SERVICE MANUAL
MODEL
COMMANDER DEST.
KP-EF61HK2
RM-871
KP-EF61ME2
RM-871
KP-EF61MN2
RM-871
KP-EF61SN2
RM-871
MICROFILM
∗ Please file according to model size. ...
61
CHASSIS NO.
MODEL
HK
SCC-N71F-A
ME
SCC-N72F-A
GE
SCC-N69F-A
AUS
SCC-N73F-A
RG-2
CHASSIS
COMMANDER DEST.
CHASSIS NO.
PROJECTION TV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KP-EF61HK2 and is the answer not in the manual?

Questions and answers

Related Manuals for Sony KP-EF61HK2

Summary of Contents for Sony KP-EF61HK2

  • Page 1 SERVICE MANUAL RG-2 CHASSIS MODEL COMMANDER DEST. CHASSIS NO. MODEL COMMANDER DEST. CHASSIS NO. KP-EF61HK2 RM-871 SCC-N71F-A KP-EF61ME2 RM-871 SCC-N72F-A KP-EF61MN2 RM-871 SCC-N69F-A KP-EF61SN2 RM-871 SCC-N73F-A PROJECTION TV MICROFILM ∗ Please file according to model size..
  • Page 2 VIEWS AND IN THE PARTS LIST ARE CRITICAL TO REMOVING THE ANODE. SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS AP- PEAR AS SHOWN IN THIS MANUAL OR IN SUPPLE- MENTS PUBLISHED BY SONY. – 2 –...

  • Page 3: Table Of Contents

    KP-EF61HK2/ME2/MN2/SN2 RM-871 TABLE OF CONTENTS Section Title Page Section Title Page 1. GENERAL ..............6-1. Block Diagrams ..........6-2. Frame Schematic Diagram ......... 2. DISASSEMBLY 6-3. Circuit Boards Location ........2-1. Rear Board Removal ......... 6-4. Schematic Diagrams and Printed Wiring 2-2.

  • Page 4: General

    SECTION1 The operating instructions mentioned here are partial abstracts from the Operating Instruction Manual. The page numbers of GENERAL the Operating Instruction Manual remain as in the manual. Getting Started Front of TV Connections Camcorder (S video input) to S video output (MONO) to video and audio outputs...
  • Page 5 Connecting a DVD player Connecting an amplifier with Dolby* Pro Logic decoder DVD player * Manufactured under license from Dolby Laboratories Rear of TV Even though you use an amplifier with Dolby Pro Logic Licensing Corporation. decoder instead of the projection TV’s audio system, you DOLBY, the double-D symbol a and “PRO LOGIC”...

  • Page 6: Installing The Projection Tv

    Installing the Getting to know the projection TV remote commander Names/symbols of buttons on the remote commander are indicated in different colors to represent the available For the best picture quality, install the projection TV functions. within the areas shown below. Label color Button function Optimum viewing area (Horizontal)

  • Page 7: Introducing The Menu System

    Press V or v to move the cursor (z) to the Introducing the Changing the menu PRESET menu ( ), and press ENTER. menu system language PRES E T L A NGUAGE / ENGL I SH ENTER ENTER AUTO PROGRAM MANUA L PROGRAM T V S Y S : B / G COL SYS : AUTO...
  • Page 8 • If you do not know your local TV system, consult your nearest L ANGUAGE / ENGL I SH ENTER ENTER Sony dealer or authorized service center. AUTO PROGRAM MANUA L PROGRAM AUTO PROGRAM T V SYS : B / G...

  • Page 9: Adjusting The Convergence

    Press V or v to move the cursor (z) to Disabling program positions Presetting the volume level for Adjusting the CONVERGENCE and press ENTER. individual programs The CONVERGENCE adjustment screen appears. By disabling unused or unwanted program positions, convergence you can skip those positions when you press PROGR If the volume of the selected program is louder than +/–.
  • Page 10 Operations To scan through program positions Watching the TV Watching the video input Displaying the on-screen information Press PROGR +/– on the remote commander or the TV until the program position you want appears. Press … on the remote commander or … on Press the TV.

  • Page 11: Adjusting The Picture And Sound

    If the picture is slightly snowy Press V/b/v/B to adjust the selected item, Adjusting the Adjusting the picture settings You may try to improve the picture by changing the and press ENTER. (VIDEO ADJUST) VM setting as described below: picture and sound For details on each item, see “Description of adjustable You can adjust the picture settings to suit your taste Display the VIDEO ADJUST menu.

