iViz Dual Charging Station
Assembly Instructions
Contents
Dual charging plate (1)
Attaching the chargers to the charging station
S
TEP
Turn both chargers over.
1
180º
Second charger (1) (use with the
charger included with iViz)
S
TEP
Rotate the protective covers on each charger.
2
180º
1
Advertisement
Related Manuals for SonoSite iViz
Summary of Contents for SonoSite iViz
-
Page 1: Assembly Instructions
Dual Charging Station Assembly Instructions Contents Second charger (1) (use with the Dual charging plate (1) charger included with iViz) Attaching the chargers to the charging station Turn both chargers over. Rotate the protective covers on each charger. 180º... - Page 2 Place the dual charging plate on top of the first Tighten the first set of screws on the dual charger. charging plate. Tighten the second set of screws on the dual Place the dual charging plate on top of the second charging plate.
- Page 3 Plug the charging adapter into the dual charging station.
- Page 4 SonoSite and the SonoSite logo are trademarks and registered trademarks of FUJIFILM SonoSite, Inc. in various jurisdictions. All other trademarks are the property of their respective owners. Copyright 2015 FUJIFILM SonoSite, Inc. All rights reserved. © Manufacturer EC Authorized Representative Australia Sponsor FUJIFILM SonoSite, Inc.
