Southland S-HBV-30175-E Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Gasoline Powered Blower/Vacuum/Mulcher; Three-in-One
30cc, 2 Cycle
Look inside for:
IMPORTANT:
Thank you for purchasing this Southland® Blower/Vacuum/Mulcher.
Read and understand all warnings and instructions in this manual before operating this tool. Improper use of this tool can
cause severe injury or death. Keep this manual for future reference.
Record the following for future reference:
Mfg. Date Code : _________________
Date of Purchase: Attach a copy of your sales receipt.
Consumer Toll Free Number: 1-800-737-2112
Refer to the website for the electronic manual and parts book.
WARNING
CALIFORNIA PROPOSITION 65 WARNING
Engine exhaust, some of its constituents, and certain product components contain or emit chemicals known to the State of
California to cause cancer and birth defects or other reproductive harm.
If you have a question or problem...
CALL TOLL FREE: 1-800-737-2112
KEEP THIS MANUAL FOR FUTURE REFERENCE
01/24/2011
Operator's Manual
www.southlandpowerequipment.com
Page
1
2-3
4
4
5-7
8-9
10
10
11
11
12-17
Printed in China
MODEL Nos. S-HBV-30175-E
S-HBV-30175
For Occasional Use Only
A200127

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S-HBV-30175-E and is the answer not in the manual?

Questions and answers

Related Manuals for Southland S-HBV-30175-E

Summary of Contents for Southland S-HBV-30175-E

  • Page 1: Table Of Contents

    12-17 IMPORTANT: Thank you for purchasing this Southland® Blower/Vacuum/Mulcher. Read and understand all warnings and instructions in this manual before operating this tool. Improper use of this tool can cause severe injury or death. Keep this manual for future reference.

  • Page 2: Safety Definitions

    Safety Definitions • Save all instructions Safety Warning Symbols: Indicates Warning. Keep all by-standers at least 50 ft. (15 m) away. 50 ft 15 m Read these instructions carefully. This equipment can throw small objects at high speed causing personal injury. Inspect area where used and remove all foreign objects.

  • Page 3: Important Safety Information

    Important Safety Information • Save all instructions Before Operating Blower/Vacuum/Mulcher 1. READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE OPERATING BLOWER/VACUUM/MULCHER. WARNING Read and follow all warnings and safety instructions. Failure to do so can result in serious injury to you or bystanders. 2.

  • Page 4: Important Safety Information

    5. A guard or other part that is damaged should be properly repaired or replaced by a qualified service center. 6. Use only genuine Southland® replacement parts and accessories. Use of any non- Southland® parts or accessories could lead to injury, damage to the unit, and will void your warranty.

  • Page 5: Product Specifications

    Product Specifications • Save all instructions Engine ......30 cc, 2 cycle Fuel Mixture .

  • Page 6: Assembly

    Assembly (Continued) • Save all instructions Blower Assembly WARNING Blower tube installation affects both Blower balance and performance. The tube and nozzle must be installed correctly. Never use the Blower without the upper tube and the nozzles correctly fitted to the Blower. Fig.
  • Page 7 Assembly (Continued) • Save all instructions Install the Vacuum Bag 1. Remove the Blower Tubes from the blower. 2. Unzip the Vacuum Bag and Insert the elbow tube as shown. (Fig. 8) 3. Align the arrow on the elbow tube with the arrow on the blower outlet.
  • Page 8 Assembly (Continued) • Save all instructions Install the Vacuum Tubes 1. Secure the Upper and Lower Vacuum Tubes together by tightening the provided screws. (Fig.11) 2. Open the vacuum door. (Fig 12) 3. Hold the Vacuum Door open until vacuum tube is installed.

  • Page 9: Operation

    Operation • Save all instructions Before Starting Engine: Mixing Fuel / 2-Cycle Oil WARNING Do not smoke or allow smoking near fuel or the Blower/Vacuum/Mulcher. Mix and pour fuel outdoors WHERE THERE ARE NO SPARKS OR FLAMES. The 2-cycle engine on your Blower/Vacuum/Mulcher 5.

  • Page 10: Operation

    Operation (Continued) • Save all instructions Starting Engine: Starting A Flooded Engine the starter handle repeatedly until engine starts and runs. This could require pulling the starter handle many 1. Place the Blower/Vacuum/Mulcher on a flat surface. times, depending on how badly the unit is flooded. 2.

  • Page 11: Routine Maintenance

    Routine Maintenance • Save all instructions WARNING Disconnect the spark plug before performing maintenance except for carburetor adjustments. Air Filter: Accumulated debris and dust in the air filter will reduce engine performance, increase fuel consumption, and increases the risk of engine damage. Clean the air filter every 5 hours of operation. 1.

  • Page 12: Troubleshooting

    Troubleshooting • Save all instructions PROBLEM POSSIBLE CAUSE(S) SOLLUTION(S) Engine will not start. 1. Ignition Switch in the “OFF” position. 1. Move ignition switch to the ON position. 2. See Starting a Flooded Engine in 2. Engine flooded. OPERATION section. 3.

  • Page 13: Warranty

    Warranty shall apply except where the METL Limited Warranty may provide a longer warranty period. Please read your warranty rights and obligations carefully. Some sections of the warranty may not apply to the specific model you purchased. Unless specifically noted otherwise, the terms below shall apply to all Southland® products covered within this manual.
  • Page 14 Warranty (Continued) • Save all instructions Other U.S States / Territories: In other areas of the Unites States, your outdoor power equipment engine must be designed, built and equipped so as to conform at the time of sale to U.S. EPA emissions standards for small off-road spark ignition engines at or below 19 kilowatts.
  • Page 15 Warranty (Continued) • Save all instructions Defects Warranty Coverage: METL warrants to the original purchaser and each subsequent purchaser that the small off-road engine (SORE) (1) has been designed, built and equipped so as to conform with all applicable regulations; and (2) is free from defects in materials and workmanship that cause the failure of a warranted part to conform with those regulations as may be applicable to the terms and conditions stated below.
  • Page 16 Warranty (Continued) • Save all instructions Emission Warranty Parts List: The repair or replacement of any warranted part otherwise eligible for warranty coverage may be excluded from such warranty coverage if METL demonstrates that the engine has been abused, neglected, or improperly maintained, and that such abuse, neglect, or improper maintenance was the direct cause of the need for repair or replacement of the part.
  • Page 17 Warranty (Continued) • Save all instructions California Evaporative Emission Control Warranty Statement YOUR WARRANTY RIGHTS AND OBLIGATIONS Applies only to Model No. S-HBV-30175: The California Air Resources Board and METL are pleased to explain the evaporative emission control system’s warranty on your 2010 model year small off-road engine (SORE).
  • Page 18 Warranty (Continued) • Save all instructions Defects Warranty Coverage: (a) The warranty period begins on the date the engine is purchased. (b) General Evaporative Emissions Warranty Coverage. The engine must be warranted to the ultimate purchaser and any subsequent owner that the evaporative emission control system when installed was: (1) Designed, built, and equipped so as to conform with all applicable regulations;...
