NEC MultiSync LCD1990FXp Specifications page 2

The world's thinnest bezel highlights the MultiSync
LCD1990FXp's dynamic design. Aside from providing an
increased screen area to let you focus more on your
ideas, the virtually imperceptible bezel frees up more
horizontal and vertical desktop space for multi-monitor
applications (see image at far right). These include both
standard side-by-side and tiled configurations, which are
also assisted by the cabinet's rear clip slots. Using the
clips (available separately), these allow for easier
alignment of the displays for a more seamless overall
appearance.
Newly designed control buttons on the bottom corner of the bezel provide you with a
more intuitive means to reach your preferred image settings. By having a key guide for
each button appear on-screen alongside it when activated, an even thinner and more
non-distracting bezel is achieved. Plus, when switching from landscape to portrait
orientation or vice versa, an internal gravitational sensor automatically changes the
on-screen guides accordingly.
As easy adaptability for displays is a necessity in financial environments, the display's
quick release stand and recessed handle are essential. With the simple pull of a lever
on the base, the display quickly disengages from the stand, allowing you to move the
display from a desktop to a wall or arm mount. Tools and easy-to-lose screws also can
be avoided with the use of this quick and simple function. The handle on the back of
the display further eases the display's portability.
A user-controlled feature offered by the MultiSync LCD1990FXp is AmbiBright
automatically adjusts the backlight depending on the brightness of ambient lighting
conditions. For example, if the sensor detects the ambient lighting becoming darker, it
reduces the backlight appropriately, which helps provide optimal readability and
reduce eyestrain. Further, if desired, you can set the display to automatically enter a
power-saving mode when the ambient lighting falls below a predetermined value (i.e.
when office lights are shut off at the end of the day), which can significantly reduce
energy expenses. When you consider the number of monitors used on trading floors
and other display-heavy environments, this brightness function can contribute
significantly to a lower total cost of ownership.
The display's Eco-Mode further helps conserve energy by allowing you to define a
setting for the backlight at a 50 or 75% brightness level. This feature's benefits are best
utilized in larger corporate environments where many displays are employed.
With XtraView+ wide-angle viewing technology you can enjoy flexible horizontal and
TM
vertical viewing angles up to 178° (89° up, down, left and right) with minimal color shift
and less glare, reflection and distortion. NEC's Rapid Response
for uninterrupted display of full-motion video with a response time of 20ms. This
lightning-fast motion makes these models better than ever for streaming video
applications such as stock tickers and live web reports.
With Ambix ® dual-input technology—which utilizes both DVI-I and traditional 15-pin
VGA connectors—you can bridge the gap between analog and digital systems by
allowing the same monitor to work seamlessly in either environment. Ambix provides
compatibility with today's computer systems and is on the forefront of tomorrow's
digital output.
MultiSync and Ambix are registered trademarks, and AmbiBright,
Rapid Response and XtraView+ are trademarks of NEC Display
Solutions of America, Inc. ENERGY STAR is a U.S. registered
trademark. All other brand or product names are trademarks or
registered trademarks of their respective holders. Multi-monitor
screen images provided by Rise Vision, Inc. Product specifications
subject to change. 9/06 ver.1.
©2006 NEC Display Solutions of America, Inc. All rights reserved.
NEC MultiSync LCD1990FXp
Model
Display
Synchronization Range
Input Signal
Input
Resolutions Supported
, which
TM
Native Resolution
Additional Features
Touch-Capable
Voltage Rating
Power Consumption (typical)
Dimensions (W x H x D)
Weight
technology provides
TM
VESA Hole Configuration Specs.
Environmental Considerations
Limited Warranty
Technical Support
NEC Display Solutions
500 Park Boulevard, Suite 1100
Itasca, Illinois 60143
866-NEC-MORE
www.necdisplay.com
MultiSync LCD1990FXp
Viewable Image Size 19"
Pixel Pitch 0.294mm
86 @ native resolution
Pixels Per Inch
Brightness (typical) 250 cd/m 2
Contrast Ratio (typical) 1500:1
178° Vert., 178° Horiz. (89U/89D/89L/89R) @ CR>10
Viewing Angle (typical)
Response Time (typical) Rapid Response (20ms)/Grey to Grey (8ms)
Display Colors 16.7 million out of 68.5 billion
Horizontal 31.5-81.1 kHz (Analog/Digital)
50-75 Hz
Vertical
ANALOG RGB 0.7 Vp-p/75 Ohms
Video
Sync Separate Sync: TTL Level (Positive/Negative)
Composite Sync: TTL Level (Positive/Negative)
Composite Sync on Green (0.3 Vp-p negative 0.7 Vp-p
positive)
DVI-I and VGA 15 pin D-sub
Analog/Digital:
720 x 400 @ 70-85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-85 Hz
1152 x 864 @ 70-85 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60-75 Hz
1280 x 1024 @ 60 Hz
Ultra-thin-frame (bezel), No Touch Auto Adjust, NaViSet
software, tilt/swivel, pivot, height-adjustable stand,
vacation switch, cable management, 8-bit gamma,
AmbiBright, Eco-Mode, quick-release stand, digital
smoothing, digital controls, sRGB, Plug and Play (VESA
DDC2B & 2Bi), VESA DPMS power management, ISO
13406-2 Class II
No
AC 100-120V/AC 220-240V
On 40W
Power Savings Mode <2W
Net (with stand) 15.4 x 16-22 x 9.7 in./392.2 x 408.9.-558.9 x 247.3mm
15.4 x 12.8 x 2.59 in./392.2 x 326.7 x 66mm
Net (without stand)
18.7 lbs./8.5 kg
Net (with stand)
Net (without stand) 13.9 lbs./6.3 kg
100mm x 100mm
5-35°C/41-95°F
Operating Temp.
Operating Humidity 30-80%
Operating Altitude: 3658 m/12,001 ft.
-10-60°C/14-140°F
Storage Temp.
Storage Humidity 10-85%
Storage Altitude: 12,192 m/40,000 ft.
3 years parts and labor, including backlight
24 hours/7 days
