- Page 1 Xtra Fun II 230 A s s e m b l y m a n u a l Specifications: Wingspan: 90.5in Length: 92.5in Weight: 17.6 - 18.7lb Engine: 3W 55i Radio: four Channel Type: Aerobatic / 3D 3W-Modellmotoren GmbH...
- Page 2 Xtra Fun II 230 Welcome Dear model airplane pilot, we are pleased with your decision for our new After we submitting the prototypes, detailed Xtra Fun II. The Xtra Fun II is a consistent tests had been done. We are happy presenting advancement of the predecessor model.
- Page 3 Xtra Fun II 230 Index Kit content.................... 4 Combo version content................. 5 Required radio, engine ................ 6 Assembling Teil 1: Landing gear................. 7 Teil 2: Insert hinges................9 Teil 3: Tail unit ..................10 Teil 4: Wings..................10 Teil 5: Engine installation ..............11 Teil 6: Cowling and Canopy..
- Page 4 Xtra Fun II 230 Kit contentt Parts list: • Fuselage • Rudder • Elevator le / ri, tube, protection bag • Wings le / ri, tube, protection bag • Canopy • Cowling • Landing gear • Wheel cover • Tail wheel assembly •...
- Page 5 Xtra Fun II 230 Content combo version Additionally to the standard design the Combo version contains : • Engine 3w 55i incl. ignition, • Carburetor, Exhaust sealing and manual • muffler - size L • exhaust manifold - S shaped •...
-
Page 6: Required Parts
Xtra Fun II 230 required parts Additionally to the parts contained in the component system you need: RC Components: • Receiver / five channels • 4 x servo aileron 2 x 8 kg / metal gear • 2 x servo elevator 2 x 11kg / metal gear •... -
Page 7: Landing Gear
Xtra Fun II 230 Landing gear Landing gear Glue aluminum parts in the wheel shoe with UHU Fasten the main landing gear with enclosed PLUS. Check the position of the wheel pants screw and washers to the fuselage. before. The wheel fits exactly without tension rings between the two aluminum parts. - Page 8 Xtra Fun II 230 Landing gear File a notch into the steel wire, in order to ensure a safe seat of the screw for linking the tail wheel.. Attach the provided tension ring M3 and adjust the tail wheel in such a way that it can be moved freely each position.
- Page 9 Xtra Fun II 230 Landing gear / Hinges With the two screws M4 x 18 and washers the gear is fastened to the fuselage. Glue hinges Use PVA as adhesive. Sand hinges before glueing with rough sandpaper on both sides.
- Page 10 Xtra Fun II 230 Tail Unit / Wings Tail Unit Servo installation rudder and elevator right. Fasten the rudder horns in such a way that they form an alignment with the servo lever. Wings Bond the hinges as into part III. Focus on absolute accurate alignment.
- Page 11 Xtra Fun II 230 Engine / Muffler Engine and Muffler Use circlips for fixing exhaust manifold. Screw engine with 4 screws M5 x 25 to the Motordom. Use screw locking medium strong. Afterwards the flexible muffler mounting is Make connection between exhaust manifold and installed.
- Page 12 Xtra Fun II 230 Cowling / canopy Cowling Glue provided wood parts at the head frame. Fix the cowling accurately on the fuselage with adhesive tape. Measure boreholes and bore with drill 2.5 mm. Pay attention to sufficient distance between Cut cylinder opening into cowling.
- Page 13 Xtra Fun II 230 RC system / CG RC system / center of gravityt Before fixing the remaining RC and ignition parts, place the components in the fuselage for a test, in order to get the correct CG. ATTENTION: For placing the components take care on your engine and ignition manual...
-
Page 14: Flight Preperation
Xtra Fun II 230 Flight preperation Programming RC We recommend the use of a modern computer system. Here we recommend the following order of programming to you: Servo directions • Elevator highly - pull / down - press • Rudder right - left •... - Page 15 Xtra Fun II 230 Flight preperation Check before maidenflight: Fly with your Xtra Fun II / Security advise: • Let an experienced model builder verify • Fly only in registered model airfields with flight assembly, attitudes and center of gravity..
- Page 16 Xtra Fun II 230 Guarantee Guarantee conditions We grant a two year warranty on our flight models. This warranty is limited to construction and/or production defects like e.g. incorrect material or glueings, because a monitoring of accurate assembly, enterprise and maintenance of the model is not possible.
