Summary of Contents for Ada 2fx
-
Page 2: Table Of Contents
ADA 2FX owners manual version 1 CONTENTS INTRODUCTION FEATURES PRECAUTIONS CONTROL FUNCTIONS REAR PANEL INITIAL SET-UP INPUT/OUTPUT ADJUSTMENT EFFECT SELECTION REPEAT HOLD DIGITAL FLANGER DIGITAL CHORUS DIGITAL DELAY REMOTE FUNCTIONS PATCH DIAGRAMS FIGURE: 5-1 CLASSIC FLANGE 5-2 THICK CHORUS 5-3 STEREO DOUBLING... -
Page 3: Introduction
ADA 2FX owners manual version 1 1.0 INTRODUCTION Thank you for purchasing the ADA 2FX DIGITAL MULTI-EFFECTS. The 2FX combines the latest in digital technology in an innovative performance oriented format. The DIGITAL MULTI-EFFECTS' dedicated controls and two independent delay processors give you more special effects processing power than any other digital delay in its class. -
Page 4: Rear Panel
ADA 2FX owners manual version 1 DIGITAL FLANGER: MANUAL Sets the static delay time. DEPTH Determines the mix between the MANUAL control and the RATE control (sweep LED). As the DEPTH control is turned clockwise, the FLANGER sweeps over a wider range. -
Page 5: Initial Set-Up
FIGURE 3-1 - INITIAL FRONT PANEL SET-UP 3.0 INITIAL SET-UP The ADA DIGITAL MULTI-EFFECTS interfaces with a wide variety of input sources including high level microphones, electronic instruments and mixing consoles. The input circuitry is high impedance which functions properly with both low or high impedance sources and low (- 18dBV) and high (+24dBV) signal levels. -
Page 6: Digital Flanger
ADA 2FX owners manual version 1 counterpoint or a background rhythm in the REPEAT HOLD mode. When your DIGITAL MULTI-EFFECTS is initially powered up, an internal protection circuit defeats the REPEAT HOLD function to prevent "howling." 3.4 DIGITAL FLANGER (A) The DIGITAL FLANGER section uses a triangle wave for its sweep waveform and offers delay times within the range of 0.5ms to 5ms for crisp, biting flange effects. -
Page 7: Remote Functions
ADA 2FX owners manual version 1 4.0 REMOTE FUNCTIONS The DM-2 CONTROLLER is a remote footswitch that accesses BYPASS, FLANGER, CHORUS, DIGITAL DELAY and REPEAT HOLD. When in the BYPASS mode, the MEMORY BYPASS™ function "remembers" the last combination of effects used. For example, this feature allows you to set-up a chorus/echo patch, enter the BYPASS mode, then turn-on chorus/echo patch with one tap of the MEMORY BYPASS™... -
Page 8: Repeat Hold
ADA 2FX owners manual version 1 FIGURE 5-5 REPEAT HOLD This captures, stores, and repeats a segment of sound without signal degradation. The pitch and repeat rate may be modified by using the MULTIPLIER control. Many useful special effects can be produced by varying the DEPTH and RATE controls. -
Page 9: Specifications
(5) If the unit is under warranty, ADA will perform the servicing and pay the return shipping charges to you. (6) If the unit is not under warranty, ADA will bill you for the servicing and return shipping charges. We require payment in advance or cash on delivery (COD) for these charges. -
Page 10: Blank Patch Sheets
ADA 2FX owners manual version 1 8.0 BLANK PATCH SHEET Notes: Notes: Notes: Notes: Notes: Notes: Page 10 of 10...