  • Page 12: Hyper Surround

    SRS (SOUND RETRIEVAL SYSTEM) is manufactured TREBLE ENTER ENTER BA L ANCE by Sony Corporation under license from SRS Labs, Inc. It is SPEAKER: Press MENU. MAIN covered by U.S. Patent No. 4,748,669. The word “SRS” and the SRS symbol (r) are registered...
  • Page 13 Receiving area for NICAM and A2 (German) To restore the normal screen Selecting a stereo or Viewing multiple programs Press PROGR INDEX again or You can also select PROGR INDEX or PIP : OFF from System Receiving area bilingual program programs at the the PIP menu, and press ENTER to restore the normal NICAM...
  • Page 14 Displaying frame- Using the Picture-in- Changing the position of the PIP screen Swapping pictures between the main and PIP screens by-frame pictures Picture (PIP) MENU Press (STROBE) features ENTER Press MENU. You can watch a slow motion movement of the main With the Picture-in-Picture (PIP) feature, you can screen picture which is displayed frame-by-frame on display a sub screen within the main picture of...

  • Page 15: Viewing Teletext

    Viewing Teletext Checking the contents of a Teletext Revealing concealed information service (INDEX) (REVEAL) Press to display an overview of the Teletext The REVEAL option lets you disclose concealed contents and page numbers. information, such as an answer to a quiz that you find on some of the Teletext pages.

  • Page 16: Game Mode

    To restore the normal picture and sound To display a Teletext page on the PIP screen Displaying Teletext Viewing a video modes using the menu Press ;, … , or PROGR +/–. on the PIP screen game screen MENU Notes (PIP TEXT) (GAME MODE) •...

  • Page 17: Troubleshooting

    If the problem persists, contact your nearest Sony You can select the output signal from the Ú (monitor/ dealer or authorized service center. TV output) jacks at the rear of the TV. However, the / Press u.

  • Page 18: Disassembly

    KP-EF61HK2/ME2/MN2/SN2 RM-871 SECTION 2 DISASSEMBLY 2-1. REAR BOARD REMOVAL 2-3. SERVICE POSITION 4 Rear board 1 Four screws (Hexagon head) Main bracket section 3 Purse lock 2 Eight screws (Hexagon head) 2-2. MAIN BRACKET SECTION REMOVAL 1 Light interception plate...

  • Page 19: H1 Board, H2 Board, H3 Board And Resistor (Focus Pack) Removal

    KP-EF61HK2/ME2/MN2/SN2 RM-871 2-4. H1 BOARD, H2 BOARD, H3 BOARD AND RESISTOR (FOCUS Pack) REMOVAL 1 Speaker grille 4 Two screws (BVTP 4X16) 5 Bracket(HA) 6 H1 board 3 Control panel assy 2 Four screws (Hxagon head) !ª Resistor 9 Four screws...

  • Page 20: G Board Removal

    KP-EF61HK2/ME2/MN2/SN2 RM-871 2-6. G BOARD REMOVAL 2-7. P1 BOARD AND V2 BOARD REMOVAL 1 Three holders PWB 3 Two claws 1 Two claws 4 V2 board 2 P1 board 2 G Board 2-8. UG BOARD, AG BOARD AND S BOARD REMOVAL...

  • Page 21: High-Voltage Cable Installation And Removal

    KP-EF61HK2/ME2/MN2/SN2 RM-871 2-9. HIGH-VOLTAGE CABLE INSTALLATION AND REMOVAL (1) Remover (2) Installation 2 Rubber cap 1 HV cable 1 Rubber cap Hook 2 HV cable turn 90° Gutter 2-10. MECHASEAL ASSY REMOVAL Removing the arrow-marked screw is strictly inhibited. If removed, it may cause liquid spill.

  • Page 22: Chassis Block Removal

    KP-EF61HK2/ME2/MN2/SN2 RM-871 2-11. CHASSIS BLOCK REMOVAL (1) MAIN BRACKET REMOVAL * Pay particular attention to the wires of each PCB when pulling out the main bracket. 1 Two screws (Hexagon head) 3 Set the main bracket. 2 Pull the main bracket.

