Function Type
Image Functions that create space in memory for images and perform basic image
Management manipulation.
Memory A function that returns memory you no longer need to the operating system.
Management
Error Functions that set the current error, return the name of the function in which the
Management last error occurred, return the error code of the last error, and clear any pending
errors.
Acquisition Functions that acquire images through an IMAQ hardware device.
Display Functions that cover all aspects of image visualization and image window
management.
Overlay Functions that create and manipulate overlays.
Regions of Functions that create and manipulate regions of interest.
Interest
File I/O Functions that read and write images to and from files.
Calibration Functions that learn calibration information and correct distorted images.
Functions that compute the centroid of an image, profile of a line of pixels,
Image Analysis
and the mean line profile. This type also includes functions that calculate the
pixel distribution and statistical parameters of an image.
Grayscale Functions for grayscale image processing and analysis.
Processing
Binary Functions for binary image processing and analysis.
Processing
Color Functions for color image processing and analysis.
Processing
Pattern Functions that learn patterns and search for patterns in images.
Matching
Caliper Functions designed for gauging, measurement, and inspection applications.
Operators Functions that perform arithmetic, logic, and comparison operations with
two images or with an image and a constant value.
Analytic Functions that perform basic geometric calculations on an image.
Geometry
© National Instruments Corporation
Table 1-1. IMAQ Vision Function Types
Description
1-3
