- Page 1 100 Series Media Converter & Industrial Ethernet Switches User Manual & Installation Guide 5/17/2007...
- Page 2 Industrial Media Converter Installation Guide 102MC-XX 102MCE-XX-YY 104TX 105TX 108TX Where: XX = ST or SC and YY = -15, -40, or -80 5/17/2007...
- Page 3 In no event shall N-TRON Corp. be liable for any incidental, special, indirect or consequential damages whatsoever included but not limited to lost profits arising out of errors or omissions in this manual or the information contained herein.
-
Page 4: General Safety Warnings
Do not operate the equipment in the presence of flammable gasses or fumes. Operating electrical equipment in such an environment constitutes a definite safety hazard. WARNING: If the equipment is used in the manner not specified by N-TRON Corp., the protection provided by the equipment may be impaired. -
Page 5: Hazardous Location Installation Requirements
HAZARDOUS LOCATION INSTALLATION REQUIREMENTS 1. This equipment is suitable for use in Class I, Div 2, Groups A, B, C, and D, or unclassified or non- hazardous locations. 2. WARNING: Explosion Hazard - Substitution of components may impair suitability for Class I, Division 2. - Page 6 100 Series Industrial Ethernet Switches The 100 Series Unmanaged Industrial Ethernet Switches support high speed layer 2 switching between ports. This series of switches are housed in a ruggedized aluminum enclosure, and provide Category-5 compliant 10/100-BaseT connections for high performance network design, and hub/repeater upgrades.
-
Page 7: Package Contents
PACKAGE CONTENTS Please make sure the Serial over Ethernet package contains the following items: 100 Series Media Converter or Ethernet Switch Instruction Sheet Contact your carrier if any items are damaged. UNPACKING Remove all the equipment from the packaging, and store the packaging in a safe place. File any damage claims with the carrier. - Page 8 DIN rail. Rotate the bottom of the unit towards you and up at an approximate 15° upward angle to completely remove the unit. Most N-Tron™ designed to be mounted on industry standard 35mm DIN rail. However, DIN rail mounting may not be suitable for all applications.
-
Page 9: Front Panel
FRONT PANEL From Top to Bottom: Speed LED LNK/ACT Link/Activity LED RJ45 Ports Auto sensing 10/100BaseT Connection Green LED lights when Power is connected NOTE: The RJ45 data port has two LED’s located at the left side of the connector. The top LED indicates Activity (ACT), and the lower LED indicates Link (LNK) status. - Page 10 DC Voltage sources. Use wire sizes of 16-28 gauge. The power cord should be limited to less than 10 meters in order to ensure optimum performance. Recommended 24V DC Power Supplies, similar to: 100-240VAC: N-Tron NTPS-24-1.3, DC 24V/1.3A 5/17/2007...
- Page 11 (i.e. CE) are obtained when the N-Tron switch chassis is connected to earth ground via a drain wire. Some N-Tron switches have metal din-rail brackets that can ground the switch if the din-rail is grounded. In some cases, N-Tron switches with metal brackets can be supplied with optional plastic brackets if isolation is required.
-
Page 12: Connecting The Unit
100Base-T ports, plug a Category 5 (or greater) twisted pair cable into the RJ45 connector. Connect the other end to the far end station. Verify that the LNK LED’s are ON once the connection has been completed. To connect any other port to another Switch or Repeater, use a standard Cat5 straight through or crossover cable. -
Page 13: Fcc Statement
FCC STATEMENT This product complies with Part 15 of the FCC-A Rules. Operation is subject to the following conditions: (1) This device may not cause harmful Interference (2) This device must accept any interference received, including interference that may cause undesired operation. - Page 14 Regulatory Approvals: Safety: UL Listed per ANSI/ISA-12.12.01-2000 (US and Canada) This apparatus is suitable for use in Class I, Div 2, Groups A, B, C, and D UL Temperature Ratings: 102MC/MCE - T5 104TX, 105TX, and 108TX - T4A EMI: EN61000-6-4, EN55011 - Class A FCC Title 47, Part 15, Subpart B - Class A ICES-003 –...
- Page 15 102MC/MCE - KEY SPECIFICATIONS Physical Height: Width: Depth Including Din-Rail Clip: Weight: Electrical Input Voltage: Input Current: Inrush Current: Input Ripple: Input Wire Size: Environmental Operating Temperature: Storage Temperature: Operating Humidity: Operating Altitude: Network Media 10BaseT: > Cat-3 Cable 100BaseT: >...
- Page 16 104TX/105TX - KEY SPECIFICATIONS Physical Height: 2.9” (max.) Width: 1.50” (max.) Depth: 4.25” (max.) Weight: 0.60 lbs. Electrical Input Voltage: 10-30 VDC (Regulated) Input Current: 215 mA max. @ 24VDC (Steady State) Inrush Current: 7.8 Amp/0.7ms max. @ 24VDC Input Ripple: Less than 100 mV Input Wire Size: 16-28 AWG...
- Page 17 108TX - KEY SPECIFICATIONS Physical Height: Width: Depth Including DIN Rail Clip: Weight: DIN Rail Electrical Input Voltage: Input Current: Inrush Current: Input Ripple: Input Wire Size: Environmental Operating Temperature: Storage Temperature: Operating Humidity: Operating Altitude: Network Media 10BaseT: 100BaseT: Connectors 10/100BaseT: Recommended Minimum Wiring Clearance:...
- Page 18 N-TRON, Corp. warrants to the end user that this hardware product will be free from defects in workmanship and materials, under normal use and service, for the applicable warranty period from the date of purchase from N-TRON or its authorized reseller. If a product does not operate as warranted during the applicable warranty period, N-TRON shall, at its option and expense, repair the defective product or part, deliver to customer an equivalent product or part to replace the defective item, or refund to customer the purchase price paid for the defective product.
