Page 2: Safety Information
Safety Information Thank you for purchasing the player. Please read this manual carefully before operating and reserve it for future reference. PRECAUTIONS Use only in a 12-volt DC negative-ground electrical system. Disconnect the vehicle's negative battery terminal while mounting and connecting the unit. When replacing the fuse, be sure to use one with an identical amperage rating. -
Page 3: Table Of Contents
Contents Safety Information ..........................................1 Contents ..............................................2 Panel Controls ............................................3 Remote Control ..........................................4-5 Button Tips .............................................6 iPod Operation............................................7 MP3 Playback............................................. 8-9 MP3 Overview ............................................10 RDS ..............................................11-12 Menu Function ..........................................13-14 Electrical Connections ..........................................15 Installation Guide ..........................................16 Anti-Theft System ..........................................17 Trouble Shooting ..........................................18 Specifications ............................................19... -
Page 4: Panel Controls
Panel Controls 1. Power on/off 2. Mute 3. Traffic Announcements 4. Source switch -Radio -Disc play (when disc is in) -iPod (when iPod connected) 5. Panel release 6. -Time display/adjust (see page 6) -Display switch 7. -Play/Pause -Top play (hold more than 2sec) 8. -
Page 5: Remote Control
Remote Control 1. -Power on/off 6. -Alternative Frequency 2. -Mute -REG on/off 3. -Push to select BAS(Bass)/TRE(Treble)/BAL 7. EQ: POP/ROCK/CLAS/FLAT/OFF (Balance)/FAD(Fader)/VOL(Volume), 8. Display switch use Volume button to adjust level. 9. -Band Switch: -Push more than 2 seconds to menu mode. FM1-FM2-FM3-MW1-MW2 4. Traffic Announcements -MP3 ID3 Display switch:... -
Page 6: Remote Control
Remote Control Replacing the lithium battery of remote control unit. When the range of the operation of the card remote control becomes short or no functions while operating, replace the battery with a new lithium battery. Make sure the battery Polarity replacement is correct. 1.Pull out the battery holder while pressing the stopper. -
Page 7: Button Tips
BUTTON TIPS AMS : Auto memory store/Auto preset scan Press AMS button to scan the preset station 1-6 for 5 seconds each. Press and hold 2 seconds, the 6 strongest available station will be automatically saved in the memory of preset button 1-6 . BUTTON SKIP Radio : Press either side of the button to tune in the station. -
Page 8: Ipod Operation
iPod Operation If the selected album name, artist, or title exceeds eleven characters, the display information will scroll upon selection. iPod Category Search Press the 6 button to enter the iPod menu. Turn the rotary encoder to choose from the following categories: •... -
Page 9: Mp3 Playback
MP3 Playback While playing MP3 MUSIC, the folder/file name and ID3 tag (Song title, Album and Artist) can entirely show in the LCD. Press the DISP to choose ID3 informations for display as follows: Elapsed playing time & Track number Folder name File name Music title Artist name Album title MP3 Track search Press AMS button to select "TRK SCH" mode. Press the knob and LCD display will show "TRK 001". - Page 10 MP3 Playback(continued) MP3 Folder Search and Character Search Press AMS button three times to select "FOLD-SCH" mode and four times to select “CHAR-SCH“ mode. Press the knob and "A" displayed. If you press the knob more than 2 seconds will search a track with the letter " A" . If the track found, the track name will displayed, then press the knob to play.
-
Page 11: Mp3 Overview
MP3 Overview Note on MP3 • MP3 is short for MPEG Audio Layer 3 and refers to an audio compression technology standard. • This product allows playback of MP3 files on CD-ROM, CD-R or CD-RW discs. • T he unit can read MP3 files written in the format compliant with ISO 9660. However it does not support the MP3 data written by the method of packet write. • The unit can not read an MP3 file that has a file extension other than ".mp3". • If you play a non- MP3 file that has the " .mp3 " extension, you may hear some noise. • In this manual, we refer to what are called "MP3 file" and "folder " in PC terminology as "track" and "Album," respectively. • Maximum number of directory level is 8, including the root directory. Maximum number of files is 999 and folders per disc is 1000 . • The unit may not play tracks in the order of Track numbers. •... -
Page 12: Rds
RDS ( Radio Data System ) RDS service availability varies with areas. Please understand if RDS service is not available in you area, the following service is not available. RDS Basics AF(Alternative Frequency): When the radio signal strength is poor, enabling the AF function will allow the unit to automatically search another station with the same PI (program identification) as the current station but with stronger signal strength. - Page 13 RDS ( Radio Data System ) PTY Reception ( Program Type ) RDS FM stations provide a program type identification signal. Example: news, rock, info, sport, etc. PTY Mode: Press PTY to turn on the Program Type reception, the previous PTY type is shown. Press PTY once again to enter the MUSIC type or press twice to enter the SPEECH type, then use buttons 1 - 6 to select the desired program type.
-
Page 14: Menu Function
Menu Function Press the knob more than 2 seconds to enter menu mode, then each press changes the mode as follows: TA mode MASK mode RETUNE mode DSP mode LOUD ON / OFF mode WOOF ON / OFF mode VOL mode BEEP ON/OFF mdoe STEREO/MONO mode(only in tuner mode) LOCAL / DX mode(only in tuner mode) - Page 15 RDS Menu Function DSP mode Rotate the knob to choose DSP sound effect: LOUD ON/OFF mode Rotate the knob to choose loudness on or off. WOOF ON/OFF mode Rotate the knob to choose Sub-woofer on or off. VOL LAST / ADJUST mode Rotate the knob to choose VOL LAST, the turn-on volume level is the volume level of latest power off.
-
Page 16: Electrical Connections
Electrical Connections Wiring Diagram Sub-woofer out iPod connector... -
Page 17: Installation Guide
Installation Guide Installation Procedures First complete the electrical connections, and then check them for correctness. Reset Press the Reset button with a pointed object to reset the unit to the original status. Note: Press the RESET button with earse the clock setiing and stored stations Installation Opening This unit can be installed in any dashboard having an opening as shown above. -
Page 18: Anti-Theft System
Anti-Theft System This unit is equipped with a detachable panel. Removing this panel makes the radio totally inoperable. Place the Detachable Panel into Case 1.Switch off the power of the unit. 2.Remove the detachable panel. 3. Gently press the button of the case and open the cover. Place the panel into the case and take it with you when you leave the car. -
Page 19: Troubleshooting
Troubleshooting If you suspect something is wrong, immediately switch power off. Do not use the unit in abnormal condition, for example without sound, or with smoke or foul smell, can cause fire or electric shock. Immediately stop using it and call the store where you purchased it. Never try to repair the unit yourself because it is dangerous to do so. General Radio No power or no sound. Noise in broadcasts. -
Page 20: Specifications
Specifications MW(AM) Radio General Frequency range: 522-1620KHz (EUROPE MODE) Power supply: 12V DC(11V-16V) 530-1710KHz (USA MODE) Test voltage 14.4V, negative ground Usable sensitivity(S/N=20dB): 30 dBμ Maximum power output: 45Wx4 channels Continuous power output: 24Wx4 channels (4 ,10% T.H.D.) Suitable speaker impedance: 4-8 ohm Disc Player Pre-Amp output voltage:...
