Summary of Contents for Shure SE530
- Page 2 A tweeter and dual woofers create an expansive sound stage complete with full- bodied bass. In addition to an ultra-premium industrial design, the Shure SE530 includes a carrying case, modular cables, interchangeable Sound IsolatingTM sleeves, and adapters—providing a comfortable, and maximum portability.
-
Page 3: Wearing The Earphones
WEARING THE EARPHONES Two suggested methods for wearing the earphones are illustrated below. Over the ear in back Over the ear in front Cable sleeve Tighten the cable and take up slack by raising the cable sleeve. -
Page 4: Inserting The Earphones
INSERTING THE EARPHONES If the earphone seems to be lacking in low frequency response (bass), check the tightness of the seal between the earphone and your ear, or try one of the other sleeve options. Warning: Do not push the earphone sleeve beyond the ear canal opening. To change earphone sleeve, twist and pull sleeve to remove it from the nozzle. -
Page 5: Removing The Earphones
REMOVING THE EARPHONES Note: Do not pull on cable to remove earphone. Grasp the body of earphone and gently twist to remove. - Page 6 CHOOSING AN EARPHONE SLEEVE Your earphones come with a selection of sleeves. Make sure the sleeve remove from your ear. Soft Flex Sleeves In small, medium, and large sizes. Made from pliable rubber. Soft Foam Sleeves When using the foam sleeves, compress the sleeve between your place for about ten seconds while the foam expands and creates a tight seal.
- Page 7 CLEANING THE EARPHONE NOZZLE If you notice a change in sound quality, remove the sleeve and check the nozzle of your earphone. If nozzle is blocked, clear obstruction by using wire loop end of cleaning tool. Wax Rem Loop Nozzle When cleaning, do not force any object through the earphone nozzle!
-
Page 8: Furnished Accessories
• Extension Cable - 9” (23cm) • Stereo Adapter Plug - 1/4 in. (6.5mm) to 1/8 in. (3.5mm) • Airline Adapter Note: The carrying case is designed to hold only the SE530 earphones. ACCESSORIES For information about earphone accessories (listed below) and other Shure products visit: www.shure.com... -
Page 9: Technical Specifications
TECHNICAL SPECIFICATIONS Transducer type Triple balanced-armature drivers 119 dB SPL/mW DC Resistance Frequency Range Input connector 3.5 mm (1/8 in.) gold-plated stereo plug Net weight 30 g (1 oz.) Operational temperature -18° C to 57° C (0° F to 135° F) Storage temperature -29°... - Page 10 CUSTOM EARPHONE SLEEVES Those who use earphones regularly for extended periods of time often sleeves for your earphones. For more information, contact: Toll Free: (877) 848-1714 660 N. Milwaukee Avenue In Chicago: (312) 432-1714 Chicago, IL 60622 e-mail: saveyourears@sensaphonics.com www.sensaphonics.com...
-
Page 11: Maintenance
MAINTENANCE Careful maintenance ensures a tight seal between the sleeve and nozzle, improving sound quality and product safety. Keep the earphones and sleeves as clean and dry as possible. To clean sleeves, remove them from earphones, gently rinse in warm water and air dry. Foam sleeves require a longer drying time. - Page 12 CERTIFICATION Eligible to bear CE marking. Conforms to European EMC Directive 89/336/EEC. Meets applicable tests and performance criteria in European Standard EN 55103 (1996) Parts 1 and 2, for residential (E1) and light industrial (E2) environments.
- Page 13 United States, Canada, Latin America, Caribbean: 5800 W. Touhy Avenue, Niles, IL 60714-4608, U.S.A. Phone: 847-600-2000 U.S. Fax: 847-600-1212 Int’l Fax: 847-600-6446 Europe, Middle East, Africa: Shure Asia Limited, Phone: 852-2893-4290 Fax: 852-2893-4055...
