RX-LCD5802 DATASHEET
5.8GHz Diversity LCD Screen Receiver Monitor
THIS VERSION WITHOUT BUILT-IN BATTERY, PLEASE
IGNORE ANY DESCRIPTION REGARDING BATTERIES IN
Specification： ： ： ：
Built-in 5.8Ghz Dual diversity receiver automatically for best reception
Built-in 2CH 5.8Ghz AV output and 1CH AV input
Built-in high performance Li-POLYMER Battery
Work status OSD display
A key to automatic signal search
Support Chinese and English menu
Size 180mm x 120mm x 50mm
：
Working Voltage ：
Power Consumption
Battery charging current
Working temperature
Features： ： ： ：
Built-in Dual Receiver Automatically for best reception Automatic Antenna Switching
Dual buffered AV outputs
Can receive 2 different channels at the same time
Not affect by 2.4GHz R/C Radios
AV Receiver with Diversity inputs
Small, light weight, durable
4 Bands and total 32 Channels
A key to automatic signal search
Work status OSD display
Display Parameters
5.8GHz Diversity LCD Screen Receiver Monitor
１ １ １ １
RX-LCD5802
(none-battery version)
THIS MANUAL IF ANY.
： RSSI indication ; Battery indicator
N ote
（ ：
DV 7-16V
： 650 mA @12V
850mA @12V ( max )
：
-10 ~ + 65
： ℃ ℃
S imple operation
，
A lways be aware of the device working condition.
：
： 2450mAH/7.4V
；
S unshield height 2 8mm
：
C hannel indication
）
