WARNING • Dangerously high voltages are present inside the TV. • TV operating voltage: 110 – 240 V AC. • Do not plug in the power cord until you have completed making all other connections; otherwise a minimum leakage current might flow through the antenna and other terminals to ground.
Table of Contents Getting Started ....................... 4 Setting up your TV (“Initial Setup”) ................5 TV top control, front and rear panels ................. 7 Connecting optional components ................8 Using the remote control and basic functions ............10 Introducing the WEGA GATE navigator ..............12 “Settings”...
x Getting Started Step 1 Insert the batteries (supplied) into the remote. Note • Do not use old or different types of batteries together. Step 2 Connect the antenna cable (not supplied) to 8 (antenna input) at the rear of the TV. •...
x Setting up your TV (“Initial Setup”) When you turn on your TV for the first time, the “Initial Setup” menu will appear. You may change the menu language, preset the TV channels automatically and sort or edit the channels using the buttons on the remote control or TV top control panel.
Page 6
Setting up your TV (“Initial Setup”) (continued) d) If you wish to edit the channels, press to change to edit mode. Press b until the mode that you wish to edit is highlighted: Label, Skip, (block symbol). Then press 1) To label, press V or v to select the alphanumeric characters for the label.
x TV top control, front and rear panels TV top control panel WEGA GATE PROG SOUND MODE TV rear panel KV-BZ21M40/BZ21P40/ KV-BZ21M50 BZ14M40/BZ14P40 (MONO) (MONO) (MONO) (MONO) TV front panel KV-BZ21M40/BZ21P40/BZ14M40/BZ14P40 KV-BZ21M50 (MONO) (MONO) (MONO) Button/Terminal Function Page Turn off or turn on the TV. Remote control sensor.
x Connecting optional components Connecting to the video input terminal ( t ) TV front panel KV-BZ21M50 KV-BZ21M40/ BZ21P40/BZ14M40/ BZ14P40* Audio/Video cable (not supplied) L(MONO)— —R (MONO)— —(MONO) Camcorder TV rear panel KV-BZ21M50 KV-BZ21M40/ BZ21P40/BZ14M40/ BZ14P40* Antenna cable (not supplied) (MONO) Audio/Video cable (MONO)
Page 9
Connecting to the component video input terminal ( KV-BZ21M50 only TV rear panel Component video cable (not supplied) (MONO) (MONO) DVD player Audio cable (not supplied) Notes • If your DVD player can output interlace and progressive mode signals, select the interlace output when connecting to (component video input) on your TV.
x Using the remote control and basic functions Button Description Page 1 ?/1 Turn off temporarily or turn on – the TV. Display the TV program. – Jump to last program number – that has been watched for at least five seconds. PROG +/–...
Page 11
Button Description Page WEGA GATE menu operations Confirm selected items. WEGA GATE Display or cancel WEGA GATE menu. V, v, B, b Select and adjust items. RETURN Return to the previous level. Timer operations Set TV to turn on automatically according to the –...
x Introducing the WEGA GATE navigator WEGA GATE is a gateway that allows you to access to preset TV channels, connected external inputs and “Settings” menu. WEGA GATE External Inputs “TV” watch the preset TV Settings channels (see page 5) Select Confirm Select...
x “Settings” Adjustment You are able to change the settings of your TV from “Settings” in WEGA GATE menu. Press WEGA GATE button to display WEGA GATE menu. Press V or v to select “Settings” and press The following is an overview of the items that can be adjusted. ”Picture”...
x Changing the “Picture” setting The “Picture” menu allows you to adjust the picture settings. Press WEGA GATE and select “Settings”. Make sure the “Picture” icon ( ) is selected, then press Press V or v to select the desired item (e.g., “Picture Mode”), then press Select “Picture Mode”...
x Changing the “Sound” setting The “Sound” menu allows you to adjust the sound settings. Press WEGA GATE and select “Settings”. Press V or v to select the “Sound” icon ( ), then press Press V or v to select the desired item (e.g., “Sound Mode”), then press Select “Sound Mode”...
x Changing the “Channel Setup” setting The “Channel Setup” menu allows you to preset channels automatically, manually preset channels and sort or edit the channels. Press WEGA GATE and select “Settings”. Press V or v to select the “Channel Setup” icon ( ), then press Press V or v to select the desired item (e.g., “Auto Program”), then press Select...
Page 17
Presetting channels manually After selecting “Manual Program”, select the program number to which you want to preset a channel. (1) Make sure “Program” is selected, then press (2) Press V or v until the program number you want to preset appears on the menu, then press Select Confirm Select the desired channel.
x Changing the “Setup” setting The “Setup” menu allows you to change the menu language, label the connected equipment, select the color system, set the wake up timer beep and reset your TV to factory settings. Press WEGA GATE and select “Settings”. Press V or v to select the “Setup”...
• Check the antenna cable and connection on the TV, VCR and at the wall noisy sound (see page 8). • Check the antenna setup. Contact a Sony dealer for advice. • Display the “Channel Setup” menu and select “Manual Program” to preset the channel again (see page 17).
Page 20
TV for about 15 minutes, then turn it on again to demagnetize the TV. • Count the number of times the 1 (standby) indicator flashes. The 1 (standby) Press ! (main power) to turn off your TV. Contact your nearest Sony indicator on your TV flashes red service center.
x 調整“声音设定” “声音设定”菜單可使您調整音響設定。 按壓 WEGA GATE 鍵並選擇“设定”。 按壓 V 或 v 鍵以選擇“声音设定”符號 ( )﹐然後按壓 鍵。 按壓 V 或 v 鍵以選擇所要的項目 (例如﹐“声音模式”)﹐然後按壓 鍵。 選擇 以 “声音模式” 選擇“动态”(低和高音調)、“标准”(人聲和高音調)或“用户 (僅於 KV-BZ21M50)设定”*。 “平衡” 按壓 v 或 B 鍵以強調左揚聲器。 (僅於 KV-BZ21M50)按壓 V 或 b 鍵以強調右揚聲器。 “智能音量控制”...
Page 36
手動預設頻道 在選擇“手动调台”之後﹐選擇您要預設頻道 的頻道號碼。 (1)確認“频道”已被選定﹐然後按壓 鍵。 (2)按壓 V 或 v 鍵直到您要預設的頻道號碼 顯示在菜單上﹐然後按壓 鍵。 選擇所要的頻道。 (1)確認“VHF 低”、“VHF 高”或“UHF”已被選定﹐然後按壓 鍵。 (2)按壓 V 或 v 鍵直到您所要的頻道顯示在電視屏幕上﹐然後按壓 鍵。 若所要頻道的聲音失真﹐則請選擇適當的電視系統(僅於 KV-BZ21M50/ BZ21M40/BZ14M40)。 (1)按壓 V 或 v 鍵以選擇“电视系统”﹐然後按壓 鍵。 (2)按壓 V 或 v 鍵直到聲音正常為止﹐然後按壓 鍵。 若您不滿意圖像和聲音質量﹐您可用“微调”來改善它。 (1)按壓 V 或 v 鍵以選擇“微调”﹐然後按壓 鍵。...
x Specifications KV-BZ21M50 KV-BZ14M40 Note KV-BZ21M40 KV-BZ14P40 KV-BZ21P40 Power requirements 110-240 V AC, 50/60 Hz Power consumption (W) Indicated on the rear of the TV Television system B/G, I, D/K, M KV-BZ21P40/ BZ14P40 only PAL, PAL 60, SECAM, NTSC3.58, NTSC4.43 Color system PAL, PAL 60, NTSC3.58 (AV IN), NTSC4.43 KV-BZ21P40/...