  • Page 23: Set-Up Adjustments

    KP-EF61HK2/ME2/MN2/SN2 RM-871 SECTION 3 SET-UP ADJUSTMENTS 3-1. SCREEN VOLTAGE ADJUSTMENT KR, KG, KB (ROUGH ALIGNMENT) 5.6K/3W X3 1. Receive the Monoscope signal. 2. Set 50% BRIGHTNESS and minimum PICTURE. 3. Turn the red VR on the FOCUS Pack (Fig. 3-1) all the way to the left and then gradually turn it to the right until the point where you can see the retrace line.

  • Page 24: 2-Pole Magnet Adjustment

    KP-EF61HK2/ME2/MN2/SN2 RM-871 3-8. GREEN AND RED FOCUS ADJUSTMENT 3-5. 2-POLE MAGNET ADJUSTMENT 3-8-1. Green and Red Lens Focus Adjustment 1. Set in service mode. 2. Set to receive the Dot signal. 1) Input a monoscope signal. 3. Place the caps on the red and blue lens so that only the green 2) Place a lens cover over Red and Blue lenses and project only color is shown.

  • Page 25: Safety Related Adjustment

    KP-EF61HK2/ME2/MN2/SN2 RM-871 SECTION 4 SAFETY RELATED ADJUSTMENT When replacing the following components marked with E BOARD – CONDUCTOR SIDE – on the schematic diagram, always check hold-down volt- CN810 age and if necessary re-adjust. CN505 Part Replaced ( ) Part Replaced ( ) E Board C515, C516, C554, D504, D507, Fig.

  • Page 26: Circuit Adjustments

    KP-EF61HK2/ME2/MN2/SN2 RM-871 SECTION 5 CIRCUIT ADJUSTMENTS 5-1. ADJUSTMENTS WITH COMMANDER 1, 4 Select the adjustment item. Service adjustments are made with the RM-871 that comes with ↓ this unit. 3, 6 Raise/lower the data value. ↓ Entering service mode MUTING Writes.

  • Page 27: Adjustment Method

    KP-EF61HK2/ME2/MN2/SN2 RM-871 Use the same method for Items Number 00-99. Use 1 and 4 5-2. ADJUSTMENT METHOD to select the adjustment item, use 3 and 6 to adjust, write with Item Number 00 MUTING , then execute the write with -.
  • Page 28 KP-EF61HK2/ME2/MN2/SN2 RM-871 Adjustment Item Table Item Data Register Device Display Item Range Values Name 00~3F V POSITION CXA2050S 00~3F V SIZE 00~0F H POSITION 00~3F H SIZE 00~0F S CORRECTION 00~0F V LINEARITY 00~3F PIN COMP 00~0F PIN PHASE 00~0F...
  • Page 29 KP-EF61HK2/ME2/MN2/SN2 RM-871 Item Data Register Device Display Item Range Values Name –127~+127 KEYSTONE SSKW –127~+127 SUB SKEW RH10 MPIN –127~+127 MID PINCUSION RH11 –127~+127 –10 PINCUSION RH12 SBOW –127~+127 SUB BOW RH13 MBOW –127~+127 MID BOW RH14 4PIN –127~+127 4th PINCUSION...
  • Page 30 KP-EF61HK2/ME2/MN2/SN2 RM-871 Item Data Register Device Display Item Range Values Name ACV2 ATIM 0-255 SAMPLE START TIME (LSR) ACV3 ATIB 0-255 SAMPLE START TIME (BOT) ACV4 AH51 0-255 OSD H POS 50 (L & R) ACV5 AH52 0-255 OSD H POS 50 (UP & BOTTOM)
  • Page 31 KP-EF61HK2/ME2/MN2/SN2 RM-871 Item Data Register Device Display Item Range Values Name 00~01 DYNAMIC COLOR 00~03 GAMMA 00~01 DC-TRANSIENT 00~07 DELAY CTRL(PAL) 00~07 DELAY CTRL(NTSC) 00~07 DELAY CTRL(SECAM) 00~07 DELAY AT DVD(50Hz) 00~07 DELAY AT DVD(60Hz) 00~0F SUB-CONTRAST 00~0F SUB-COLOR(OTHER) 00~0F...
  • Page 32 KP-EF61HK2/ME2/MN2/SN2 RM-871 Item Data Register Device Display Item Range Values Name 00~3F CORING 00~3F DSC OFFSET 00~3F DSC GAIN 00~01 DELAY TIME 00~0F SEL PIN DELAY SDA9189X 00~FF H POSITION(MSB 8bit) 00~FF V POSITION 00~1F HSI DELAY 00~01 DECIMATION FILTER...
  • Page 33 KP-EF61HK2/ME2/MN2/SN2 RM-871 Item Data Register Device Display Item Range Values Name 00~07 USER SET UP 00~01 D/K STEREO SEARCH 00~01 NO SYNC MUTE 00~01 DISABLE DEGAUSS 00~01 DISABLE WIDEZOOM 00~01 BASS CENTER SHIFT 00~01 BASS VOLUME SHIFT 00~03 WOOFER OFF BASS SHIFT...

