SYSTEM-ZDAS-16CA-8 PROGRAMMING GUIDE
Thanks for choosing
reading carefully this guide, operating this system strictly on the standard procedure.
is suitable for most circumstances and convenient for using, no matter its
ZDAS-16CA-8
appearance, function, or operation. We hope this Guide could answer most of your questions
when using the system.
1.1 Summarize
takes advanced microprocessor as its core technology. So it has the
ZDAS-16CA-8
advantages of high integration, very good stability, flexible function and convenient use.
1.2 Attentions before usage
Get approval from local police office before presetting the police phone number as
the alarm phone number
Ensure the system is in the correct installation, then connect AC power supply with
the panel
Only suitable for DC 12V 7AH sealed lead rechargeable storage battery, be cautious
to connect red positive line with positive terminal （+）, and black negative line with
negative terminal（－）. The incorrect connection will cause damage of main panel.
Rechargeable current ≤ 1.5A
Avoid metal parts or hand contact to the electronic parts on the circuit when install
the lines.
Must use 2.7K resistor short unused wired zone
Mark wires to avoid miss-connection when using too many wired zones
Cut off all AC power supply, battery and telephone line before maintenance
Short JP1 when reset main panel
The 1.00MM copper-core wire from the keypad to alarm panel is up to 150 meters, 4
keypads can be connected in series
1.3 Features
High speed digital communication, compatible ADEMCO4+2, CID digital
communication protocol；Send alarm signal to alarm center.
Different programmable settings, such as alarm sounds, zone types, recording,
monitoring, remote controlling, telephone number, phone line Check, and etc.
Compatible with wired and wireless function
1 group 6 bits primary passwords, 15 groups subsidiary setting passwords are
available to improve security;
Multi-Function Alarm Control Panel. We suggest you
ZDAS-16CA-8

Chapter 1 Summarize

Page1of 16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZDAS-16CA-8 and is the answer not in the manual?

Questions and answers

Shani kapur Gauro
March 16, 2025

Would you please can you tell me about is programing code

0
1 comments:
Mr. Anderson
March 16, 2025

The programming code for the Zuden ZDAS-16CA-8 follows specific formats based on the function being set. Some key programming codes include:

- Set alarm code for zone (1~8): `8+17+set alarm code (2 bit)`
- Set Arm Code: `8+18+set alarm code (2 bit)`
- Set Dis-Arm Code: `8+19+set alarm code (2 bit)`
- Set key Code Conversion Table: `8+20+set alarm code (2 bit)`
- Set key Code 16 Bit Number Related Key: `8+21+set alarm code (2 bit)`
- Set System Startup Code: `8+25+set alarm code (2 bit)`
- Set AC Power Recovery Code: `8+26+set alarm code (2 bit)`
- Set AC Power Failure Code: `8+27+set alarm code (2 bit)`

Additional programming codes involve setting self-inspection report intervals and siren sound time:

- Set interval time of Self-inspection Report: `41+ time (2 bit) + (confirm key)`
- Set Siren Sound Time: `42+ time (2 bit) + (confirm key)`

These codes are used within the system’s programming mode to configure various alarm and system settings.

This answer is automatically generated

0

Related Manuals for Zuden ZDAS-16CA-8

Summary of Contents for Zuden ZDAS-16CA-8

  • Page 1: Chapter 1 Summarize

    SYSTEM-ZDAS-16CA-8 PROGRAMMING GUIDE Thanks for choosing Multi-Function Alarm Control Panel. We suggest you ZDAS-16CA-8 reading carefully this guide, operating this system strictly on the standard procedure. is suitable for most circumstances and convenient for using, no matter its ZDAS-16CA-8 appearance, function, or operation. We hope this Guide could answer most of your questions when using the system.

  • Page 2: Main Specification

    ZDAS-16CA-8 Wireless & Wired Security Alarm System 6 groups of phone number and 2 group alarm center phone number could be set. When the alarm activated, it could repeat dialing the numbers. 7 ARM modes: EXIT ARM, BOUNDARY ARM, single zone ARM, delay ARM, remote ARM, compel ARM and preset time ARM.

  • Page 3: Chapter 2 Installation And Connection

    ZDAS-16CA-8 Wireless & Wired Security Alarm System Chapter 2 Installation and Connection 2.1 Wiring Diagram 2.1.1 Wiring diagram on main board * Indicator LED will light on when working normally, Z1-Z8 means 1－8 zone 2.1.2 Wiring diagram of expand board (Only for ZDAS-16CA) * Z9－Z16 means 9－16 zone...

