Track-Bot PlayStation Wireless Remote
Controlled Robot (RKI-1247)
Assembly Guide & Manual
Robokits India
http://www.robokits.co.in
&
http://www.robokitsworld.com
info@robokits.co.in
http://www.robokits.co.in
http://www.robokitsworld.com
Page 1
Track-Bot PS2 Wireless Remote Controlled Robot Assembly Guide
Advertisement
Related Manuals for Robokits TrackBot RKI-1247
Summary of Contents for Robokits TrackBot RKI-1247
- Page 1 Track-Bot PlayStation Wireless Remote Controlled Robot (RKI-1247) Assembly Guide & Manual Robokits India http://www.robokits.co.in & http://www.robokitsworld.com info@robokits.co.in http://www.robokits.co.in http://www.robokitsworld.com Page 1 Track-Bot PS2 Wireless Remote Controlled Robot Assembly Guide...
- Page 2 1 X PS2 Receiver and Motor Controller Circuit for 2 DC motors • All required screws, studs, cable ties and connectors • You can see video demo of this robot on YouTube at : https://www.youtube.com/watch?v=jMUEgDPHygM http://www.robokits.co.in http://www.robokitsworld.com Page 2 Track-Bot PS2 Wireless Remote Controlled Robot Assembly Guide...
- Page 3 Chassis. Twist wires both motors to keep them neat and managed. motors back Chassis with nuts. You will need to open the nuts first. http://www.robokits.co.in http://www.robokitsworld.com Page 3 Track-Bot PS2 Wireless Remote Controlled Robot Assembly Guide...
- Page 4 Fix 4 pulleys to the shafts of both DC motors and dummy motors. Threaded holes are already there on all shafts. Try to fix the screw through them. http://www.robokits.co.in http://www.robokitsworld.com Page 4 Track-Bot PS2 Wireless Remote Controlled Robot Assembly Guide...
- Page 5 Make 2 such extended cable ties. Fix the battery to the base with cable ties. After fixing properly cut extra cable ties portion with nipper or cable cutter. http://www.robokits.co.in http://www.robokitsworld.com Page 5 Track-Bot PS2 Wireless Remote Controlled Robot Assembly Guide...
- Page 6 Put a belt over pulleys on each side. You may need to stretch belts a little. Now the mechanical part is complete, it is now time to put on electronics. http://www.robokits.co.in http://www.robokitsworld.com Page 6 Track-Bot PS2 Wireless Remote Controlled Robot Assembly Guide...
- Page 7 Step 6 Take the circuit and screws and 10 mm studs. Fix 4 studs to the circuit holes with screws. http://www.robokits.co.in http://www.robokitsworld.com Page 7 Track-Bot PS2 Wireless Remote Controlled Robot Assembly Guide...
- Page 8 Connection of 6 pin connector of receiver to PCB should be done in such a way that GND pin comes to black wire. http://www.robokits.co.in http://www.robokitsworld.com Page 8 Track-Bot PS2 Wireless Remote Controlled Robot Assembly Guide...
- Page 9 Note that in DC motors you can swap wires to change directions. Check for forward backward, left right action. Change the wires if robot is doing wrong action on key press. http://www.robokits.co.in http://www.robokitsworld.com Page 9 Track-Bot PS2 Wireless Remote Controlled Robot Assembly Guide...
-
Page 10: Remote Control Commands
Move forward with speed control Left joystick Move backwards with down speed control Left joystick Take left turn with speed left control Left joystick Take right turn with speed right control http://www.robokits.co.in http://www.robokitsworld.com Page 10 Track-Bot PS2 Wireless Remote Controlled Robot Assembly Guide... -
Page 11: Service And Support
The PS2 Remote Controlled TrackBot is intended for personal experimental and amusement use and in no case should be used where the health or safety of persons may depend on its proper operation. Robokits provides no warrantee of suitability or performance for any purpose for the product. Use of the product software and or hardware is with the understanding that any outcome whatsoever is at the users own risk.
