Summary of Contents for Bush 32/133DVDB
- Page 1 HD Ready LED TV with Freeview, DVD & USB Media Player User Guide Model No 32/133DVDB 32/133DVDW...
-
Page 2: Table Of Contents
Connecting a sky digital set top box 42-43 Wall mounting Frequently asked questions 44-45 TV buttons Technical specification 46-47 Remote control Bush warranty information Connections TV buttons and input source TV connections 23-24 Standard features How to navigate the menus Channel menu Picture menu... -
Page 3: Safety Information
Safety information... - Page 4 Safety information Important - Please read these instructions fully before installing or operating WARNING - Never place a television set on an unstable location. A television set may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such as: •...
-
Page 5: Safety Information
Safety information Important - Please read these instructions fully before installing or operating • Always place the television on a flat level surface Packaging avoiding anywhere which may be subject to • The safest way to transport your item is in the strong vibration. - Page 6 Safety information Important - Please read these instructions fully before installing or operating • HDMI, the HDMI logo and High-Definition Disposal Multimedia Interface are trademarks or registered UK: Waste electrical products should not trademarks of HDMI Licensing LLC. be disposed of with household waste. Please dispose •...
-
Page 7: Getting To Know Your Tv
Getting to know your TV... -
Page 8: Accessories
Getting to know your TV You’ll be up and running in no time Accessories 1 x User guide 1 x Remote control User Guide 2 x AAA batteries 1 x Quick start guide 1 x TV 1 x Mini Component / YPbPr Cable 1 x Mini Composite / AV Cable 1 x RF cable 1 x Stand installation pack... -
Page 9: Stand Installation
Getting to know your TV You’ll be up and running in no time Stand installation To complete the stand installation you will require a cross head screw driver. (A) 5 x M(4x10) (B) 3 x ST(3.7x18) Counter Sunk 5 x M(4x10) fig 1) Attach the stand neck to the rear of the TV set. -
Page 10: Detaching The Stand
Getting to know your TV You’ll be up and running in no time Detaching the stand To detach the stand please remove the 5 screws highlighted then remove the stand feet from the rear of the TV set. 5 x M(4x10) Securing the TV using anti-tip straps For maximum security in the home, when using a TV with its stand, anti-tip straps should be fitted. -
Page 11: Wall Mounting
Getting to know your TV You’ll be up and running in no time Wall mounting IMPORTANT: Before drilling any holes in the wall ensure you are not drilling where there could be any electric wires, water or gas pipes. 1) Remove the four screws located at the back of the TV set. 2) The wall mount can now be easily attached to the mounting holes, located on the back of the TV, using the same four screws removed. -
Page 12: Remote Control
Getting to know your TV You’ll be up and running in no time TV buttons and input source 1) Stop/Eject DVD 2) Play/Pause DVD 3) Volume up and menu right 4) Volume down and menu left 5) Programme/Channel up and menu up 6) Programme/Channel down and menu down 7) Displays Menu/OSD 8) Displays the input source menu... - Page 13 Getting to know your TV You’ll be up and running in no time Remote control functions For Models with Integrated DVD players For Models with PVR Function For Models with USB Playback For Models with 3D Feature 1) STANDBY 2) MUTE 3) DTV 4) RADIO 5) DVD...
- Page 14 Connections...
- Page 15 Connections Bringing it all together Connections EARPHONE Earphone socket COAX in Digital Coax output HDMI 1 HDMI input HDMI 2 HDMI input VGA/PC VGA/PC input VGA/PC AUDIO IN 3.5mm PC audio input COMPONENT (HD) Component input (YPbPr) AV IN Video input RF IN RF / TV Aerial Input HDMI 3...
- Page 16 Connections Bringing it all together Connections Connecting a camcorder, camera or games console. The TV source should be set to composite/AV. L (white) R (red) Mini Video AV in (yellow) Connecting a DVD player/recorder, video recorder or cable/satellite box. Source should be set to composite/video. Mini Scart AV in...
- Page 17 Connections Connecting a High Definition (HD) Device Option 2 - via Component cable If you are supplied with a cable from the device which has RED, GREEN, BLUE, RED & WHITE connectors you must connect via Component (for picture) and by phono cable (for sound). TV Source should be set to Component/YPbPr.
