it HUH-106 User Manual

Wooden cube speaker

Table of Contents

Download this manual

WOODEN CUBE SPEAKER

ON/OFF Switch

Charge Port

INCLUDED: (1) Wooden Cube Speaker, (1) Charging Cable, (1) Audio Cable

Plug the supplied Charging Cable into the speaker's Charge Port. Connect the

Charging Cable to a laptop USB port or AC wall adaptor (not included).

Charging time is approximately 3 hours. Once charging is complete, the LED

Indicator Light will turn OFF. Please Note: It is recommended to fully charge

the speaker prior to ﬁrst use.

Turn the Wooden Cube Speaker ON. The LED light will light BLUE indicating the

unit is ON. Plug the supplied 3.5mm Audio Cable into the speaker's Audio Port.

Connect the other end of the Audio Cable into the 3.5mm headphone jack of

the device (smartphone, tablet, etc.) you will be playing music from.

OVERVIEW

BOTTOM PANEL

ON OFF

CHARGE

AUDIO

MODEL: HUH-106

Audio Port

LED Indicator Light

Table of Contents

Do you have a question about the HUH-106 and is the answer not in the manual?

Page 1 Charging Cable to a laptop USB port or AC wall adaptor (not included). Charging time is approximately 3 hours. Once charging is complete, the LED Indicator Light will turn OFF. Please Note: It is recommended to fully charge the speaker prior to ﬁrst use.
Page 2 SPECIFICATIONS Frequency Response: 250Hz-20kHz S/N: >=60dB Power Supply: USB charge or built-in lithium battery Loudspeaker Output: 3W x 1pcs Horn Speciﬁcations: 1.77" 4 3W Lithium Battery Capacity: 180mAh 3.7V Playback Time: 3 to 5 hours Charging Time: 3 to 4 hours Input Voltage: USB +5V 1.0A Product Size: 2.17 x 2.17 x 2.17in (55 x 55 x 55mm) Output Power: 3W...
Page 3 The Warranty is “Not” transferable. IT agrees, within the initial “90 Day” period, to repair or replace the product if it is determined to be defective at “No Charge”. It is further agreed that IT will cover the cost to repair or replace damaged “Parts”...
Page 4 • Shipping fees are non-refundable To be payable to Innovative Technology Electronics Corp.(for handling and return shipping charges) (IT) will not be responsible for delays or unprocessed claims resulting from a purchaser’s failure to provide any / all of the necessary information. Send all inquiries or RMA request via our website: www.ithomeproducts.com/support.
