LCD6520L-BK Installation Guide
65" LCD Display
Ventilation Requirements (all models)
Dimensions below are minimum required for proper ventilation.
WALL
50mm
2"
WALL
NOTE: The ventilation space should not be covered or closed off at the front of the opening. If for some reason the
opening needs to be covered, other means of ventilation will need to be incorporated into the design. Contact NEC for
design review and recommendations.
www.necdisplay.com
NEC Display Solutions of America, Inc.
50mm
2"
LCD6520L-BK
Rev 1.0
0 to 40 degC
32 to 104 degF
50mm
WALL
2"
50mm
2"
50mm
2"
Page 2 of 10