-
Page 18: Standard Features
Standard features... -
Page 19: How To Navigate The Menus
Standard features Standard features Simple everyday use Simple everyday use How to navigate the menus To access this menu, press [MENU] button on the remote control. To enter a menu press [OK] If you wish to make changes to any of the default settings, use the scroll buttons. -
Page 20: Channel Menu
Standard features Simple everyday use Channel menu Auto Tuning - Allows you to retune the television for all digital channels, digital radio stations and analogue channels. Analogue Manual Tuning - Allows you to manually tune your analogue signal Freeview Manual Tuning - Allows you to manually tune your digital signal Channel Edit - Allows you to delete, move, skip and add favourite channels. -
Page 21: Picture Menu
Standard features Simple everyday use Noise Reduction Picture menu • Off - Turns noise reduction off. • Low - Minor system adjustment. • Middle - Medium system adjustments. • High - Maximum system adjustments. Aspect Ratio - Within the UK the picture format varies depending on the channel/broadcast. -
Page 22: Sound Menu
Standard features Simple everyday use Surround Sound Sound menu • Off - Off. • TruSurround HD - TruSurround HD™ creates an immersive, feature-rich surround sound experience from two speakers, complete with rich bass, high frequency detail and clear dialog. Audio Description - This allows the user to increase and decrease the AD (Audio Description) volume level. -
Page 23: Time Menu
Standard features Simple everyday use Time menu System/Hotel lock menu Clock - Shows the date and time. System/Hotel Lock - Allows you to lock or unlock the menu. You will be asked to enter a 4 digit password use Off Time - Allows you to set a specific time for your TV button to quit the password input. -
Page 24: Setup Menu
Standard features Simple everyday use Setup menu HDMI CEC (Consumer Electronic Control) - Allows HDMI devices to control each other and allows the user to operate multiple devices with one remote control. (only available with compatible devices). LED Status - Allows the user to switch the LED Power indicator light ON or OFF, when the TV is being operated.(When this option is set to OFF the LED Power indicator light will flash when the remote... -
Page 25: Advanced Features
Advanced features... -
Page 26: Day Tv Guide
Advanced features Getting the most from your TV 7 day TV guide and channel list TV Guide is available in Digital TV mode. It provides information about forthcoming programmes (where supported by the freeview channel). You can view the start and end time of all programmes and on all channels for the next 7 days and set reminders. -
Page 27: Usb Media Player
Advanced features Getting the most from your TV USB media player USB mode offers playback of various different types of content that you have saved on your USB Memory Stick. On switching to USB source the menu screen will appear. The content will be divided into Photo, Music, Movie and Text based on file type. -
Page 28: Dvd Setup
Advanced features Getting the most from your TV DVD setup Applies to TV models with built in DVD players only. TV Display - Choose from the following options 4:3 Pan Scan PS Traditional picture format, often used on old fi lm 4:3 Letter Box LB Traditional picture which has been adapted for widescreen Wide... -
Page 29: Product Support
Product support... -
Page 30: Connecting A Sky Digital Set Top Box
Product support Help is always at hand Connecting a sky digital set top box Using a Sky Remote or a Universal Remote to operate your TV Sky Remote Control - If you wish to use your Sky remote to operate the basic functions of your TV, you need to program a 4 digit code into it. - Page 31 Product support Help is always at hand Connecting your TV to your Sky box (when your Sky box is located in a different room to the TV) Option 2) Please note, if you are adding a ‘Magic Eye/TV Link’ to your system so that you can use your Sky remote control to change the Sky channel in the room where the 2nd TV is located, please refer to the instructions included with the TV link/magic eye in order to ensure the RF or RF2 output on your Sky box is powered on.
-
Page 32: Frequently Asked Questions
Product support Help is always at hand Frequently asked questions General I would like to have 1) Use the 3.5mm headphone output and a 3.5mm to phono cable (available louder sound by separately) to connect to an amplifi er/surround sound system. Please note connecting additional this will deactivate the TV’s built in speakers. - Page 33 Product support Help is always at hand Frequently asked questions Game I have connected my Component cables only provide HD pictures. For the sound you will need Consoles Playstation/Xbox to to connect the red & white audio cables on the Playstation/Xbox to the red the TV via Component &...
-
Page 34: Technical Specification
Product support Help is always at hand Technical specifi cation Product fiche Trademark Bush Model ID 32/133DVDB 32/133DVDW Energy effi ciency class Visible screen size (diagonal) 81 cm / 32 inches On mode power consumption 31.0 W Annual energy consumption *1... - Page 35 Product support Help is always at hand Technical specifi cation Compatible files in USB Mode Codec Media File Ext. Remark Video Audio Max Resolution: 1920x1080 .mpg MPEG-1, MPEG-2 Max Data rate: 40 Mbps Xvid, MJPEG, .avi MPEG-4 SP/ASP, H.264 MPEG-2, H.264 Max Resolution: 1920x1080 MP3, WMA, .mov/...
- Page 36 Contact: www.argos-support.co.uk Helpline: 0330 024 0805 BUS/MAN/0030...
