To attach the MultiSync
1. Turn off the power to your computer.
2. For the PC or MAC with DVI digital output: Connect the DVI signal cable (not
included) to the connector of the display card in your system (Figure A.1). Tighten all
screws.
For the PC with Analog output: Connect the 15-pin mini D-SUB signal cable to the
connector of the display card in your system (Figure A.2). Tighten all screws.
For the MAC: Connect the MultiSync Macintosh cable adapter to the computer, then
attach the 15-pin mini D-SUB signal cable to the MultiSync Macintosh cable adapter
(Figure B.1). Tighten all screws.
NOTE: To obtain the MultiSync LCD1760NX
Mitsubishi Electronics Display of America, Inc. at (800) 632-4662.
3. Remove the cable cover. Connect the 15-pin mini D-SUB of the video signal cable and
DVI signal cable (not included) to the appropriate connector on the back of the
monitor (Figure C.1).
4. Connect one end of the power cord to the monitor and the other end to the power
outlet. Place the Video Signal Cable and power cord under Cable cover (Figure C.1).
Replace cable cover.
NOTE: Adjust position of cable that place under cable cover, to avoid damage for cable
or monitor.
NOTE: If you use this monitor at AC125-240V, please refer to Recommended Use
section of this manual for proper selection of power cord.
5. The vacation switch on the right side of the monitor must be turned on (Figure D.1).
Turn on the monitor with the front power button and the computer.
NOTE: The vacation switch is a true on/off switch. If this switch is on the OFF position,
the monitor cannot be turned on using the front button. DO NOT switch on/off
repeatedly.
6. Analog input only: No-Touch Auto Adjust automatically adjusts the monitor to optimal
settings upon initial setup for most timings. For further adjustments, use the following
OSM ® controls:
• Auto Adjust Contrast
• Auto Adjust
Refer to the Controls section of this User 's Manual for a full description of these
OSM controls.
NOTE: For download information on the Windows
LCD monitor, refer to the References section of this User's Manual.
1760NX
NOTE: If you have any problems, please refer to the Troubleshooting section of this User's Manual.
