Inaxsys IVTVision Quick Start Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

This document is supplemental to the quick start guide and software user manual software user manual shipped with your
system.
This document describes the camera configuration software provided by major IP camera manufacturers for use prior to
configuring your IVTVision system. For additional information, please consult with the camera manufacturer's software
instructions.
Most systems can be installed with the following steps:
Install the servers as shown in the IVTVision Quick Start Guides.
1.
Confirm the camera has the correct firmware version at: http://www.inaxsys.com/ip-cameras-integration-s135/.
2.
3.
Configure the cameras with a fixed IP address as shown in this document.
4.
Test camera-to-server communications by browsing to the camera from the server.
Configure your IVTVision server as shown in the user manual.
5.
Consult the Inaxsys Knowledge Base at
6.
Each IP camera manufacturer provides a utility to find cameras on the local network and set their IP addresses. This utility is
typically available on the software CD shipped with your camera, or from the camera manufacturer's web site. Please refer
to the documentation provided by your camera's manufacturer if you have questions after reading this guide.

Supported Manufacturers:

1.
2.
3.
4.
5.
6.
7.
8.
9.
NOTE: This manual does not discuss cameras interfacing with ONVIF or RTSP protocols. See Chapter 4 of the user manual
for additional information on configuration of these cameras.
IVTVision IP Camera Quickstart Guide
http://www.inaxsys.com/knowledge-base-s156/
www.inaxsys.com
for additional information.
Page 1 of 17
7/15/2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IVTVision and is the answer not in the manual?

Questions and answers

Related Manuals for Inaxsys IVTVision

Summary of Contents for Inaxsys IVTVision

  • Page 1 This document describes the camera configuration software provided by major IP camera manufacturers for use prior to configuring your IVTVision system. For additional information, please consult with the camera manufacturer’s software instructions. Most systems can be installed with the following steps: Install the servers as shown in the IVTVision Quick Start Guides.
  • Page 2 IP cameras to keep unexpected network events from changing the IP address of the camera. If the camera’s IP address changes, the IVTVision Server cannot receive or record video from that camera until a user manually reassigns the camera’s IP address or changes the address setting on the IVTVision server to match the camera’s new address.
  • Page 3 The utility finds all cameras on the network. Select the Manufacturer filter and enter Dynamics to list only American Dynamics cameras. To view current IP address, firmware, serial number, and MAC address information for a camera, select it in the list and click Device Properties to open the following window: www.inaxsys.com Page 3 of 17 7/15/2014...
  • Page 4 You can also right-click the camera in the list to select Upgrade Firmware or to select Launch Camera Web GUI for additional camera configuration parameters: NOTE: The factory default login for the American Dynamics cameras is:  username: admin  password: admin www.inaxsys.com Page 4 of 17 7/15/2014...
  • Page 5 After you enter the IP address and subnet mask entered, click Apply and Save & Reboot. NOTE: The factory default login for ACTi IP cameras is: username: admin   password: 123456 You will need the username and password when you add this camera to your IVTVision system. www.inaxsys.com Page 5 of 17 7/15/2014...
  • Page 6 Enter the IP Address in the New Camera IP field. Click Set IP to set the IP address. To configure additional information for the camera, go to the camera’s web page. www.inaxsys.com Page 6 of 17 7/15/2014...
  • Page 7 Enter the IP address, subnet mask, and default router. Click OK to apply the IP address. NOTE: The factory default login for Axis IP cameras is:  username: root  password: pass You will need the username and password when you add this camera to your IVTVision system. www.inaxsys.com Page 7 of 17 7/15/2014...
  • Page 8 All Ganz IP cameras on the local subnet are listed in the Camera List section. Select a camera to display information in the Camera Info area. www.inaxsys.com Page 8 of 17 7/15/2014...
  • Page 9 Set IP Address. NOTE: The factory default login for Ganz devices is:  username: admin  password: admin You will need the username and password when you add this camera to your IVTVision system. www.inaxsys.com Page 9 of 17 7/15/2014...
  • Page 10  password: system You will need the username and password when you add this camera to your IVTVision system. To get the IQinVision camera to factory defaults, hold the reset button in while powering on the camera. www.inaxsys.com...
  • Page 11 IP address that is not used by any other device on your local network, ensuring that the first three numbers match the first three numbers of your IVTVision Server’s IP address. Set the net mask to 255.255.255.0, leave the HTTP port at 80, enter the camera’s Administrator name and password, and click Apply.
  • Page 12 To change the IP address, select Off next to DHCP and type the address. Click Save when finished. NOTE: The factory default login for Pelco cameras is:  username: admin  password: admin You will need the username and password when you add this camera to your IVTVision system. www.inaxsys.com Page 12 of 17 7/15/2014...
  • Page 13 Click OK to apply the new settings. NOTE: The factory default login for Samsung IP cameras is:  username: admin  password: 4321 You will need the username and password when you add this camera to your IVTVision system. www.inaxsys.com Page 13 of 17 7/15/2014...
  • Page 14 IP address. Enter an IP address that is not used by any other device on your local network, ensuring that the first three numbers match the first three numbers of your IVTVision Server’s IP address. Set the subnet to 255.255.255.0, leave the HTTP port at 80, enter the camera’s Administrator name and password, and click Apply.
  • Page 15 Vivotek provides an Installation Wizard utility to find IP cameras. This is provided on the CD included in the box with the camera. Run the utility to display the following window: This detects and displays your type of network. Click Next to continue. www.inaxsys.com Page 15 of 17 7/15/2014...
  • Page 16 Enter the root password for the Vivotek camera. If you have not set up the camera previously, the default password is blank. Enter in the new root password and keep the default Date/Time settings. Click Next. www.inaxsys.com Page 16 of 17...
  • Page 17 IP by DHCP Server Automatically if necessary. Click Next to continue. Use the default ports. Do not select Enable DDNS unless you are planning to put this camera on the Internet. This is not recommended. Click Next to complete the configuration. www.inaxsys.com Page 17 of 17 7/15/2014...
