  • Page 1 EDP420 USER MANUAL...

  • Page 3: Table Of Contents

    CONTENTS: INTRODUCTION PACK CONTENTS SPECIFICATIONS SETTING UP: POWER SUPPLY USING HEADPHONES TOP/REAR PANEL DESCRIPTION 3 - 4 OPERATION: SELECT A DRUM KIT SET PAD VOICE SET PAD VOLUME SET PAD PAN SET PAD GAIN SAVE KIT PLAY SONG MASTER VOLUME ACCOMPANIMENT VOLUME DRUM OFF TEMPO...

  • Page 4: Introduction

    INTRODUCTION: Ashton is designed in Australia by a team of industry experts that have years of experience in the development, design and production of musical instruments and equipment. Ashton’s range of products are a result of years of development and careful testing. Every Ashton product is designed with value in mind and features the highest quality materials available.

  • Page 5: Setting Up

    Do not use adapters other than what is specified. The technical specifications for the power adapter on the Ashton EDP420 is 12V DC. USING BATTERIES: 1. Open the battery compartment cover on the underside of the unit.

  • Page 6: Top/Rear Panel Description

    DESCRIPTION: TOP PANEL A. POWER: This switch turns the power ON/OFF. B. TEMPO -/+: Speeds up or decreases the tempo speed. C. MASTER VOLUME -/+: Increases or decreases the volume of the device. D. ACC. VOLUME -/+: Increases or decreases the volume of an accompaniment. E.
  • Page 7 DESCRIPTION: TOP PANEL L. SONG: This button enters you into the ‘SONG’ menu - browse songs via the turning pad (T). M. START/STOP: Press once to start or stop a song from playing. N. VOLUME: This button can be used to change the volume of a pad. O.

  • Page 8: Operation

    OPERATION: The following pages entail a detailed guide on how to use all functions of your Ashton EDP420, please refer to the rear/top panel descriptions on the previous pages to locate the buttons that each description is referring to. SELECT A DRUM KIT:...

  • Page 9: Set Pad Volume

    OPERATION: SET A PAD VOLUME: Press the (VOLUME) button once to enter the PAD ASSIGN (VOLUME) menu. The corre- sponding menu indicator should light up. To assign a volume to a pad, select a pad by either pressing the (PAD) button to search through all 7 pads or by hitting the pad you wish to assign a voice to.

  • Page 10: Set Pad Gain

    (SAVE) button again. The EDP420 should quit to the kit menu and be set to the current kit if you have successfully saved the kit. Please note that an unsaved user kit will be lost if you change the kit.

  • Page 11: Play Song

    MASTER VOLUME: Use the (MASTER VOLUME +/-) buttons to adjust the main volume of the EDP420, The 3 - digit LED screen will read L and then two digits for volume (0 - 9). ACCOMPANIMENT VOLUME:...

  • Page 12: Tempo

    OPERATION TEMPO: Press any of the (TEMPO +/-) buttons to enter the tempo menu. Use either button to make the tempo faster or slower respectively (30 - 280BPM). Pressing both buttons together will set the tempo to the current song default. METRONOME: The metronome will automatically engage when a song is playing but with only the indicator flashing.

  • Page 13: Record

    EDP420. USB JACK: The EDP420 will output all the MIDI information generated by hitting the pads or stepping on the pedal via the MIDI output connector. It can also receive MIDI data from an external device.

  • Page 14: Voice List

    VOICE LIST SNARE KIT (continued) HI-HAT KIT (continued) KICK KIT 040. Acoustic Snare 003 077. Analog Hi-Hat Pan 001. Rock Kick 001 041. Acoustic Snare 004 078. Analog Hi-Hat Open 002. Rock Kick 002 042. Acoustic Snare 005 079. Shakable 003.
  • Page 15 VOICE LIST SFX KIT (continued) SFX KIT (continued) PANEL KIT (continued) 153. SFX 008 194. SFX 049 114. Claves 154, SFX 009 195. SFX 050 115. Mute Triangle 155. SFX 010 196. SFX 051 116. Open Triangle 156. SFX 011 197.

  • Page 16: Kit List

    KITS LIST: 001. Pop 1 011. Rock 2 021. Conga 1 002. Pop 2 012. Boss 022. Conga 2 003. Standard 1 013. Rock 3 023. Timbales 004. Room 014. Standard 3 024. Latin 005. Rock 025. Funk 015. Rock 4 006.

  • Page 17: Safety Information

    SAFETY INFORMATION: INSTRUCTIONS RELATING TO RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS. WARNING! When using any electronic product basic precautions should always be followed, including the following: Read all the safety and installation instructions and explanations of graphic symbols before using the products.
