your iPhone to Internet Type “iViewerDVR” and hit the Popup the app intro and and click into “”AppStore”... - Page 41 Step 7 Step 8 Step 9 Press iViewerDVR app Click the left down corner to add Hit “Add” button to add one DVR connecting into DVR account information data info (located at the far left end corner). Attention: In order to synchronize DVR with the application with no further technical issues, please make sure you enter &...
-
Page 42: Google Android Phone Operating System - Installation And Management
8-2. Google Android Phone operating system – installation and management (iViewerDVR software installation guide) Step 1 Step 2 Step 3 Type in “iViewerDVR” Click onto “iViewer DVR” app Connect your Android phone to Internet and then click “Install” button enter Market (PLAY store) application Step 4 Step 5 Step 6... - Page 43 Step 7 Step 8 Click “Yes” to add DVR login Popup entering DVR name, IP address, account information default gateway address, account login ID, and password. Then click on “Add “button. Attention: In order to synchronize DVR with the application with no technical issues, please make sure you enter & save your DVR data information into the app when first time initiating the app.