  • Page 34: Registration (Convergence)Adjustment Method

    KP-EF61HK2/ME2/MN2/SN2 RM-871 MAIN DEFLECTION ADJUSTMENT 5-4. REGISTRATION (CONVERGENCE) 1) Adjust VSP V-Lin. ADJUSTMENT METHOD Correct linearity of the horizontal top and bottom lines. PAL REGISTRATION ADJUSTMENT VSP VLINE 1) Receive the PAL SPCB signal. 2) Select Service mode and enter adjustment items for Green signal.
  • Page 35 KP-EF61HK2/ME2/MN2/SN2 RM-871 SUB DEFLECTION ADJUSTMENT ITEM VERTICAL LINE ADJUSTMENT Adjustment O : Yes – : No 1. Carefully watching out for the GH CENT screen centre section, adjust GH CENT, GH BOW, GH SKEW. Adjustment type 2. GH 4th Bow adjustment. Correct the corner distortion which...
  • Page 36 KP-EF61HK2/ME2/MN2/SN2 RM-871 HORIZONTAL LINE ADJUSTMENT HORIZONTAL SIZE ADJUSTMENT 1. Finely adjust the centre position of the vertical line at the 1. Adjust with GH MSIZE, so that the sizes of both edges centre of the screen with GV CENT. and centre are equal.
  • Page 37 KP-EF61HK2/ME2/MN2/SN2 RM-871 GREEN VERTICAL SIZE ADJUSTMENT GREEN HORIZONTAL QUATERNARY ADJUSTMENT 1. Adjust GV MSIZE so that the sizes at the top and bottom 1. Adjust GH 4PIN, to correct the 4th order distortion. and centre are equal. 2. Adjust GH 4SBO to balance and correct the 4th order dis- 2.
  • Page 38 KP-EF61HK2/ME2/MN2/SN2 RM-871 GREEN HORIZONTAL SYMMETRICAL PIN GREEN VERTICAL 4TH ORDER DISTORTION DISTORTION ADJUSTMENT ADJUSTMENT 1. Adjust GH MPIN to correct pin distortion at both edges of 1. By using GV 4 PIN, 4th-Order distortion of the horizontal the centre section.

  • Page 39: Auto Convergence Adjustment

    KP-EF61HK2/ME2/MN2/SN2 RM-871 GREEN VERTICAL ASYMMETRICAL PIN DISTORTION GREEN AND BLUE ADJUSTMENT (2ND-ORDER DISTORTION) ADJUSTMENT 1. Adjust so that the blue and green lines are on top of each 1. Correct the asymmetrical pin distortion at the top and bot- other.

  • Page 40: White Balance Adjustment

    KP-EF61HK2/ME2/MN2/SN2 RM-871 5-6. WHITE BALANCE ADJUSTMENT SUB HUE ADJUSTMENT (SH1, SH2) 1. Receive the monoscope signal and adjust the picture qual- 1. Input a PAL color-bar. ity with the menu. 2. Set the following condition: 2. Adjust service mode S-BRIGHT so that the signal 10 IRE PICTURE 90%, BRIGHTNESS 50%, COLOR 50%.

