THUNDER TIGER raptor e700 Instruction Manual

1277
SPECIFICATION / 規格表
Description / 產品名稱 RAPTOR E700
Item No. / 產品料號 4761
Power / 動力 Electric Motor
Rotor Head / 主旋翼頭型式 Flybarless
Length / 總長 1277 mm / ( 50.3" )
Width / 總寬 191mm / ( 7.5" )
Height / 總高 385 mm / ( 15.2" )
Length / 長度 690~700 mm / ( 27.2~27.5" )
Main Rotor (Req'd)
主旋翼 Diameter / 迴轉直徑 1538~1558 mm / ( 60.5~61.3" )
Length / 長度 105 mm / ( 4.1" )
Tail Rotor
尾旋翼
Diameter / 迴轉直徑 280 mm / ( 11.0" )
Main Gear / Pinion 主齒盤 / 驅動齒數 128T / 13T
Gear Ratio (E:M:T) / 齒輪比 9.85 : 1 : 4.27
Full Equipped Weight w/o Battery 2917-gram
全配重量不含電池 (102.9 oz)
Max. Battery on Board
160 x 50 x 65 mm (6.3 x 1.96 x 2.55")
電池最大承載量
Battery: 12S (6S x 2) 5.0Ah
Battery C-rate: Above 30C
Recommended Power Configuration
ESC:120~160A
動力搭配建議
Motor:520~560KV
Est. Rotor rpm:2200~2300
FEATURES / 特色
1. Latest fiberglass canopy design w/sleek scheme
2. Collective pitch range +/-15 degrees
3. Innovative quick calibration system
4. Elevator control arm link use bearing connect for stability and smoothly
5. Lightened metal main shaft bearing blocks
6. 12mm hardened hollow steel main shaft
7. 2mm aerospace grade true carbon side frame
8. Lightweight and heavy-duty 14mm herringbone 128T main gear V.S. 13T Pionion
9. Lite yet rigid one-piece machined AL tail case
10. Precisely and heavy-duty tail rotor system
11. 8mm torque tube driven w/efficient helical bevel tail gear
12. Quick-release battery tray(Patent Pending) fits two 6 cells Lipo battery packs
13. Extended electronics tray for installation versatility
14. Top mounted motor for better center of gravity and efficient heat dissipation
15. Adjustable motor mount and pinion bearing block
16. Rear rudder servo plate for easy maintenance and efficient heat dissipation
17. Lightweight and rugged landing skid for low center of gravity
18. Easy to install tail rotor rod guide
19. Lightweight one-piece metal tail boom support bracket
20. All metal servo horns and control arms assembly eliminate the need for upgrades
No.4761
191
1. 原廠塗裝完成高彩度玻璃纖維機頭罩
2. 主旋翼攻角最大可達+/-15度
3. 原創中立點快速校正系統
4. 升降舵連接座採滾珠軸承固定，增加耐用度與順暢度
5. 輕量化主軸軸承座
6. 12mm熱處理強化主軸
7. 高強度2mm碳纖維側板
8. 高負載輕量化14mm人字型128T主齒盤，搭配13T馬達齒輪
9. 一體成型輕量化高強度金屬尾座
10. 高精度全金屬尾旋翼系統
11. 8mm尾傳動軸並搭配高負載尾螺旋傘齒
12. 原創電池快拆機構，可容納2組6CELLS鋰電池
13. 加大電子設備固定座，方便配置
14. 上置式馬達設計使機體重心更為集中且高效散熱
15. 可調式馬達固定座及馬達驅動齒輪支撐座
16. 後置式尾舵伺服機固定座方便維修與散熱
17. 高強度輕量化低重心腳架組
18. 快拆式尾舵拉桿導環
19. 一體成型輕量化金屬尾管支撐固定座
20. 配備金屬伺服機舵片及控制臂組，無需額外進行升級改裝
JK6176
INSTRUCTION MANUAL INSTRUCTION MANUAL
組 裝 說 明 書
No.4761
This radio control model is not a toy! Before beginning assembly, please read this
manual thoroughly.
The contents are subject to change without prior notice due to product improvements
and specification changes.
本產品為高性能模型非一般玩具，組裝與操作前請詳閱本產品說明書。
本套件所附之零件可能跟圖示有所差異。因產品後續之設計研發或功能不斷改善之原因，我們
將保留產品規格變更權利，不再另行通知使用者。
E700
3D
