AOC L19WH Service Manual

AOC L19WH Service Manual

19" lcd color monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

19" LCD Color Monitor
Service
Service
Service
Description
Table Of Contents......................................................1
Revision List........................................................2
1. Monitor Specification...............................................3
2. LCD Monitor Description.....................................4
3. Operation Instruction............................................5
3.1. General Instructions..................................................5
3.2. Control Button......................................................5
3.3 Adjusting the Picture..........................................7
4. Input/Output Specification.......................................9
4.1. Input Signal Connector.........................................9
4.2. Factory Preset Display Modes.................................9
4.3. Panel Specification...............................................10
5. Block Diagram.....................................................12
5.1 Software Flow Chart.........................................12
5.2.Electrical Block Diagram....................................14
6. Schematic................................................................16
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE CHASSIS
AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC
EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING

TABLE OF CONTENTS

Page Description
6.1 Main Board....................................................16
6.2 Power Board...............................................21
6.3 Key Board..............................................23
6.4 Audio Board..............................................24
7. PCB Layout..........................................................25
7.1. Main Board.........................................................25
7.2. Power Board........................................................27
7.3. Key Board..........................................................29
7.4. Audio Board......................................................30
8. Maintainability....................................................31
8.2. Trouble Shooting................................................31
10. Monitor Exploded View.....................................39
11. BOM List..............................................................40
SAFETY NOTICE
1
No Brand L19WH
Horizontal Frequency
30 kHz-80 kHz
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the L19WH and is the answer not in the manual?

Questions and answers

Audrey
March 16, 2025

I can only listen thru my earphones My monitor has no sound

0
1 comments:
Mr. Anderson
March 16, 2025

The AOC L19WH monitor may have no sound due to the following reasons:

1. Audio Output Issue: The monitor has an audio output rated at 3.0W rms per channel, but if external speakers or headphones are not connected properly, no sound will be heard.

2. Volume Settings: The monitor’s volume settings may be too low or muted. Adjusting the volume settings through the monitor’s menu could resolve the issue.

3. Input Source: The monitor uses a 15-pin D-Sub (VGA) connector, which does not carry audio signals. If the audio source is connected only through VGA without a separate audio cable, no sound will be produced.

4. Audio Connection: If the monitor has an audio input port, ensure that an appropriate cable is connected from the audio source (e.g., computer or media device) to the monitor’s input.

5. Hardware Malfunction: A faulty audio board or internal speaker issue could prevent sound output.

6. Software or Driver Issues: If the monitor is connected to a PC, the audio settings in the operating system should be checked to ensure the correct output device is selected.

By checking these factors, the issue with no sound can be identified and resolved.

This answer is automatically generated

0