  • Page 41: Block Diagrams

    KP-EF61HK2/ME2/MN2/SN2 KP-EF61HK2/ME2/MN2/SN2 KP-EF61HK2/ME2/MN2/SN2 RM-871 RM-871 RM-871 SECTION 6 DIAGRAMS 6-1. BLOCK DIAGRAMS CN401 SUB VIDEO (SURROUND) IC2201 (U-COM,Y/C JUNGLE,AUDIO PROCESSOR,SECAM DEC) IC301 D/A CONVERTER Y/C/J CN405 S DAT SYNC SEPA TV-SYNC CV IN R OUT RED DRIVE S CLK DAC4...
  • Page 42 KP-EF61HK2/ME2/MN2/SN2 KP-EF61HK2/ME2/MN2/SN2 KP-EF61HK2/ME2/MN2/SN2 RM-871 RM-871 RM-871 CN1405 CN1434 R-H(+) G-H(+) CN1401 CN1432 V.OUT V.IN (DY) R-H(-) G-H(-) V.IN V.OUT CN1461 VM.IN VM.OUT V.DEF VM DRIVE BUFF/AMP V.MID Q1431,1432 Q1433-1436 VM.RET VM.RET V.RET (RED DY) (VM/GREEN DY) CN1705 PJERST AUDIO AMP,V-DEFRECTION,...
  • Page 43 KP-EF61HK2/ME2/MN2/SN2 KP-EF61HK2/ME2/MN2/SN2 RM-871 RM-871 CN3501 TEXT SEL (TEXT) (DVD IN) J2901 GREEN CN2901 TO P1 BOAR BLUE DVD Y IC3501 CN2401 TEXT GENERATOR DVD BY CN3502 R BUFF DVD RY TO P1 BOAR R OUT Q3507 CN2801 X IN X3501...
  • Page 44 KP-EF61HK2/ME2/MN2/SN2 KP-EF61HK2/ME2/MN2/SN2 RM-871 RM-871 (KEY.LED,AC SW) (RED AMP) (GREEN AMP) (BLUE AMP) CN3103 CN3104 AC(L)IN AC(L)OUT RED AMP V901 V902 V903 Q704,703 GREEN AMP BLUE AMP TO G BOARD AU(N)IN PICTURE TUBE PICTURE TUBE Q762,763 PICTURE TUBE S3106 TO G BOARD...

  • Page 45: Frame Schematic Diagram

    6-2. FRAME SCHEMATIC DIAGRAM 6-3. CIRCUIT BOARDS LOCATION R-Y IN S DAT S DAT B-Y IN (SURROUND) S CLK S CLK S SYS1 CN2401 CN2801 Y IN CN2902 CN2004 CN403 CN407 CN1002 S SYS2 WHT-L :S-MICRO :S-MICRO :S-MICRO :S-MICRO :S-MICRO :S-MICRO :S-MICRO R-Y OUT...

  • Page 46: Schematic Diagrams And Printed Wiring Boards

    AUDIO PROCESSOR, µ COM, Y/C JUNGLE, SECAM DEC, PICTURE BOOSTER — AG BOARD (Conductor Side) — — AG BOARD (Component Side) — 6-4. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS • AG BOARD SEMICONDUCTOR LOCATION Terminal name of semiconductors in silk screen Q425 Note: Q426...

  • Page 47: Schematic Diagram Of Ag (1/3) Board

    (1) Schematic Diagram of AG (1/3) Board TU101 BTF-FG441 CN102 :FASTON R101 4.7k :CHIP TO G BOARD C104 CN6009 R102 L101 C101 10µH :CHIP :CHIP C102 R106 C103 CN103 0.01 470p C107 B:CHIP :CHIP CH:CHIP R108 R109 :FASTON R107 6.8k :CHIP :CHIP Q101...

  • Page 48: Schematic Diagram Of Ag (2/3) Board

    (2) Schematic Diagram of AG (2/3) Board CN401 C1001 :S-MICRO C1002 CH:CHIP 100p CH:CHIP R1069 1k :CHIP C1004 100p CH:CHIP R1070 1k :CHIP IC1001 M24C08FM6T C1006 100p CH:CHIP R1071 1k :CHIP C1009 NONVOLA.MEMORY C1008 100p CH:CHIP C1033 220p CH:CHIP STDBY5V F:CHIP R401 R402...

  • Page 50: Schematic Diagram Of D Board

    (5) Schematic Diagram of D Board VAR OUT CN1807 CN1808 CN1601 CENTER SP IN / SURROUND OUT :S-MICRO :S-MICRO :S-MICRO TO H2 BOARD CN3204 J1601 TB1601 HP AUDIO R Q1612 DTC143TKA C1601 MUTE 0.001 L1601 L1602 B:CHIP 1µH 1µH -2.9 C1602 R1601 0.001...

