Page 1: Assembly Manual
® ® 4.1 Bench SelectTech ® Assembly Manual Manual en Español Latino Americano: http://www.bowflex.com... -
Page 2: Table Of Contents
To validate warranty support, keep the original proof of purchase and record the following information: Serial Number ________________________________ Date of Purchase ____________________ To register your product warranty, go to: www.bowflex.com/register Or call 1 (800) 605–3369. If you have questions or problems with your product, please call 1 (800) 605–3369 Or go to: www.bowflex.com Nautilus, Inc., (800) NAUTILUS / (800) 628-8458, www.NautilusInc.com - Customer Service: North America (800) 605-3369,... -
Page 3: Important Safety Instructions
Important Safety Instructions This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Before using this equipment, obey the following warnings: Read and understand all warnings on this machine. Carefully read and understand the Assembly Manual. •... -
Page 4: Safety Warning Labels And Serial Number
Important Safety Instructions • Do not wear loose clothing or jewelry. This equipment contains moving parts. Do not put fingers or other objects into moving parts of the exercise equipment. • Always wear rubber soled athletic shoes when you use this equipment. Do not use the equipment with bare feet or only wearing socks. -
Page 5: Specifications
Specifications 19.7” 50 cm 60.5” 21.1” 153.8 cm 53.6 cm Maximum load limit 480 lbs. (218 kg) This product, its packaging, and components contain chemicals known to the State of California to cause cancer, birth defects, or reproductive harm. This Notice is provided in accordance with California’s Proposition 65. -
Page 6: Parts
Parts Item Description Main Frame Rear Stabilizer Front Stabilizer Leg Hold Down Assembly Tube, Foam Roller Pad, Foam Roller Seat Pad Back Pad... -
Page 7: Hardware
Hardware Item Description Button Head Hex Screw M8 X 60 Button Head Hex Screw M10 x 100 Button Head Hex Screw M10 x 75 Button Head Hex Screw M8 X 20 Flat Washer M8 Button Head Hex Screw M10 x 25 Lock Nut M10 Flat Washer M10 End Cap 3/4”... -
Page 8: Assembly Steps
Assembly Step 1: Attach Front and Rear Stabilizers 6 mm 6 mm... - Page 9 Assembly Step 2: Attach Seat Pad to Main Frame 5 mm...
- Page 10 Assembly Step 3: Attach Back Pad to Main Frame 5 mm...
- Page 11 Assembly Step 4: Install Leg Hold Down Attachment 6 mm Step 5: Final Inspection Inspect your equipment to ensure that all fasteners are tight, the equipment is level, and components are properly assembled. If necessary, adjust the feet until they are evenly balanced in contact with the floor.
-
Page 12: Bench Positions
Bench Positions Correctly adjust and safely engage all Positional Adjustment Devices. Keep your body weight centered on the bench while exercising. Flat 30° 45° 90° Decline with Seat raised... -
Page 13: Companion Exercise Equipment
Companion Exercise Equipment The Bowflex SelectTech 4.1 bench is designed for use with SelectTech dumbbell ® ® ® equipment. The SelectTech Dumbbell features an exclusive locking mechanism ® designed to assure proper and complete selection of the weight plates for each exercise. -
Page 14: Maintenance
Maintenance Equipment must be regularly examined for damage and repairs. The owner is responsible to make sure that regular maintenance is done. Worn or damaged components must be replaced immediately or the equipment removed from service until the repair is made. Only manufacturer supplied components can be used to maintain and repair the equipment. - Page 15 Warranty In the event that replacement parts or components do not correct the issue, Nautilus, Inc, reserves the right to replace the product or apply a limited credit reimbursement toward another Nautilus Inc. brand product, at our discretion. Reasonable substitution may be required depending upon Product availability.
- Page 16 Nautilus Bowflex Schwinn Fitness Universal ® ® ® ® 8001601.020413.B...
