To ensure this product is correctly installed and used appropriately, we highly advise you
to read this user guide very carefully.
1 . I N T R O D U C T I O N
Z4 B-box 2 UPS provides a business quality protection to your digital leisure
devices and ADSL modem.
It is easy to use and protects your computer (PC or Mac) as well as your LCD screen from
power disturbances, power outages and overloads. It keeps your system energised even
during a mains power cut of up to 20 minutes. The RJ11 connectors also protect your
Internet/ADSL modem.
Your Z4 B-box 2 UPS lets you enjoy your multimedia equipment with peace of mind.
2 . M A I N C H A R A C T E R I S T I C S
 A highly-reliable microprocessor control
 High frequency technology
 Automatic restart during AC power recovery
 Cold start feature if no power supply
 Automatic frequency detection
 Indicator lights and an audible alarm
 Compact size and lightweight
Phone/modem or network surge protection

3 . S A F E T Y I N S T R U C T I O N S – S e c u r i t y
 Risk of electric shock:

The UPS unit uses potentially hazardous voltages. Do not attempt to disassemble
this equipment as it does not contain accessible components that can be repaired by
users, fuse change excepted.

All repairs should be performed by qualified technicians only.

The utility power outlet shall be near the equipment and easily accessible. To
isolate the UPS from AC input, remove the plug from the utility power outlet.

The UPS has its own internal power supply (battery). There is a risk that output
sockets may still be live after the UPS has been disconnected from the mains power
supply.

In an emergency situation, switch the UPS to the "Off" position and disconnect the
unit from the AC power supply.

When the UPS is out of order, please refer to section: "trouble shooting" and call
the hot line.
 Connected products:

Combined UPS and connected equipment leakage current should not exceed 3,5
mA.

Make sure that the connected load does not exceed UPS capabilities. To ensure
improved backup time and longer battery life, we recommend a load equivalent to 1/3
of nominal power.

Do not plug the UPS input into its own output socket.
 Do not plug the UPS into a power strip or surge suppressor.