  • Page 51: Schematic Diagrams Of P1 And V2 Boards

    • V2 BOARD WAVEFORMS (6) Schematic Diagrams of P1 and V2 Boards • P1 BOARD IC2406 BA7606F • P1 BOARD WAVEFORMS PAL/SECAM NTSC PAL/SECAM NTSC PAL/SECAM 4.3 Vp-p (12MHz) 2.5 Vp-p (20.48MHz) 1.2 Vp-p (H) 1.2 Vp-p (H) 1.0 Vp-p (H) 1.4 Vp-p (H) 1.3 Vp-p (H) NTSC...

  • Page 53: Semiconductors

    KP-EF61HK2/ME2/MN2/SN2 KP-EF61HK2/ME2/MN2/SN2 RM-871 RM-871 6-5. SEMICONDUCTORS MC14052BF PST593C-MMP-4P DTC144ESA 2SC2611 D10SC6M-4012 MA3240-TX BA7606F-T2 CXP86213-002S STV9379 DIC144ESA-TP 2SC2688-LK CXA1315M SAA5261 2SA1175-HFE CXA1875AM-T4 2SA1309A-QRSTA HEF4053BT LETTER SIDE 2SC2785-HFE 2SC3311A-QRSTA TOP VIEW LETTER SIDE 52pin DIP 4pin Chip TOP VIEW MSP3410D-PS-B4-T-ND PST9143NL TDA8395T/N3...

  • Page 54: Exploded Views

    KP-EF61HK2/ME2/MN2/SN2 RM-871 SECTION 7 EXPLODED VIEWS NOTE: • The construction parts of an assembled part are indicated with a collation number in the remark The components identified by • Items with no part number and no description are column. shading and mark...

  • Page 55: Cabinet And Panel Block

    KP-EF61HK2/ME2/MN2/SN2 RM-871 The components identified by 7-2. CABINET AND PANEL BLOCK shading and mark are criti- cal for safety. Replace only with part number : 7-685-534-19 +BTP 2.6X8 specified. : 7-685-663-71 +BVTP 4X16 : 7-685-648-79 +BVTP 3X12 CHASSIS AND PICTURE TUBE BLOCK REF.

  • Page 56: Chassis And Picture Tube Block

    KP-EF61HK2/ME2/MN2/SN2 RM-871 The components identified by 7-3. CHASSIS AND PICTURE TUBE BLOCK shading and mark are criti- cal for safety. Replace only with part number : 7-685-663-71 +BVTP 4X16 specified. : 7-685-648-79 +BVTP 3X12 REF. NO. PART NO. DESCRIPTION REMARK REF.

  • Page 57: Electrical Parts List

    The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. SECTION 8 ELECTRICAL PARTS LIST REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- -------------------...
  • Page 58 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- -------------...
  • Page 59 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. P1 AG REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ -------------...
  • Page 60 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- ------------- C110 1-164-232-11 CERAMIC CHIP 0.01MF...
  • Page 61 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- ------------- C1031 1-163-009-11 CERAMIC CHIP 0.001MF 10%...
  • Page 62 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- ------------- D2014 8-719-977-22 DIODE DTZ9.1...
  • Page 63 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- -------------...
  • Page 64 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- -------------...
  • Page 65 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. AG G REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ -------------...
  • Page 66 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- -------------...
  • Page 67 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. G CG REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ -------------...
  • Page 68 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- -------------...
  • Page 69 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. CR V2 D REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------...
  • Page 70 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- -------------...
  • Page 71 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- -------------...
  • Page 72 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- -------------...
  • Page 73 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- -------------...
  • Page 74 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- -------------...
  • Page 75 • The components identified by in this manual have been The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 carefully factory-selected for shading and mark are criti- each set in order to satisfy cal for safety. regulations regarding X-ray Replace only with part number radiation.
  • Page 76 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- -------------...
  • Page 77 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. E H1 REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ -------------...
  • Page 78 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. H2 H3 UG REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------...
  • Page 79 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- ------------- * A-1390-876-A ZR MOUNT <COIL>...
  • Page 80 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- -------------...
  • Page 81 The components identified by KP-EF61HK2/ME2/MN2/SN2 RM-871 shading and mark are criti- cal for safety. Replace only with part number specified. REF. NO. PART NO. DESCRIPTION REMARK REF. NO. PART NO. DESCRIPTION REMARK ------------ ------------- ------------------- ------------- ------------ ------------- ------------------- -------------...
