Instruction for Use
miniBar
RH 430 LD
RH 438 LD
RH 440 LD(G)
RH 441 LD
RH 448 LD
RH 460 LD
RH 461 LDG
RH 468 LD
DE
INSTRUCTION FOR USE / INSTALLATION INSTRUCTION
Type HC20 / 60
821 2693 -61
RH 436 D
RH 438 D
RH 447 D
RH 448 D
RH 468 D
RH 455 LD
RH 456 LD
RH 456 LDE
article number 568.15.313, 568.15.402, 568.15.561
ABSORPTION - REFRIGERATOR
T.B. MB 03/2006
English
Advertisement
Table of Contents
Related Manuals for Hafele RH 430 LD
Summary of Contents for Hafele RH 430 LD
-
Page 1: Instruction For Use
568.15.313, 568.15.402, 568.15.561 Instruction for Use miniBar RH 436 D RH 430 LD RH 438 D RH 438 LD RH 447 D RH 440 LD(G) RH 448 D RH 441 LD RH 468 D RH 448 LD RH 455 LD... -
Page 2: Table Of Contents
INTRODUCTION FOR YOUR SAFETY 2.1 Warnings and Safety Advice 2.2 Coolants WARRANTY AND CUSTOMER SERVICE INSTALLATION 4.1 The Purpose of this Manual 4.2 Tools/Materials Required 4.3 Unpacking 4.4 Cleaning 4.5 Installation 4.6 Securing 4.7 Connecting the Device to the Electricity Supply 4.8 Changing the Sliding Hinge 4.9 Changing the Doorhang INSTRUCTION FOR USE... -
Page 3: Introduction
INTRODUCTION You have made an excellent choice by choosing the Dometic miniBar. We are convinced that you will be satisfied with your new appliance in every way. Silent in operation, the miniBar fulfils high quality standards and guarantees an efficient use of resources and energy during its entire working life, i.e. during manufacturing, use and disposal. -
Page 4: Installation
INSTALLATION The Purpose of this Manual The manual shows you how to: install the miniBar correctly. operate the miniBar correctly. guarantee the miniBar´s correct maintenance and functioning. deal with faults by yourself. Tools / Materials Required You will need the following tools for initial operation: mild detergent Unpacking Check during unpacking that the device is defect-free. -
Page 5: Installation
Installation 200 cm² 20 mm IMPORTANT: Please follow the installation details below carefully. Guarantee is valid for products installed as described only. 1. The refrigerator must be level both directions 2. There sould be 20mm clearance to the wall 3. Ventilation must be provided as shown in alternatives A,B,C or D 4. -
Page 6: Securing
Securing 4.6.1 RH456LD/E 1. Tighten screw. 2. Put on cap. 4.6.2 RH430LD, RH440LD(G), RH441LD, RH460LD, RH461LDG RH436D, RH447D, RH438(L)D, RH448(L)D,RH468(L)D The miniBar must be screwed onto the cupboard using the lower hinges. 1. Tighten screw. 2. Put on cap. -
Page 7: Connecting The Device To The Electricity Supply
Connecting the Device to the Electricity Supply The device must be connected to a properly earthed socket in line with the relevant valid country regulations. Check prior to initial operation that the voltage noted on the model label corresponds to the mains voltage. -
Page 8: Changing The Sliding Hinge
If the plug supplied on the mains lead is not suitable for the socket in your home, it should be cut off and disposed of safely, or destroyed, to avoid any possible shock hazard resulting from the plug being inserted into a 13 amp socket elswhere in the use. -
Page 9: Changing The Doorhang
Changing the Doorhang ( RH436D, RH447D, RH430LD, RH440LD(G), RH441LD, RH460LD, RH461LDG, RH438LD, RH448LD,RH468LD) -
Page 10: Instruction For Use
INSTRUCTION FOR USE Initial Operation The device must be plugged into a properly earthed socket. The miniBar achieves its operating temperature after several hours. The miniBar operates silently ! Temperature Control The miniBar is fitted with an electronic temperature control. The thermostat control min. -
Page 11: Automatic Door Control (Adc)
Automatic Door Control (ADC) The following descriptions only apply to devices with ADC. Using a red dot in the display window (A, point 3), the ADC shows that the miniBar´s door has been opened. 1. Open the miniBar, check its contents and - if applicable- stock it up again. -
Page 12: Interior Light
Interior Light 5.6.1 RH456LD /E Model RH456LD/E is fitted with low voltage lighting. When the door is opened, the light in the cooling shelf is switched on via a sensor. The light in the uncooled storage shelf is switched on manually by means of a switch integrated into the lamp. -
Page 13: Environmental Advice
Environmental Advice miniBars manufactured by Dometic GmbH are free from CFCs / HCFCs and fluorinated hydrocarbons. The cooling unit uses ammonia as the coo lant (a natural compound of hydrogen and nitrogen). Cyclopentane, which does not damage the ozone layer, is used as propellant for the insulation made from PU-foam. -
Page 14: Check List
5.11 Check List Failure : No cooling (the aggregate at the back of the device is cold). Possible Cause Self Help Authorised Service a.) The thermostat is set to “0”. a.) Set temperature control to middle position. b.) The device plug is not b.) Plug in device plug. -
Page 15: Technical Data
5.12 Technical Data Model RH430/438LD RH440/448LD RH441LD RH455LD Built-in Built-in Freestanding / Freestanding Built-in Casing Metal Metal Metal Wood Gross Contentss (litres) cooled / uncooled 30 / - 40 / - 40 / - 35 / 20 Dimensions (mm) (H x W xD) 522x384x412 554x401x446 554x401x449...