  • Page 4: Connection Of Power Supply

    ZDAS-16CA-8 Wireless & Wired Security Alarm System 2.1.3 8 zones Expand module Z9－Z16 means 9－16 zone It must connect 2.7K resistors, connecting is the same with Z1-Z8. Set expanded 9-16 wired zones ON/OFF. 1. Insert the expand module (Factory setting: inserted) 2.
  • Page 5 ZDAS-16CA-8 Wireless & Wired Security Alarm System 2.5 Connection of Telephone Line Phone Communication Port: The exterior line should be connected to LIN1, LIN2. TEL1 and TEL2 should be connected to the telephone. 2.6 Connection of Sound Monitor Sound Monitor Port: The signal line should be connected to MIK, the POSITIVE should be connected to MIK+, and the negative should be connected to ground wire GND.

  • Page 6: Chapter 3 System Operation

    ZDAS-16CA-8 Wireless & Wired Security Alarm System Chapter 3 System Operation 3.1 System Operation The main usage of the alarm system is to prevent illegal intruder from your home or office, or to get help in emergency. When you are leaving your office or home, make sure all the windows and doors are locked.
  • Page 7 ZDAS-16CA-8 Wireless & Wired Security Alarm System Specification: ①. Function Indicator Light (Power Supply, Communication, Signal, Status, ARM, Setting): Indicate the working status of the System Function Display Explanation Indicator Light AC Power Supply Normal Power Supply AC Power Supply Break...

  • Page 8: Remote Control

    ZDAS-16CA-8 Wireless & Wired Security Alarm System 2, If ARM succeed, the Buzzer will long sound, ARM Indicate Light on; if the system refuse the dictate, the Buzzer will short sound 3 times, it means that some zone is activated or set ARM already.

  • Page 9: Chapter 4 System Settings

    ZDAS-16CA-8 Wireless & Wired Security Alarm System seconds, or press “1”, after twice record and indicate sound “Du”, input user password to tus. Remote Control Sta Remote Control Status: Start control status by using telephone or mobile phone, press “1” to start ARM; press “2” to disarm, (stop dial the following phone number after ARM started): press “3”...

  • Page 10: Set Mode

    ZDAS-16CA-8 Wireless & Wired Security Alarm System Telephone Remote Control 0---inefficacy Ring Times 0---8 times ARM Delay 0---no delay Telephone Line Check No Check Code CID code Telephone alarm control Input ”1” set, input ”2” stop, input “3” monitor Recorder...
  • Page 11 ZDAS-16CA-8 Wireless & Wired Security Alarm System subsidiary password. 4. Exit setting status (see 4.4), or automatically exit after 30 seconds. (Factory User Password: Group 1: 123456); 4.7 Wireless Detector Learning Function 1. Start Set Mode (see 4.3); 2. Choose the zone to learn: 20＋zone number (2 bits)＋F4 (Confirm Key), Zone number is from 01~16.
  • Page 12 ZDAS-16CA-8 Wireless & Wired Security Alarm System 3. Exit Set Mode (see 4.4) 4.11 Set User Code (Alarm Center Code) Alarm allocates 4 bits network code: 1. Start Set Mode (see 2. Set User Code: 31＋4 bits User code＋F4 (Confirm Key);...
  • Page 13 ZDAS-16CA-8 Wireless & Wired Security Alarm System Format: “0” “1” “2” is center (“0” CID, “1” available program 4+2), “5” user’s telephone Format after reset: “0” is 0, “1--6” line is 5 4.15 Set Report Output 1. Start Set Mode (see 2.
  • Page 14 ZDAS-16CA-8 Wireless & Wired Security Alarm System 4.23 Set Programmable4+2 Code for different Alarm Center 1. Start Set Mode (see Conversion Table 8+ (01~16) +alarm code (2 bits) + F4 Set Zone number 1~16 16 Bit Number Related Key 8+ 17+set alarm code (2 bits) + F4 Set Alarm Code...
  • Page 15 ZDAS-16CA-8 Wireless & Wired Security Alarm System 3. Exit Set Mode (see 4.31 Set Alarm if AC power down 1. Start Set Mode (see 2. Press 62+0/1+F4 (1. sound, 0. no sound. Factory setting: 0) 3. Exit Set Mode (see 4.32 Set Open/Close of Anti Jumper alarm function...
