Summary of Contents for Vibe qb69
- Page 1 Instruction Manual To ensure maximum performance and safety, please follow this manual. Please retain the manual for future reference after installation...
- Page 2 This manual is for your safety and must be adhered to at all times, please read this manual and ensure that you fully understand the installation and set up procedures explained in this manual before any work on the vehicle is attempted. If you have any doubts about the installation of the VIBE QB69 speakers please contact your nearest authorised VIBE dealer.
- Page 3 Before you begin please read all instructions that come with your power tools and wear all recommended safety equipment, also remember the rule - measure twice cut once, please ensure that the QB69 will actually fit in its intended location as replacing metalwork is a costly business.
- Page 4 Secure the2 side screws first and then fasten the 4 corner screws through the grill and the speaker to secure the speaker in place. Congratulations you have completed the installation of the VIBE QB69 Speakers can be enclosed , or mounted free air, For best results...
- Page 5 Parameters RMS Power = 200 watts Peak Power = 600 watts Miminum recommended amplifier input = 100 Watts RMS Sensitivity = 93dB Frequency response = 30Hz – 25KHz Mounting cutout = 170mm x 220mm Mounting depth = 100mm Recv = 3.600 ohms Fo = 45.272 Hz Sd = 28.400 mm Vas = 31.383 ltr...
-
Page 7: Limited Warranty
For the avoidance of doubt, VIBE does not limit its liability for death or personal injury to the extent...
